- Page 1 ’ WNER ANUAL Ceiling Fan Installation Instructions For 5SH54XXD-L Series Fans READ AND SAVE THESE INSTRUCTIONS Total fan weight with light kit...
-
Page 2: Tools Required
Installation AFETY WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes ANSI/NFPA 70-1999), including fire-rated construction. - Page 3 Loosen set screws with locking nuts. Remove keeper from pin and then Loosen screw on downrod ball. pin from yoke for downrod. Thread the leadwires and safety cable through the downrod and place the downrod into the yoke. Insert Tighten the set screws securely. Slide the downrod ball down, remove the clevis pin by aligning the holes the cross pin and save.
- Page 4 Safety cable installation House Safety Cable Blue Black Lag Screw Black safety White White cable Green washer Ground lock 3” lag washer screw Hang assembled fan from the mounting bracket For Canadian installation and for USA fan and Connect black and blue wire from fan to installed to ceiling in previous steps.
- Page 5 Remove 3 screws on the ridge of the switch cap and save. If not installing the light kit skip to step 40. Push wires Place and press firmly on the capaci- through center hole of the switch tor to stick it to the switch housing. cap.
- Page 6 Installing without light kit. Attach switch cap to fan by lining up 3 screw holes and installing the 3 screws removed and saved from ear- lier step. Tighten screws securely.
- Page 7 ROUBLE HOOTING If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart.
