- Page 1 Owner’s Manual Ceiling Fan Installation Instructions Total fan weigh with light For 5SCR60BR3 Fan READ AND SAVE THESE INSTRUCTIONS Quality Ceiling fans...
-
Page 2: Installation
WARNING – Risk of fire, electric shock, or personal injury, The fan in this box may be either directly supported from a structural framing member of a building and/or may be mounted to an outlet box marked acceptable for fan support of 31.8 kg. (70 lbs.) or less. Most outlet boxes commonly used for the support of luminaires may not be acceptable for fan support and may need to be replaced. - Page 3 Align hole in downrod with hole in yoke and install cross pin. Install downrod into yoke. Install keeper into cross pin. Place glass into cage on fan body. Secure mounting neck to the mounting plate with four screws to become a complete mount- ing bracket.
- Page 4 . If you have more than one fan with remote. You can set the dip switches to different positiosns to have seperate control. Install remote receiver by sliding into opening in the Mounting bracket.
- Page 5 For light kit go to step 44 Remove plug from switch housing. Install lockwasher and hex nut pro- vided and tighten securely. Plug connector from fan to connector from switch housing. Twist lower cover plate into place by twisting in direction of arrow.
- Page 6 Raise decorative cover and twist clockwise until tight. Plug white wire from fan to white wire from light kit. Then plug blue wire from fan to black wire from light kit. Raise decorative cover and twist clockwise until tight. Install 3 x 60 watt (E12) base bulbs.
- Page 7 To control fan speed select from High, Medium or low speed buttons. To turn the fan off press the Fan on / off button. To dim upper lights press and hold U/L botton. To dim Lower lights press and hold D/L button. To turn off either up or down light press and quickly release either U/L or D/L button.
-
Page 8: Troubleshooting
If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet. - Page 9 6/21/06 REV.0 New made from 5GMR manual...
