mark on the brackets.
Route Beam Wires to the Operator (Non-prewired Installation)
Route Beam Wires to the Operator (Non-prewired Installation)
Route and secure the wires from the sender
and receiver back to the operator head.
Wiring the Beams to the Operator
Wiring the Beams to the Operator
Attach either twisted connection to the
operator's BEAM terminal. Connect the
other twisted connection to the operator's
COMMON terminal.
Wall
Station
NOTE: Route wires away from
the LED lights.
Install the Power Supply and Optional Mounting Bracket
Install the Power Supply and Optional Mounting Bracket
Connect the power wires to
the terminals (either wire to
either terminal).
Green
LED
Install the Power Supply and Optional Mounting Bracket
Install the Power Supply and Optional Mounting Bracket
DECORA – STANDARD STYLE –
CENTER FASTENER CENTER FASTENER
Spread the ears of the optional retaining bracket apart, and then plug the power
supply into the outlet. The included zip tie can be used to secure the mounting
ears together.
4
Adjusting the Open and Close Limits
Spread the ears of the optional retaining bracket apart, and then plug the power
supply into the outlet. The included zip tie can be used to secure the mounting
ears together.
NOTE: The operator
is preset on its
close limit and the
open limit is preset
for a 7-foot high
door.
OPEN LIMIT (optional):
Press both the UP and LEARN buttons for
three seconds. The operator will beep
and flash two times. Press the UP or
DOWN buttons to jog the operator to the
open limit position. Press the LEARN
Beams (L or R)
button to store the setting, two long
beeps for confirmation, and exit setup.
CLOSE LIMIT (optional):
Press both the DOWN and LEARN buttons
for three seconds. The operator will beep
and flash two times.
Press the UP or DOWN buttons to jog the operator to the closed limit position. Press
the LEARN button to store the setting, two long beeps for confirmation, and exit setup.
Setup the Safety Reversal System
Be sure that the trolley latch is up,
and the door is connected to the
Power Terminal
operator.
After limits have been set, the
learning process will be complete
after the fourth cycle.
Nice G.O. Homeowner Smartphone App Installation
Nice G.O. Homeowner Smartphone App Installation
Download, Register and Activate Application
Use the homeowner's smartphone to visit the app
store to download and install the Nice G.O. application.
On initial use, you'll be asked to register and create
their account. Once completed, sign in with the new
account information.
SECURED
Connect the Opener to the Nice G.O. app
Using the Nice G.O. app on your mobile device,
tap the plus sign at the bottom right of screen to
Connect Your Device. Follow directions in app to
Connect Your Device.
Adjusting the Open and Close Limits
Adjusting the Open and Close Limits
WALLSTATION
GREEN LED
WALLSTATION
BEAMS
RED LED
BEAMS
UP(+)
LEARN
DOWN (-)
POWER
DOWN
Automatic Door Force Setup
Automatic Door Force Setup
4
4
Scan to download
the app.
5
Adding a Transmitter or Keypad Code Adding a Transmitter or Keypad Code
UP +
Press & release LEARN button
LEARN
DOWN
Red LED will light for 15 seconds (ready to Learn)
Push Transmitter button or enter Keypad Code
1 flash = Transmitter button or Keypad Code learned
Erasing a Transmitter or Keypad Code Erasing a Transmitter or Keypad Code
UP +
UP Press & release LEARN button
LEARN
DOWN -
Red LED will light for 15 seconds (ready to Learn)
Push Transmitter button or enter Keypad Code
4 flashes = Transmitter button or Keypad Code erased
Erasing All Transmitters or Keypads
Erasing All Transmitters or Keypads
UP +
Press LEARN button for 10 seconds
LEARN
DOWN -
3 flashes = All Transmitters & Keypads erased
Setting the Open Limit
NOTE: LIMITS ARE PRESET FOR 7-FOOT DOORS
UP +
Press LEARN & UP for 3 seconds
LEARN
DOWN -
2 green flashes = Set UP limit
UP +
Press UP (+) or DOWN (-) to jog the door to the correct posi-
LEARN
DOWN -
UP +
Press LEARN to store the limit
Customer Service
LEARN
DOWN -
(800) 421-1587
2 green flashes = Open Limit stored
M – F, 8am – 7pm EST
Niceforyou.com
