INSTALLATION
INSTRUCTIONS
REVISION
Form No. 3108477.054 2/05
(Replaces 3108477.047)
(French 3109437.040)
©2005 Dometic Corporation
LaGrange, IN 46761
59528, 59529 & 59530 Series Air Conditioner With Analog Thermostat and Air Distribution Box
ROOF TOP AIR CONDITIONER
3107210 AIR DISTRIBUTION BOX KIT and
3107541.009 ANALOG RELAY KIT
This manual must be read and un-
derstood before installation, adjust-
ment, service, or maintenance is per-
formed. This unit must be installed
by a qualified service technician.
Modification of this product can be
extremely hazardous and could re-
sult in personal injury or property
damage.
Important:
Instructions must stay with unit.
Owner read carefully
BRISK AIR
59528 Series
59529 Series
59530 Series
USED WITH
C
US
Lire et comprendre ce manuel avant
de procéder à l'installation, à des
réglages, de l'entretien ou des
réparations. L'installation de cet
appareil doit être effectuée par un
réparateur qualifié. Toute modification
de cet appareil peut être extrêmement
dangereuse et entraîner des blessures
ou dommages matériels.
1
RECORD THIS INFORMATION FOR FUTURE
REFERENCE BEFORE INSTALLING THE
UNIT:
Model Number
Serial Number
Date Purchased
Place of Purchase
®
MODELS
59528.601
59530.532
59529.531
59530.536
59529.601
59530.601
59529.631
59530.631
59530.531
