- Page 1 Blue e+ fan-and-filter unit Fan-and-filter unit SK 3237.7xx/.8xx SK 3241.7xx/.8xx SK 3238.7xx/.8xx SK 3243.7xx/.8xx SK 3239.7xx/.8xx SK 3244.7xx/.8xx SK 3240.7xx/.8xx Assembly and operating instructions...
- Page 2 Preface Preface Dear Customer! Thank you for choosing a fan-and-filter unit from Rittal. Yours Rittal GmbH & Co. KG Rittal GmbH & Co. KG Auf dem Stuetzelberg 35745 Herborn Germany Phone: +49(0)2772 505-0 Fax: +49(0)2772 505-2319 E-Mail: info@rittal.com www.rittal.com www.rittal.de We are always happy to answer any technical ques- tions regarding our entire range of products.
-
Page 3: Table Of Contents
Inspection and maintenance ....12 Storage and disposal ......12 Technical specifications ...... 13 Cut-out/drilling dimensions ....20 EMC fan/outlet filter ......21 Accessories ........22 Connection diagrams ......24 Declaration of conformity ....25 Rittal Blue e+ fan-and-filter unit assembly and operating instructions... -
Page 4: Notes On Documentation
Safety instructions Please observe the following safety instructions when assembling and operating the unit: Fig. 1: Product description – Always wear the prescribed personal protective equipment when working on the fan-and-filter unit. Rittal Blue e+ fan-and-filter unit assembly and operating instructions... -
Page 5: Functional Description
This reduces energy costs, and extends the service Tab. 1: Scope of supply life of the fans and filters. The Rittal fan-and-filter unit series with EC fans offers the highest energy efficien- cy as well as a wide range of closed-loop control and Assembly and connections monitoring options. -
Page 6: Layout Of The Components In The Enclosure
Lines indicating the dimensions of cut-outs and drilling of the following accessories: specifications for mounting and fixing of the fan (only – IP55 by using a pleated filter and absorber mat. Rittal Blue e+ fan-and-filter unit assembly and operating instructions... -
Page 7: Safety Clip
– 2.5 mm² fine-wire soldered). Fig. 4: Removing the safety clip Notes on electrical connection When performing the electrical connection, it is impor- tant to observe all valid national and regional regula- Rittal Blue e+ fan-and-filter unit assembly and operating instructions... -
Page 8: Rotating The Voltage Connection
Rotating the voltage connection If the position of the voltage connection is not ideally accessible, it may be rotated through 90° and snapped into position. Rittal Blue e+ fan-and-filter unit assembly and operating instructions... -
Page 9: Changing The Direction Of Airflow
◾ Unlock the bayonet connection and detach the fan housing from the filter box. This is done in the same way as described in section 5.2 "Rotating the voltage connection", page 8. ◾ Turn the fan housing by 180°. Rittal Blue e+ fan-and-filter unit assembly and operating instructions... -
Page 10: Commissioning
– 400/460 V, 3-phase Installing and changing the filter The fan-and-filter unit and outlet filter are supplied as standard with a pleated filter for pre-filtering dry coarse dust and lint in the ambient air. Rittal Blue e+ fan-and-filter unit assembly and operating instructions... -
Page 11: Replacing The Chopped-Fibre Filter
If it becomes necessary to change the direc- tion of the airflow (see section 5.3 "Chang- Fig. 16: Installing the IP55 pleated filter ing the direction of airflow", page 9), the installation is reversed accordingly. Rittal Blue e+ fan-and-filter unit assembly and operating instructions... -
Page 12: Inspection And Maintenance
Sequence of maintenance measures: – Check the level of dirt. – Filter soiling? Replace the filter. – Fan membranes soiled? Clean. – Check the noise generation of the fan. – Compressed air cleaning Rittal Blue e+ fan-and-filter unit assembly and operating instructions... -
Page 13: Technical Specifications
±10 Power consumption 13.0/11.1 12.0/10.0 Pre-fuse T Motor circuit-breaker – Air throughputs (further information can be found in the characteristic curves on the Rittal homepage) Unimpeded airflow with chopped-fibre filter m³/h 20/25 With outlet filter including chopped-fibre filter m³/h 15/18 Unimpeded airflow with pleated filter m³/h... - Page 14 ±10 Power consumption 14.7/16.5 15.4/15.8 Pre-fuse T Motor circuit-breaker – Air throughputs (further information can be found in the characteristic curves on the Rittal homepage) Unimpeded airflow with chopped-fibre filter m³/h 53/64 With outlet filter including chopped-fibre filter m³/h 40/46 Unimpeded airflow with pleated filter m³/h...
- Page 15 ±10 Power consumption 14.7/16.5 15.4/15.8 Pre-fuse T Motor circuit-breaker – Air throughputs (further information can be found in the characteristic curves on the Rittal homepage) Unimpeded airflow with chopped-fibre filter m³/h 100/115 With outlet filter including chopped-fibre filter m³/h 75/86 Unimpeded airflow with pleated filter m³/h...
- Page 16 Power consumption 33.1/37.3 35.5/38.2 10.1 Pre-fuse T Motor circuit-breaker – Air throughputs (further information can be found in the characteristic curves on the Rittal homepage) Unimpeded airflow with chopped-fibre filter m³/h 175/157 With outlet filter including chopped-fibre filter m³/h 130/112 Unimpeded airflow with pleated filter m³/h...
- Page 17 Power consumption 43.2/54.5 43.4/52.2 19.1 Pre-fuse T Motor circuit-breaker – Air throughputs (further information can be found in the characteristic curves on the Rittal homepage) Unimpeded airflow with chopped-fibre filter m³/h 225/245 With outlet filter including chopped-fibre filter m³/h 173/187 Unimpeded airflow with pleated filter m³/h...
- Page 18 ±10 Power consumption 77.7/106.4 78.7/102.8 Pre-fuse T Motor circuit-breaker – Air throughputs (further information can be found in the characteristic curves on the Rittal homepage) Unimpeded airflow with chopped-fibre filter m³/h 540/590 With outlet filter including chopped-fibre filter m³/h 444/498 Unimpeded airflow with pleated filter m³/h...
- Page 19 120.7/166.1 116.9/165.6 Pre-fuse T – Motor circuit-breaker – 0.2…0.4 Air throughputs (further information can be found in the characteristic curves on the Rittal homepage) Unimpeded airflow with chopped-fibre filter m³/h 700/770 With outlet filter including chopped-fibre filter m³/h 537/587 Unimpeded airflow with pleated filter m³/h...
-
Page 20: Cut-Out/Drilling Dimensions
255 x 255 224 x 224 3241.xxx 255 x 255 224 x 224 3243.xxx 323 x 323 144.5 292 x 292 3244.xxx 323 x 323 292 x 292 Tab. 10: Cut-out dimensions Rittal Blue e+ fan-and-filter unit assembly and operating instructions... -
Page 21: Emc Fan/Outlet Filter
(see accompanying drilling template). dia (model nos. 3237.067, 3238.066, 3239.066, 3240.066, 3243.066). Model No. F mm Ø mm 3237.xxx 100.5 3238.xxx 132.5 3239.xxx 3240.xxx 3241.xxx 3243.xxx 3244.xxx 3245.xxx Tab. 11: Drilling dimensions Rittal Blue e+ fan-and-filter unit assembly and operating instructions... -
Page 22: Accessories
5 pc(s). 3238.025 3239.xxx ISO ePM10 55% 5 pc(s). 3181.125 3240.xxx/3241.xxx ISO ePM10 55% 5 pc(s). 3182.125 3243.xxx/3244.xxx ISO ePM10 55% 5 pc(s). 3183.125 Tab. 15: IP55 pleated filter for fan-and-filter unit Rittal Blue e+ fan-and-filter unit assembly and operating instructions... - Page 23 1 pc(s). 3243.080 NEMA 4, NEMA 4X Tab. 17: Hose-proof hoods Safety clip To fit Model No. Packs of Model No. 3237.xxx/3238.xxx 1 pc(s). 3201.940 3239.xxx/3240.xxx/3241.xxx/3243.xxx/3244.xxx 1 pc(s). 3201.941 Tab. 18: Safety clip Rittal Blue e+ fan-and-filter unit assembly and operating instructions...
-
Page 24: Connection Diagrams
3244 .700/.708/.710/ .718/.800/.810 .718/.800/.810 3239 .700/.708/.710/ .718/.800/.810 24 V DC – N PE L2 L3 PE 3240 .700/.708/.710/ 3244.740 3237.724 .718/.800/.810 3238.724/.824 3241 .700/.708/.710/ 3239.724/.824 .718/.800/.810 3240.724 3241.724 Fig. 23: Connection diagrams Rittal Blue e+ fan-and-filter unit assembly and operating instructions... -
Page 25: Declaration Of Conformity
2011/65/EU Hazardous Substances Directive (RoHS) 2014/30/EU EMC Directive Verantwortlich für Dokumentation Responsible for documentation Rittal GmbH & Co. KG Auf dem Stützelberg 35745 Herborn 2023 - 000097 - 01 Seite 1 von 1 Rittal Blue e+ fan-and-filter unit assembly and operating instructions... - Page 26 Notes Rittal Blue e+ fan-and-filter unit assembly and operating instructions...
- Page 27 Notes Rittal Blue e+ fan-and-filter unit assembly and operating instructions...
- Page 28 ◾ Climate Control ◾ IT Infrastructure ◾ Software & Services You can find the contact details of all Rittal companies throughout the world here. www.rittal.com/contact RITTAL GmbH & Co. KG Auf dem Stuetzelberg · 35745 Herborn · Germany Phone +49 2772 505-0...
