2. Lock Installation
A. Install cylinder.
Connecting
Backplate
Bar
Cylinder
Connecting
Ring
Screws
(Break off to
suit.)
3. Frame Prep and Strike Installation
A. Mortise frame to suit.
B. Drill pilot holes.
C. Install strike.
Attaching
2.008"
(51mm)
1/4"
(6.4mm)
1-1/4"
(32mm)
Hole
1-855-557-5078 • www.accentra-assaabloy.com
Copyright © 2018-2024 ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
Cylinder
Strike
Screws
UP
2-3/8" (60mm) Backset
N ° .1
1/8"
(3mm)
Pilot Hole (3)
2.638"
(67mm)
B. Install lock.
Attaching
Screws (3)
Lock
Same height
as lock
.709"
.709"
(18mm)
(18mm)
2-3/8" (60mm) Backset
.709"
.709"
(18mm)
(18mm)
UP
N ° .2
1/8"
(3mm)
Pilot Hole (3)
2.638"
(67mm)
2.008"
(51mm)
1/4"
(6.4mm)
1-1/4"
(32mm)
Hole
80-9350-0001-000 01/24
