- Page 1 GREEN ARROW, BLUE ARROW KATAMARAN 26113, 26114 JUST REMOTE-CONTROLLED BEDIENUNGSANLEITUNG OPERATION MANUAL...
- Page 3 Welcome to AMEWI The Amewi Trade GmbH is an international import- and wholesale company for R/C models, toys and creative items, located in Borchen near Paderborn, Germany. Our product range includes over 10,000 items. Above all, this includes remote-controlled car, helicopter, boat, and tank models as well as a wide range of accessories and all necessary spare parts.
-
Page 4: Sicherheits- Und Gefahrenhinweise
This product has been manufactured according to actual technical standards. The product is matching the requirements of the existing European and national guidelines. The Declaration of Conformity has been proofed. AMEWI Trade GmbH declares that this product is matching the basic requirements and remaining regulations of the guideline 2014/53/EU {RED). The declarations and documents are stored at the manufacturer and can be requested and applied there. - Page 5 Improper use such as short-circuiting, or overcharging may result in explosion or fire. Keep the battery in a safe place that babies or children cannot reach. The above indicates the danger of using the battery. The user assumes full responsibility for the outcome of using the battery. amewi.com...
- Page 6 DISPOSAL ENTSORGUNGSHINWEISE / Die Firma AMEWI Trade GmbH ist unter der Batt-Reg.-Nr. DE 77735153 sowie der WEEE-Reg.-Nr. 93834722 bei der Stiftung EAR angemeldet und recycelt alle gebrauchten elektronischen Bauteile ordnungsgemäß. Elektrische und elektronische Geräte dürfen nicht in den Hausmüll. Entsorgen Sie das Produkt am Ende seiner Lebensdauer gemäß...
- Page 7 Vielen Dank für den Kauf des Amewi Green Arrow, Blue Arrow Katamarans. Bitte lesen Sie die Bedienungsanleitung aufmerksam durch und bewahren Sie sie für spätere Fragen auf. Thank you for purchasing the Amewi Green Arrow. Blue Arrow Catamaran. Please read the instruction manual carefully and keep it for future reference.
-
Page 8: Wichtige Hinweise
Sendemasten. Orten mit aktiven Funkwellen. Near crowds or in public places. In rivers or flowing waters. Near electricity pylons or other Near a radio tower, mobile phone transmission towers. masts or other places with active radio waves. amewi.com... - Page 9 Da das Produkt kleinteile enthält, auf öffentlichen Straßen oder halten Sie es von kleinen Kindern fern. überfüllten Plätzen. As the product contains small parts, Do not operate the model on keep it away from small children. public roads or crowded places. amewi.com...
-
Page 10: Die Fernsteuerung
Lenkung D/R Gas D/R Steering D/R Gashebel Throttle D/R Binden Throttle Code matching trigger An/Aus Schalter / Power Batteriefach Battery compartment Für die Fernsteuerung werden vier 1,5V AA-Batterien benötigt. Four 1.5V AA batteries are required for the remote control. amewi.com... -
Page 11: Batterien Einlegen
Open the battery compartment cover and insert four 1.5V AA batteries. Ensure that the polarity is correct. Close the battery compartment cover. THE BOAT DAS BOOT / Anlenkung Pull rod Wasserauslass / Water outlet Wassereingang / Water inlet Lenkung Steering Verschluss Lock knob amewi.com... -
Page 12: Akku Laden
Connect the USB charging cable to a USB socket on a PC. laptop, mobile phone charger or power bank. A red indicator light illuminate. 2. Connect the balance plug of the battery to the charging cable. The green charging indicator light flashes. When the green LED lights up continuously, the charging process is complete. amewi.com... - Page 13 Put the battery into the battery mount and make sure it is Connect the battery to the electronic. firmly seated. Montieren Sie die Rumpfabdeckung wie gezeigt. Montieren Sie die Abdeckung wie gezeigt. Install the hull cover as shown. Install the seal cover as shown. amewi.com...
-
Page 14: Bedienung
Press the BND button and wait until the blue indicator light stops flashing and lights up continuously. The boat and remote control are now connected. Kontrollleuchte Bindeknopf Indicator light Frequency matching button OPERATION BEDIENUNG / Vorwärts: Ziehen Sie den Gashebel nach hinten. Forward: pull the throttle trigger back. amewi.com... -
Page 15: Funktionen Der Fernsteuerung
Über den ST.DR Poti können Sie den maximalen Winkel des Ruders einstellen. You can set the maximum angle of the rudder using the ST.DR potentiometer. Lenkung Dual Rate Steering Dual Rate ST.D/R ST.D/R Min. Lenkausschlag Max Lenkausschlag Min steering angle Max steering angle amewi.com... -
Page 16: Remote Control Batteries
If the indicator light on the remote-control flashes and beeps are heard, this indicates that the power of battery in the boat is low. Please drive to the shore as quickly as possible and charge or replace the battery. amewi.com... -
Page 17: Wartung / Maintenance
If there is a lot of water in the hull, you can let it flow out via the drain plug at the back. Make sure you leave the boat open to dry out completely to avoid corrosion. amewi.com... - Page 20 amewi.com...
