  • Page 1 User Manual Uninterruptible Power Supply System Zeus 2 208V...

  • Page 2: Table Of Contents

    Please comply with all warnings and operating instructions in this manual. This equipment should only be installed, serviced, and maintained by qualified personnel. Do not operate this unit before reading through all safety information and operating instructions carefully. Disclaimer We assumes no responsibility or liability for loss or damages, whether direct, indirect, consequential or incidental, which might arise out of the use of such information.

  • Page 3: Safety And Emc Instructions

    1. Safety and EMC instructions SAVE THESE INSTRUCTIONS: This Manual Contains Important Instructions. All safety instructions in this document must be read, understood and followed. 1-1. Transportation and Storage Please transport the UPS system only in the original packaging to protect against shock and damage. The UPS must be stored in the room where the temperature is well regulated.

  • Page 4: Connection Warnings

    1-4. Connection warnings • In accordance with safety standard, installation has to be provided with a "Backfeed protection" system, as for example a contactor, which will prevent the appearance of voltage or dangerous energy in the input mains during a mains fault.

  • Page 5: Standards

    1-6. Standards * Safety UL 1778, CSA C22.2 No.107.3-14 * EMI Conducted Emission: FCC Part 15, Subpart B Class A Radiated Emission: FCC Part 15, Subpart B Class A NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.

  • Page 6: Wiring Terminal View

    2-3. Wiring Terminal View Diagram 2: 15K/20K Rear Panel Diagram 1: 10K Rear Panel Diagram 4: 15K/20K L Input/Output Terminal Diagram 3: 10K Input/Output Terminal...
  • Page 7 Diagram 6: 40KL front view with door Diagram 5: 30KL front view open with door removed Diagram 7: 30KL Imput/ Terminal Diagram 8: 40KL Imput/ Terminal...

  • Page 8: Operation Principle

    1. RS-232 communication port (only for firmware updates) 2. USB communication port 3. Emergency power off function connector (EPO connector) Note: Keep the EPO connector closed for UPS normal operation. To activate EPO function, please remove the jumper 4. Share current port (only available for parallel model) 5.

  • Page 9: Single Ups Installation

    2-5. Single UPS Installation Installation and wiring must be carried out in accordance with the local electric laws and regulations by trained profes- sionals. 1) Make sure that the mains wire and breakers of the building are rated for the capacity of the UPS to prevent electric shock or risk of fire.
  • Page 10 Terminal block wiring diagram for 15K(L) /20K(L) Terminal block wiring diagram for 30KL/40KL...
  • Page 11 Battery connection wiring NOTE 1: Make sure that the wires are connected securely with the terminals. NOTE 2: Please install the output breaker between the output terminal and the load, and the breaker should have leak- age current protective function if necessary. 6) Put the terminal block cover back at the rear panel of the UPS.

  • Page 12: Ups Installation For Parallel System

    2-6. UPS Installation for Parallel System If the UPS is only for single operation, you may skip this section. 1) Install and wired the UPS according to the section 2-5. 2) Connect the output wires of each UPS to an output breaker. 3) Connect all output breakers to a centralize breaker.

  • Page 13: Software Installation

    6) Refer to the following communication wiring diagrams for share current cable and parallel cable connections. Diagram 1: Two UPSs in parallel Diagram 2: Three UPS in parallel Parallel system for 10K(L)/15K(L)/20K(L) Diagram 1: Two UPSs in parallel Diagram 2: Three UPS in parallel Parallel system for 30KL/40KL 2-7.

  • Page 14: Led Indicators And Lcd Panel

    3-2. LED Indicators and LCD Panel LED Indicators: There are 4 LEDs on front panel to show the UPS working status: Mode/LED Bypass Line Battery Fault UPS On Standby mode Bypass mode Line mode Battery mode CVCF mode Battery Test ECO mode Fault Note:...

  • Page 15: Screen Description

    3-3. Screen Description After initialization, the LCD will display the main screen. There are five sub-menus: Control, measure, setting, informa- tion and data log. Touch any sub-menu icon to enter into the sub-screen. Menu tree...
  • Page 16 3-3-1. Main screen Upon powering on, the LCD will start initialization after a few seconds, as shown below. After initialization, the main screen will display as shown below. On the button, there are five icons to represent five sub-menus: Control, Measure, Setting, Information, Data Log.
  • Page 17 3-3-2. Control screen Touch the icon to enter the control sub-menu. Touch the icon to return to the main interface regardless of whether any of the submenu screens are active. Screen 1.0 «Control» interface and sub-menus...
  • Page 18 UPS On/Off It will show “Turn on UPS?” when UPS is off. It will show “Turn off UPS?” when UPS is on. Touch “YES” to turn on or off the UPS. Then, the screen will return to the main screen. Touch “Back” to return to the main screen immediately or “No”...
  • Page 19 Audio mute It will show “Mute all” if the audio is active. Touch “Yes” to activate mute. If “Mute all” is active, I will show icon on the top left corner of the main screen. Touch “Back” to return to CONTROL screen immediately or “No” to cancel this operation and back to CONTROL screen.
  • Page 20 3-3-3. Measure screen Touch the icon to enter the Value page. Touch the icon to browse through the information. Touch the icon to return to the main screen. Touch the icon to go back to the previous menu. Value screen - Page 1 •...
  • Page 21 Value screen - Page 3 • INPUT W: R, S and T input power in watt. • INPUT VA: R, S and T input power in VA. • INPUT W (%): R, S and T input power watt in percentage. •...
  • Page 22 The authority list: UPS operation mode Authorization Standby Bypass Battery Battery test Converter Line mode Fault mode mode mode mode mode mode mode Setting item User Maintainer password Date/Time Language Input source Contact Phone Mail Audio alarm Energy Star Output voltage Output frequency CVCF mode Bypass forbid...
  • Page 23 General setting General screen - Page 1 • Date/Time: Set the date and time. The format is YYYY-MM-DD HH:MM:SS. The calendar day will be automatically changed when the year, month and date are set. • Language: Set the LCD language. Only English is available. •...
  • Page 24 Advance setting Advanced- Password page It’s required to enter a 4-digit password to access the “ADVANCE” page. ADVANCE → User To access the “Advance → User” Setting menu page, the default password is “0000”. If entered password is right, the page will jump to the setting screen. If the password is wrong, it will ask to enter again. Password error page Advance Setting Menu Page There are three sub-menus under Advance →...
  • Page 25 ELECTRICAL Electrical Setting - Page 1 Output Voltage: Select the output rated voltage. •There are two options, 120V and 127V. 120Vac is the default setting. Output Frequency: Select output rated frequency. • 50Hz: The output frequency is set for 50Hz. •...
  • Page 26 Bypass at UPS off: Select the bypass status when manually turning off the UPS. This setting is only available when “Bypass forbid.” is set to “Disable”. • Enable: Bypass enabled. When selected, bypass mode is activated. • Disable: Bypass disabled. When selected, no output through bypass when manually turning off the UPS. Bypass Voltage Range: Set the bypass voltage range.
  • Page 27 MISCELLANEOUS Miscellaneous setting page • Auto restart - Enable: If this option is selected, when the UPS shuts down due to low battery, the UPS will return to line mode once utility power is restored. - Disable: After “Disable” is set, the UPS will not automatically turn on if a UPS shutdown occurs and the utility restores.
  • Page 28 SYS PARAMETER SYS PARAMETER - Page 1 • Mode Name: Set the UPS model name. • Serial Number: Set the serial number. • Manufacturer: Set the UPS manufacturer. • Charger Number: The number of charging boards installed in the UPS. NOTE: It’s required to restart the UPS after setting.
  • Page 29 INSTALL INFO INSTALL INFO Page • SYS Install Date: Set the date of UPS installation. • BAT Install Date: Set the date of Battery installation. VOL CALI VOL CALI - Page 1 • Bus VOL: BUS voltage calibration. Each click is 0.1% no matter it’s pressing up or down key .
  • Page 30 VOL CALI - Page 2 • Line VOL: Line voltage calibration. Each click is 0.1% no matter if it’s pressing up or down key . Press “up” key to increase 0.1% and press “down” key to decrease 0.1%. Press “OK” key to confirm the modification. •...
  • Page 31 CURR CALI CURR CALI Page • Output CURR: Output current calibration. Each click is 0.1% no matter it’s pressing up or down key . Press “up” key to increase 0.1% and press “down” key to decrease 0.1%. Press “OK” key to confirm the modification. INITIAL INITIAL menu page INITIAL DATALOG page...
  • Page 32 INITIAL PARAMETERS Page • PARAMETERS: After pressing the confirmation window, it will pop up as shown in above screen. Touch “YES” to restore default value. Touch “Back” or “No” to cancel this operation and go back to the INITIAL menu page. INITIAL CALI page •...
  • Page 33 INITIAL TOUCH screen • TOUCH CALI: After pressing the confirmation window, it will pop up as shown on the above screen. Touch screen to recalibrate. Then, the blue screen appears and please click on the place of the cross with your mouse. ELECTRONIC Electrical setting - Page 1 •...
  • Page 34 Electrical setting - Page 2 • Bypass UPS off: Select the bypass status when manually turning off the UPS. This setting is only available when “Bypass forbid” is set to “Disable”. - Enable: Bypass enabled. When selected, bypass mode is activated. - Disable: Bypass disabled.
  • Page 35 BATTERY Battery setting page • Battery Warning Voltage: - HIGH: High battery warning voltage. The setting range is 14.0V ~ 15.0V. 14.4V is the default setting. - LOW: Low battery warning voltage. The setting range is 10.1V ~ 14.0V. 11.4V is the default setting. This parameter setting is related to the “Shutdown Voltage”...
  • Page 36 MISCELLANEOUS Miscellaneous setting page • Auto restart - Enable: After “Enable” is set, once UPS shutdown occurs due to low battery and then utility restores, the UPS will return to line mode. - Disable: : After “Disable” is set, once UPS shutdown occurs and the utility restores, the UPS will not automatically turn on.
  • Page 37 UPS SELFTEST This function is only effective when UPS type setting is “HV”. Therefore, please disconnect all loads and utility first before executing this function. Then, please change UPS type to “HV”. For the detailed operation, please check “System Parameter” menu under Advance → Maintainer directory. After changing UPS type to “HV”, you have to restart the UPS.
  • Page 38 3-3-5. Information screen Touch the icon to open the information page. Touch the icon to browse the information. Touch the icon to return to main screen. Touch the icon to go back to the previous menu. Basic Information Page 1 Basic information •...
  • Page 39 Rated information page Rated information • Output Voltage: It shows output rated voltage. • Output FRE: It shows output rated frequency. • CVCF Mode: Enable/Disable CVCF mode. • Bypass Forbid: Enable/disable bypass function. • Bypass UPS Off: Enable/disable auto bypass function when UPS is off. •...
  • Page 40 Parameter Information - Page 2 • BATT Mode Work Time: The maximum discharge time in battery mode. • BATT Warning Voltage: - HIGH: High battery warning voltage. - LOW: Low battery warning voltage. • Shutdown Voltage: If battery voltage goes below this point, the UPS will automatically shut down. •...

  • Page 41: Audible Alarm

    3-3-6. Data Log screen Touch the icon to open the data log page. Data log is used to record the warning and fault information of the UPS. The record contains date and time, code, type, and description. Touch the icon to move up or down the page if there is more than one in the data log.

  • Page 42: Single Ups Operation

    3-5. Single UPS operation 1. Turn on the UPS with utility power (in AC mode) 1) After power mains is connected correctly, set the breaker of the battery pack to “ON” position (this step only necessary for long-run model). Then set the line input breaker to “ON” position. At the same time the fan will start running and the UPS will start initialization.
  • Page 43 2) In Battery mode, users can touch “SETTING” → “Basic” → Audio Mute to enable “Mode Mute” to disable the buzzer. 3) The backup time of the long-run model depends on the external battery capacity. 4) The backup time may vary from different operating temperature and load type. 5) When setting discharging time for 16.5 hours (default value from LCD menu), after discharging 16.5 hours, UPS will shut down automatically to protect the battery.

  • Page 44: Parallel Operation

    3-6. Parallel Operation 1. Parallel system initial startup 1) Turn on each UPS in AC mode respectively (Refer to section 3-5(1)). Then, measure the inverter output voltage of each phase for each UPS with a multi-meter. Calibrate the inverter output voltage by configuring inverter voltage adjustment (Refer to SETTING →...

  • Page 45: Fault Code

    Warning: (Only for the parallel system) • Before turning on the parallel system to activate inverter, make sure that all unit’s maintenance switch at the same position. • When the parallel system is turned on, please do not operate the maintenance switch of any unit. •...

  • Page 46: Trouble Shooting

    4. Troubleshooting guide If the UPS system does not operate correctly, please solve the problem by using the table below. Symptom Possible cause Solution No indication and alarm in the front The AC input power is not connected Check if input cable firmly connected display panel even though the mains well.

  • Page 47: Storage And Maintenance

    5. Storage and Maintenance 5-1. Storage Before storing, charge the UPS for at least 7 hours. Store the UPS covered and upright in a cool, dry location. During stor- age, recharge the battery in accordance with the following table: Storage temperature Recharge frequency Charging time -25°C - 40°C...

  • Page 48: Specifications

    6. Specifications FTP-210K FTP-215K FTP-220K FTP-230K FTP-240K Specification Galleon II 3in/3out LV 10K-40K 208V UL General Capacity 10KVA / 10KW 15KVA / 15KW 20KVA / 20KW 30KVA / 30KW 40KVA / 40KW Topology True Double Conversion Phase 3-Phase In / 3-Phase Out Input 3 x 208/220 VAC (Ph-Ph) Nominal Voltage...
  • Page 49 Charging Current 12A MAX 12A MAX 16A MAX Charging Voltage 140V Float voltage 136.5V 107V @ 0% < load ≤ 30% End of discharge voltage 102V @ 30% < load ≤ 70% 107V 9.6V @ 70% < load Max. charging power 2880 W 3840 W 10 min @9Ah/40...
