- Page 1 WAY-FI PLUS KIT ADVANCED INSTALLATION MANUAL...
- Page 2 Technical publication for information purposes released by FERMAX ELECTRÓNICA S.A.U. FERMAX ELECTRÓNICA applies a continuous improvement policy, therefore it reserves the right to modify the contents of this document, as well as the product specifications referred to therein, at any time and without prior notice.
-
Page 3: Table Of Contents
ON THE TYPE OF CABLE 2.6 ELECTRIC DOOR LOCK CONNECTION 2.7 INSTALLATION 2.8 SPECIFICATIONS 2.9 MAIN SCREEN 2.10 SCREENS SETTINGS 3 INITIAL CONFIGURATION 4 APP NAVIGATION 4.1 CALLS 4.2 APP NAVIGATION 5 INTEGRATION WITH GOOGLE HOME AND ALEXA WAY-FI PLUS KIT... -
Page 4: Main Specifications
• White LED lighting with automatic sensor. • Wide-angle camera (122ºH, 63ºV). • High sensitivity 2M CMOS camera. 1.3 POWER SUPPLY • Universal AC input (100-240 V AC 50/60 Hz) • Supports overcurrent and short-circuit protection • DIN rail mounting WAY-FI PLUS KIT... -
Page 5: Description Of The Main Elements
White LED when on Do not disturb Purple LED when the DND function is on Missed call indicator Green LED when there are new images/videos Connector Interface for bus, buzzer and F1 Loudspeaker Plays visitors' voices and call ringtones WAY-FI PLUS KIT... -
Page 6: Outdoor Panel
GDRPD (EU) 2016/679. Current personal data protection legislation in EU countries requires a label to be affixed to the outdoor panel if video capture is being used. This occurs when the kit monitor has activated this function, or if you capture images from the WAY-FI PLUS KIT... -
Page 7: Wiring Diagram
Do not connect a door lock with an operating voltage other than 12 Vdc or higher than 250mA. Recommended door lock: REF: F29588 Note: Maximum of 2 outdoor panels, 1 master monitor + 5 slave monitors, 1 buzzer pushbutton. WAY-FI PLUS KIT... -
Page 8: Table Of Distances Depending On The Type Of Cable
The cameras that are connected by cable are connected to the router on the Ethernet outputs. Cameras that connect via Wi-Fi are paired via the mobile application. WAY-FI PLUS by FERMAX. 2.5 TABLE OF DISTANCES DEPENDING ON THE TYPE OF CABLE Last panel -... -
Page 9: Electric Door Lock Connection
3. There are two types of door lock configurations: Type 1: Type 2: Feed power to unlock Remove power to unlock 1 2 3 1 2 3 S- NO/NC COM NO/NC POWER POWER SUPPLY SUPPLY 2.7 INSTALLATION 2.7.1 Indoor monitor WAY-FI PLUS KIT... - Page 10 2) Fix the rain hood to the wall with screws. 3) Pull out the cable and connect the system according to the wiring diagram (Chap. 2.4 Wiring diagram) 4) Secure the outdoor panel on the rain hood with the vandal-proof screw. 2.7.3 System power supply WALL WAY-FI PLUS KIT...
-
Page 11: Specifications
2-wire at source / 2-wire electric door lock / 2-wire automatic door / 2-wire exit pushbutton Lighting LED for night vision Operating temperature A-20 ~ +55ºC Weight (g) 375 g (with hood) Dimensions (mm) 94 (W) x 162 (H) x 26 (D) (with rain cover) WAY-FI PLUS KIT... -
Page 12: Main Screen
If you slide the down arrow on the main page, you will have access to the quick actions menu: Call volume regulation Activate / Deactivate Do Not Disturb Enable / Deactivate Wi-Fi Automatic image capture Automatic video capture Deactivate automatic capture WAY-FI PLUS KIT... - Page 13 If timings have been set for the door lock and the gate in the timings menu, the option to select whether to release the main or secondary door will be displayed. main door secondary door WAY-FI PLUS KIT...
- Page 14 8. Number of gallery pages: indicates the number on the left on the page being browsed within the gallery and the number on the right indicates the total number of pages in the gallery. 9. Back button: pressing this returns you to the home screen. WAY-FI PLUS KIT...
-
Page 15: Screens Settings
2.10.1 Installer Setting Advanced options appear to make the relevant changes as well as monitor hardware information. By pressing the tool icon three times (in less than one second), you can access the following options: WAY-FI PLUS KIT... - Page 16 • Door1 info: information such as: Firmware Version, MCU Version, Bus IP, Server IP, Gateway and MAC Address. Additionally, if you have any pending updates, it will be possible to perform an OTA (Over-The-Air) update, which is downloaded automatically with an Internet connection. WAY-FI PLUS KIT...
- Page 17 - Factory Reset: returns the monitor to its initial settings. Selecting this option will prompt the machine to ask whether the change is required; if so, it may then be implemented by pressing the button. 2.10.2 Wi-Fi configuration On the Wi-Fi configuration page, the following options appear: WAY-FI PLUS KIT...
- Page 18 • Other: By pressing this button, a wireless network can be added manually if it is hidden. A window will appear where tapping on any of the Wi-Fi SSID and Password fields will display the keypad to enter the name and credentials of the Wi-Fi to be connected. WAY-FI PLUS KIT...
- Page 19 QR appears. 4. QR code app: scanning the QR code will download the WAY-FI PLUS by FERMAX application. This application is available for Android and iOS.
- Page 20 3. Stream: you can select the quality of the video stream, it can be Main Stream or Sub Stream. Note: If 2 or more monitors are connected, select the Sub Stream mode to obtain a smoother picture. 4. Sound alarm: an alarm sound can be activated or deactivated on the camera when WAY-FI PLUS KIT...
- Page 21 Activated Deactivated Alarm reception: icon indicates that this option is available to receive alarms in the event of motion detection. As with Display, this option will change colour indicating that the Alarm Sound is activated: Deactivated Activated WAY-FI PLUS KIT...
- Page 22 If the camera is connected wirelessly, it is necessary to use the WAY-FI PLUS by FERMAX application to assign it to the monitor; select Apartment settings > Advanced parameters > Add camera to monitor and follow the steps indicated. Once registration is complete, the new camera can be displayed on the monitor screen.
- Page 23 Main monitor. Call divert can only be enabled on the Main monitor. Note: Two monitors cannot share the same address. 3. Additional call sources: this option allows you to activate or deactivate placing of internal calls originating from the panel or from the WAY-FI PLUS by FERMAX mobile app. 2.10.6 Language In the Language configuration page you can set the language of the monitor.
- Page 24 It will then go through the same process of waiting and confirming that the process was successful. 3. Delete all images and videos on SD: performs the same process of deleting images and videos, but in the SD memory. 4. Format: as the name suggests, it formats the SD memory. WAY-FI PLUS KIT...
- Page 25 The chosen timing can be checked by clicking on each icon, which will cause the corresponding device to be activated. In the case of F1 the icon will be shown in green when the output is active. WAY-FI PLUS KIT...
-
Page 26: Initial Configuration
WAY-FI PLUS By FERMAX App. The first time you start the WAY-FI PLUS kit, the monitor will start with a configuration sequence. 1. Once you connect your kit to the power supply, the monitor will start up with the language selection. - Page 27 After setting the configurations, the monitor will restart and you will have access to the connections to pair the mobile phone to the monitor for the call divert functionality through the WAY-FI PLUS by FERMAX application. WAY-FI PLUS KIT...
- Page 28 6-digit code to the assigned email address to validate the registration. The login window will appear. Click on "Sing-up" to create your account for the first time. You must fill in the required fields in order to receive the confirmation email. Then click on the "Sing-up” button. WAY-FI PLUS KIT...
- Page 29 On the mobile phone, enter the code, tick the confirmation box and press the "Next" button. The application will confirm that the registration has been successful. The application will access the main screen and you will be ready to pair the monitor. WAY-FI PLUS KIT...
- Page 30 QR pairing code from the album. It also has the ability to auto-adjust the zoom of the camera to get the pairing QR code. WAY-FI PLUS KIT...
- Page 31 Set a password (numeric values only) with a minimum of 4 digits. ************* ************* I forgot my password: if you cannot log in because you cannot remember your password, you can recover it from this menu. WAY-FI PLUS KIT...
-
Page 32: App Navigation
Door Relay screen The available options found when making a call from the panel or performing Auto-On are displayed. WAY-FI PLUS KIT... - Page 33 F1 button: sends the command to activate an auxiliary device. 02/10/2023 09:17:35 02/10/2023 09:17:35 00:00 Change Camera: if more than camera and/or panel 02/10/2023 09:17:35 02/10/2023 09:17:35 is connected, the selection of these connected cameras will be displayed. WAY-FI PLUS KIT...
-
Page 34: App Navigation
Apartment settings: this is where you can configure and view the following sub- menus: • House name: the name of the monitor can be changed. Press the icon and a pop-up window will appear to modify the name of the monitor. WAY-FI PLUS KIT... - Page 35 These users must be previously registered in the WAY-FI PLUS by FERMAX APP. There is no maximum number of guest users to share the apartment with. During the sharing process, it is possible to authorise permissions for the following...
- Page 36 Note: Only the user who has paired the monitor (the administrator) may share the apartment and manage the respective functionalities vis-à-vis the guests. • Push Settings: You can Enable or Deactivate pop-up notifications for specific functions such as: Calls, Tamper Alert, Open Door, Alarm F1. WAY-FI PLUS KIT...
- Page 37 The current and new passwords must be entered, and the new one confirmed. Once set, the password is confirmed by pressing the 'confirm' button. · Unlock Setting: the different door release modes are displayed. WAY-FI PLUS KIT...
- Page 38 (Panel1, Panel2, CAM) will appear in this section to allow an AutoOn action to be carried out. · Thumbnail: This allows you to change the preview image of the main screen monitor window within the App. WAY-FI PLUS KIT...
- Page 39 Once added, they can be viewed from the app and alarm alerts can be received in the event of motion detection. To add a new camera to the monitor from the app, the first step is to reset the camera by pressing the button for about 5 seconds. WAY-FI PLUS KIT...
- Page 40 4.2.2 Gallery It is possible to view screenshots or recordings that are made through the external panel. It is possible to filter by device, type of capture (image or video) and by date. WAY-FI PLUS KIT...
- Page 41 Release door: this displays information on which monitor and door has been released. F1 button: this shows whether an additional device has been activated or deactivated. Panel call: This indicates that the call has been answered. This indicates that the call has not been answered. WAY-FI PLUS KIT...
- Page 42 When you select the Delete button, a pop-up window will appear to confirm whether you want to delete events via individual selection, or simply delete all events. 4.2.4 Settings In this section you can modify general settings such as: WAY-FI PLUS KIT...
- Page 43 PLUS platform via this option. The deletion process will display a warning, asking if you are sure you want to delete the account. It will also send an email with a validation code to confirm the deletion of the account. WAY-FI PLUS KIT...
-
Page 44: Integration With Google Home And Alexa
By scanning the QR code or accessing the following link, you will find the instructions for the pairing process. https://soporte.fermax.com/portal/en/kb/articles/way-fi-plus-integration-with-digital-assistants Note: See the corresponding links for Alexa and Google Home for more details. Skill: https://www.amazon.com/gp/help/customer/display.html?nodeId=GZNCJ6AMUM25V8RM Google Home: https://support.google.com/googlenest/answer/9159862?hl=en WAY-FI PLUS KIT... - Page 45 RADIO FREQUENCY MODULE EC DECLARATION OF CONFORMITY FERMAX ELECTRÓNICA, S.A.U. declares that this product complies with the requirements of the RED Directive 2014/53/EU on Radio Frequency Equipment. https://www.fermax.com/spain/pro/documentacion/documentacion-tecnica/DT-13-declaraciones-de-conformidad.html Radio frequency module: Frequency: 2.4GHz / Maximum power: 14 ± 0.6 dBm APPENDIX A EXAMPLE OF SUPPLIER'S DECLARATION OF CONFORMITY —...
