EWFS Hand-held
transmitter 1/8 channel
Operating and installation instructions
General information
Fig. 1 EWFS Hand-held transmitter 1-channel
Fig. 2 EWFS Hand-held transmitter 8-channel
The EWFS hand-held transmitter allows wireless operation
of an EWFS-compatible receiver and is available as a
1-channel or 8-channel version.
Intended use
This EWFS Hand-held transmitter is a device developed to
control WAREMA EWFS receivers. Any use other than the
purpose described in these instructions requires approval
from the manufacturer.
Safety instructions
C AUTION
Never activate buttons on your transmitter
arbitrarily unless you have a line of sight to
the sun shading product. Children must not
play with this product – keep remote controls
and transmitters out of the reach of children!
Follow the steps below in the order shown to ensure
problem-free operation:
Please read these instructions carefully
Insert the batteries
Learn the hand-held transmitter into the receivers
Check that the system is functioning correctly
Commissioning
You can find instruction videos on our
YouTube channel at:
http://www.youtube.com/user/SonnenLichtManager/videos
warema_2033389_alhb_en_v3•2022-04-01
Insert the supplied batteries into the battery
compartment as described in the "Maintenance"
section. The device is then ready for operation.
Front operating elements
A B C
Fig. 3 Operating panel of EWFS Hand-held transmitter
1-channel (left),
operating panel of EWFS Hand-held transmitter
8-channel (right)
Pos. Fig. Function of the EWFS Hand-held transmitter 1/8
channel
①
The transmission LED
The EWFS Hand-held transmitter is transmitting.
If the batteries are depleted, this LED flashes when
transmitting a move command. The LED does not
light up when the batteries are fully depleted.
②
UP button
raises the sun shading system
③
STOP button
stops a move command
④
DOWN button
lowers the sun shading system
⑤
Function buttons activate special functions in the
A B C
receiver:
"A" button": Sun control Automatically temporarily
switches on and off
After 12 hours the sun control is re-
activated again automatically!
"B" button": Switches the lighting on and off
"C" button": Saves the comfort position and calls
it up again.
Channel buttons "+" or "-"

-
are used to select the channel.
+
LED display channel 1 to 6
 1
2
displays which channel has been selected (in this
3
case, Channel 2).
4
Select a channel: Pressing the "+" or "-" button
5
6
selects a channel. This is indicated by a channel
LED lighting up.
The channels are changed in succession when the
channel buttons are pressed repeatedly.
We reserve the right to make technical modifications
Valid from
1 April 2022
Keep for future use.
1
2
-
3
4
5
6
7 +
8
A B C
lights up:
