WMS Hand-held transmitter
comfort
Operating and installation instructions
General information
Fig. 1
WMS Hand-held transmitter comfort
The WMS Hand-held transmitter comfort is used for the
remote control of WAREMA WMS receivers. The receivers
send confirmation of the received commands, and
the hand-held transmitter indicates that it received the
confirmation.
The WMS Hand-held transmitter comfort supports 5
different product types. Ten channels are available per
product type and up to 10 receivers can be learned into
each channel.
To operate different products simultaneously and to recall
specifically defined states, up to 10 different scenarios can
be defined. A scenario can be used to operate up to 200
receivers with a single command.
The comfort control functions can be switched on and
off via the WMS Hand-held transmitter comfort. The
parameters of the control functions that are stored in the
receiver can be displayed and changed.
When the WMS Hand-held transmitter comfort operates a
product, it indicates whether this product was previously
operated by an automatic control mode. If a control
function is preventing operation of the product (e.g. a
wind alarm), this is also displayed on the WMS Hand-held
transmitter comfort.
Intended use
The WMS Hand-held transmitter comfort was developed
to control WMS receivers. Any use other than the purpose
described in these instructions requires approval from the
manufacturer.
warema_890374_alhb_en_v6•2022-11-01
Safety instructions
C
AUTION
The hand-held transmitter is for indoor use
only. It is not water-proof. Do not leave the
hand-held transmitter outdoors!
C
AUTION
Never activate buttons on your transmitter
arbitrarily unless you have a line of sight to
the sun shading product. Children must not
play with this product – remote controls or
transmitters must not get into the hands of
children!
Follow the steps below in the order shown to ensure
problem-free operation:
Please read these instructions carefully
Insert the batteries
Learn the hand-held transmitter into the receivers
Check that the system is functioning correctly
Further information and aids such as video
guides and the WMS practical manual can
be found on our support site.
www.warema.com/radio-systems-support
Insert the supplied batteries into the battery
compartment as described in the "Maintenance"
section. The device is then ready for operation.
Commissioning can also be carried out using the
WMS studio pro PC software.
Before WMS receivers can be operated via a hand-
held transmitter, the hand-held transmitter or the
receiver must be included as a device in a radio
network.
We reserve the right to make technical modifications
Valid from
1st November 2022
Keep for future use.
1
