VISSCHER DUKE 11X14 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
I N STRU CT ION
MANUAL
E N G L I S H
D U K E / B A K E R
1 1 X 1 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DUKE 11X14 and is the answer not in the manual?

Questions and answers

Related Manuals for VISSCHER DUKE 11X14

Summary of Contents for VISSCHER DUKE 11X14

  • Page 1 D U K E / B A K E R I N STRU CT ION MANUAL 1 1 X 1 4 E N G L I S H...
  • Page 2 Index IMPORTANT TOOLS HARDWARE COMPONENTS STEP 01 STEP 02 STEP 03 STEP 04...

  • Page 3: Before You Begin

    Assistance Estimated assembly If you require assistence, or need to order replacement time: 8 hours. parts, contact your Visscher Dealer. For additional information call the number below. Please have the serial number ready to ensure quick service. TOLL FREE 1 (877) 795-7423 0400 Duke - Baker 11x14 Instructions V1.1...
  • Page 4 Tools Some tools are required, others are suggested: PE NCI L K N IF E P HI L LI P S SC REW DRI V ER P R OT E CT I VE GLOV E S Required TAP E ME A S URE B U B BL E L E V E L TO OL P O WER D RI LL L A D D E R ( 8 F T / 2.
  • Page 5 Hardware RO B ERTS O N B IT 5- 1 / 8 " X 5 / 1 6 " R SS ( T 30 TOR X ) 3/ 8" H E X H E AD BIT 185X 186X 4" X 5 / 1 6 " R SS ( T 30 TOR X ) 3 / 4 "...
  • Page 6 Components Panels 4026 Long Threshold 4027 Short Threshold 4010 Narrow Post 1880 Foam Gasket 3544 Shear Panel 3506 Full Glass Window Panel 4110 Front Post 80” 4111 Back Post 5125 Side Post 80” 4109 Side Beam 4007 Side Post (Pre-drilled) 4107 Beam MEASUREMENTS ARE APPROXIMATE...
  • Page 7 Components Roofing Structure & Upper Windows 20 15/16” 19 11/16” 1/16” 4114 Back Filler (Mid) 4113 Back Filler (End) 4112 Upright (Pre-drilled) 19 11/16” 20 15/16” 19 11/16” 42 9/16” 4115 Front Filler (Left) 4116 Front Filler (Mid) 4117 Front Filler (Right) 4118 Gusset 4106...
  • Page 8 Components Door Systems 2602 Short Bottom Track 2594 Three-Door Bottom Track 2601 Two-Door Bottom Track 2593 Long Top Track 2600 Short Top Track 2603 Spacer 4006 Strike Post 2604 2605 Handle Pin and Keeper 2570 Two-Door System 2560 Three-Door System The small parts and tools for the Door System can be found in the packaging, located on the upper left corner of the door.
  • Page 9 Components Roofing 2672 Short Side Flashing 1834 Foam Closure 2707 Front Edge Flashing 2671 Long Flashing 2493 Roof Sheet 4191 Tar Paper 2500 Full Ceiling Board 6034 Underside Drip Edge 2507 Starter Ceiling Board 2673 Underside Flashing MEASUREMENTS ARE APPROXIMATE 0400 Duke - Baker 11x14 Instructions V1.1...
  • Page 10 Phases Follow the sequence of phases, as shown: Panels Roofing Roofing Structure & Upper Windows Doors System Roofing Doors System Roofing Structure & Upper Windows Panels 0400 Duke - Baker 11x14 Instructions V1.1...
  • Page 11 Phase A Panels Full Glass Window Shear panel Shear panel Shear panel Panel location can be modified to fit your needs. Each side must have at least one Shear Panel. Door direction can be reversed. See Door Fliping Instructions if you wish to change the orientation of the Doors.
  • Page 12 Step 1 C H A L K L I N E M A R K E R 1) Using Chalk tool (or a Floor Marking Tape), trace the inside edges of all four corners onto the ground at the exact location you wish your gazebo to be placed. These markings will be helpful in placing your corner posts and panels in the steps to come.
  • Page 13 Step 2 1) Remove the protective plastic before assembling the Shear Panels 3544). The film on the panel is meant to reduce any chance of scratches or scuffs. It is not meant to be left on and will be extremely difficult to remove if left in the sun. 3544 Shear Panel 0400 Duke - Baker 11x14 Instructions...

  • Page 14: Inside View

    Step 3 1) Assemble two Back Post Assemblies (DC 4111 5125). Posts are to be flush to the bottom. Pre-drilled pilot holes must be oriented as shown in the diagram. Reserve the Back Post Assemblies for the next steps. 4" X 5/ 1 6" RS S (T3 0 TORX ) Inside view 4111 Back Post...

  • Page 15: Outside View

    Step 4 K NI F E 1) Use Foam Gasket 1880) and adhere to Panel edges 3544) connecting to Back Post Assembly. Make sure the Back Post is facing the outside corner, as shown. knife 1880 Foam Gasket 3544 Shear Panel Outside view 3544 Shear Panel...

  • Page 16: Top View

    Step 5 1) Fasten the Panels 3544) to the Back post Assembly. Wall Panels are to be flush at bottom. 2 1/2" #8 WASHER HEAD (#2 ROBERTSON) Inside view Back Post Assembly Top view 3544 Shear Panel 3544 Shear Panel 1880 Foam Gasket Screws should...
  • Page 17 Step 6 1) Repeat Steps 4 and 5 for the other side of the structure. 2) Arrange two sets of panels 3544) and Back Post Assemblies. 2 1/2" #8 WASHER HEAD (#2 ROBERTSON) 3544 Shear Panel KN I FE knife 1880 Foam Gasket Do not over sink...
  • Page 18 Step 7 1) Use Foam Gasket 1880) and adhere to Panel edges (DC 3506 3544). 2) Fasten the Panels together. Wall Panels are to be flush at top and bottom. If necessary, use Trigger Clamps to assist wall assembly. 2 1/2" #8 WASHER HEAD (#2 ROBERTSON) 3506 Full Glass Window 1880...
  • Page 19 Step 8 1) Use Foam Gasket 1880) and adhere to Panel edges 3544). 2) Fit the Side Post 5125) to Shear Panel edges, then Narrow Post 4010) to Side Post edge. Posts to sit tight to floor. 3) Fasten Posts to Shear Panels, as shown. Do the same for both sides 5 - 1 / 8 "...
  • Page 20 Step 9 1) Assemble two Front Post Assemblies (DC 4110 4007), as shown. All the Posts of the Assembly are to be flush to the bottom. Front Post 4110) has 6 pre-drilled holes that must face each other. The 2 pre-drilled holes side must face the back of the structure.
  • Page 21 Step 10 1) Assemble the Side Beams 4109) to Front Post Assemblies. 2) Fasten the Side Beams through the two pre-drilled holes, as shown. 5 - 1 / 8 " X 5 /1 6 " R S S ( T 3 0 TO R X ) 4109 Side Beam 4109...
  • Page 22 Step 11 1) Carefully place the Side Beam Assemblies on both sides. 2) Fasten the Side Beam Assembly to Back Posts through the two pre-drilled holes, as shown. 5 - 1 / 8 " X 5 /1 6 " R S S ( T 3 0 TO R X ) Flush Side Beam Assembly 0400 Duke - Baker 11x14 Instructions...
  • Page 23 Step 12 1) Use Foam Gasket 1880) and adhere to Panel edges 3544). 2) Fasten the Shear Panel to the stucture from the inside, as shown. 2 1/2" #8 WASHER HEAD (#2 ROBERTSON) 3544 Shear Panel KN I FE knife 1880 Foam Gasket Fastened from...
  • Page 24 Step 13 1) Use Foam Gasket 1880) and adhere to Panel edges 3544). 2) Fit the Side Post 5125) to Shear Panel edge, then Narrow Post 4010) to Side Post edge. Posts to sit tight to floor. 3) Fasten Posts to Shear Panel, as shown. If necessary, use Trigger Clamps 5 - 1 / 8 "...
  • Page 25 Step 14 1) Place the Beam 4107) between Front Posts. 2) Fasten the Beam through the Front Posts Pre-drilled holes in both sides, as shown. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) 4107 Beam 4107...
  • Page 26 Step 15 1) Place the Beam 4107) between Back Posts. 2) Fasten the Beam through the Back Posts Pre-drilled holes in both sides, as shown. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) 4107 Beam 4107...
  • Page 27 Step 16 1) Fasten the Beams to Full Glass Windows and Shear Panels from inside. Use two screws per Panel. 2 1/2" #8 WASHER HEAD (#2 ROBERTSON) Inside view Fastened Use two screws from inside per Panel 0400 Duke - Baker 11x14 Instructions V1.1...
  • Page 28 Step 17 1) Fit the three Threshold Pieces (DC 4026 4027) between Posts and flat on the floor. 2) Fasten Thresholds to the Posts, as shown. 106X 2 3 /4 " # 1 0 R S S (T 2 5 TO R X) 4026 Long Threshold 4027...
  • Page 29 Phase B Roofing Structure & Upper Windows 0400 Duke - Baker 11x14 Instructions V1.1...
  • Page 30 Step 18 1) Place the first Upper Beam 4108) between Posts as shown. 2) Fasten through the pre-drilled holes following the order shown on Detail Views. Use the Torx T30 6” Bit to reach full depth. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) TO RX T 30 BIT 6”...
  • Page 31 Step 19 1) Flip the second Upper Beams 4108) and Place between Posts as shown. Flip horizontaly the second Upper Beam to change the holes positions. 2) Fasten through the pre-drilled holes following the order shown on Detail Views. Use the Torx T30 6” Bit to reach full depth. 5 - 1 / 8 "...

  • Page 32: Side View

    Step 20 1) Fasten the Uprights 4112) to Front Posts in the inside holes. Align the longest face to the Post and the shortest face to backwards. 4112 Upright 4" X 5/ 1 6" RS S (T3 0 TORX ) Side view Align the longest face to the Post and the shortest...
  • Page 33 Step 21 1) Fit Rafters 4106) and fasten to the Front and Back Posts. The Rafter notches must fit to the Posts. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) 4106 Rafter 4106...
  • Page 34 Step 22 1) Fit Gussets 4118) and fasten to Rafters through the pre-drilled holes, as shown. If necessary, use Rubbet Mallet to push the Gussets to the back. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) R U B B E R M A L L E T 4118 Gusset...
  • Page 35 Step 23 1) Fasten Right and Left Sloped Windows (DC 4218 4219) to Beams, Rafters and Gussets, as shown. 1" #8 PAN HEAD 4218 Sloped Window (Right) 4219 Sloped Window (Left) (#2 ROBERTSON) 4218 Sloped Window (Right) Side view 4219 Sloped Window (Left) Inside view Inside view...

  • Page 36: Front View

    Step 24 1) Fit the Back Fillers (DC 4114 4113) and fasten to Upper Beam. The tab side of each Filler must be fit together in the middle of the structure 4113 4114 as shown on Detail View. Use the Torx T30 6” Bit to Back Filler (Mid) Back Filler (End) 4 "...
  • Page 37 Step 25 TORX T30 B IT 6” 1) Fit Left, Mid and Right Front Fillers(DC 4115, DC 4116 4117) and fasten to Upper Beam. The tab side of each Filler must be fit togeth- er in the middle of the structure as shown on Detail View. Use the Torx T30 6”...
  • Page 38 Step 26 1) Fit Rafters 4106) and fasten to Front and Back Fillers. Use the Torx T30 Bit 6” to reach full depth. 5-1 / 8" X 5/1 6" RS S ( T30 TORX) TORX T30 B IT 6” 4106 Rafter 4106 Rafter...
  • Page 39 Phase C Doors System Optional Sliding Screen Doors Enhance your VISSCHER fully enclosed structure with our Sliding Screen Door Kits. Embrace the fresh breeze while keeping the bugs out. Crafted with high-quality insect screens that glide effortlessly along an aluminum track,...
  • Page 40 Step 27 1) Fit strike Post 4006) to Front Right Post Assembly. Strike Post to sit tight to floor. Follow the critical dimension on the dia- gram below before fastening. 2) Use pre-drilled pilot holes to set the locations of the fasteners. 4 "...
  • Page 41 Step 28 1) Align the Strike Plate 2577) so the Strike and Deadbolt both align with the holes. 2) Fasten Strike Plate to the Strike Post. 1 1/2" #8 FLAT HEAD - BL 2577 Strike Plate (#2 ROBERTSON) 2577 Strike Plate 4006 Strike Post Use the 3x Black...
  • Page 42 Step 29 1) Fit the Three-Door Bottom Track 2594) to the Threshold and tight to the Strike Post. 2) Fasten through the pre-drilled holes. 1" #8 PAN HEAD (#2 ROBERTSON) 2594 Three-Door Bottom Track Fit tightly to Strike Post 2594 Three-Door Bottom Track 0400 Duke - Baker 11x14 Instructions V1.1...
  • Page 43 Step 30 1) Fit the Short Bottom Track 2602) to the Threshold and tight to the adjacent track. 2) Push Wall Panel inwards or outwards to ensure track are in-line with each other. 1" #8 PAN HEAD (#2 ROBERTSON) 2602 Short Bottom Track Fit tightly to each other...
  • Page 44 Step 31 1) Place one Spacer 2603) near the Front Left Post and fit tightly to the Bottom Track. The Spacer will help the installation of the Top Track in the right position. 2603 Spacer Tight to bottom track 2603 Spacer 0400 Duke - Baker 11x14 Instructions V1.1...
  • Page 45 Step 32 1) Fit the Long Top Track 2593) to the Front Beam, resting on the Spacer and Strike Post. 2) Align the Top Track to the inside edge of the Front Right Post. 2593 Long Top Track 1 1 /2 " X 1 /4 " RSS (T 25 TO RX) Edge of the Top Track to inside edge of post...
  • Page 46 Step 33 1) To facilitate the installation of the Three-Door System, remove the Short Bottom Track and the End Cap of the Top Track. Remove End Cap Remove Short Bottom Track 0400 Duke - Baker 11x14 Instructions V1.1...
  • Page 47 Step 34 1) Adjust the Pins up of the Three-Door System 2560) and fit the Rollers 2606) to be placed at the same level. 2606 Roller 2560 Three-Door System The Door System is extremely heavy. Use caution when lifting and maneuvering the product.
  • Page 48 Step 35 1) Maneuver the Three-Door System 2560) so the Top Rollers are in-line with the Top Track. 2) Carefully lift the Three-Door System up and move the Top Rollers into the Top Track. 3) Align the Bottom Pins so they enter the channel in the Bottom Track. 2560 Three-Door System Top Rollers...
  • Page 49 Step 36 1) The Top of the Door Panels are to be parallel with the Top Track. 2) The Bottom Pins are to be embedded in the Bottom Track along full distance of Track. 3) If adjustment is required to meet these criteria, remove Door System from Top Track one roller at a time and spin the top Roller in the direction necessary.
  • Page 50 Step 37 1) Re-install the Short Bottom Track and Top Track End Cap. Re-install End Cap Top Track End Cap Re-install Short Bottom Track 2602 Short Bottom Track 0400 Duke - Baker 11x14 Instructions V1.1...

  • Page 51: Inside View

    Step 38 1) Measure 40 inches from the floor to set the Handle 2605) to the metal frame of the Door. Two tabs on the Handle are to fit tightly to inside of metal frame of the Door. 2)Fasten the Handle to the metal frame using two self-drilling screws. 1 "...
  • Page 52 Step 39 P ENCIL 1) To determine the placement of the Keeper, assemble the Handle, pin and Keeper 2604) together. 2) Pull the Handle inwards and tight towards the Narrow Post. 3) Mark the edges of the Keeper on the Narrow Post with a Pencil. 1"...

  • Page 53: Top View

    Step 40 1) Fit the Two-Door Bottom Track 2601) to the threshold, as shown on Top View. 2) Fit the Short Bottom Track 2602) to the threshold, Post and tight to the adjacent track. 3) Push Wall Panel inwards or outwards to ensure track are in-line with each other. 1"...
  • Page 54 Step 41 1) Place two Spacers 2603) and fit tightly to bottom tracks. 2603 Spacer 2603 Spacer Tight to bottom track Tight to bottom track 0400 Duke - Baker 11x14 Instructions V1.1...
  • Page 55 Step 42 1) Fit the Short Top Track 2600) to the Side Beam, resting on both Spacers. 2) Align the Short Top Track to the inside edges of the Front Right Post. 2600 Short Top Track 1 1 /2 " X 1 /4 " RSS (T 25 TO RX) 2600 Short Top Track Rest tightly...
  • Page 56 Step 43 1) To facilitate the installation of the Two-Door System, remove the Short Bottom Track and the End Cap of the Top Track. Remove End Cap Remove Short Bottom Track 0400 Duke - Baker 11x14 Instructions V1.1...
  • Page 57 Step 44 1) Adjust the Pins up of the Passive Two-Door System 2753) and fit the Rollers 2606) to be placed at the same level. 2606 Roller 2753 Two-Door System (Passive) The Door System is extremely heavy. Use caution when lifting and maneuvering the product.
  • Page 58 Step 45 1) Maneuver the Two-Door System 2570) so the Top Rollers are in-line with the Top Track. 2) Carefully lift the Two-Door System up and move the Top Rollers into the Top Track. 3) Align the Bottom Pins so they enter the channel in the Bottom Track. 2570 Two-Door System Top Roller...
  • Page 59 Step 46 1) The Top of the Door Panels are to be parallel with the Top Track. 2) The Bottom Pins are to be embedded in the Bottom Track along full distance of Track. 3) If adjustment is required to meet these criteria, remove Door System from Top Track one roller at a time and spin the Top Roller in the direction necessary.
  • Page 60 Step 47 1) Re-install the Short Bottom Track and Top Track End Cap. Re-install End Cap Top Track End Cap Re-install Short Bottom Track 0400 Duke - Baker 11x14 Instructions V1.1...
  • Page 61 Step 48 1) Measure 40 inches from the floor to set the Handle 2605) to the metal frame of the Door. Two tabs on the Handle are to fit tightly to inside of metal frame of the Door. 2)Fasten the Handle to the metal frame using two self-drilling screws. 1 "...
  • Page 62 Step 49 P E NCIL 1) The Two-Door System will rest un-level. To level, lift upwards on the Handle when locating the placement of the Keeper. 2) Assemble the Handle, Pin and Keeper 2504) together. 1" #8 PAN HEAD 3) Pull the Handle inwards, upwards and tight towards the post. (#2 ROBERTSON) Pencil 2604...
  • Page 63 Step 50 1) Fold the Two-Door System and move in front of the Wall Panel. 2) Place a Keeper 2604) on the Back Post at the same height as the Handle. 1" #8 PAN HEAD (#2 ROBERTSON) 2604 Pin and Keeper 2604 Pin and Keeper 2605...
  • Page 64 Step 51 1) Fit the Two-Door Bottom Track 2601) to the threshold and flush to Front Left Post. 2) Fit the Short Bottom Track 2602) to the threshold and tight to the adjacent track. 3) Push Wall Panel inwards or outwards to ensure track are in-line with each other. 1"...
  • Page 65 Step 52 1) Place two Spacers 2603) and fit tightly to bottom tracks. 2603 Spacer 2603 Spacer Tight to bottom track Tight to bottom track 0400 Duke - Baker 11x14 Instructions V1.1...
  • Page 66 Step 53 1) Fit the Short Top Track 2600) to the Side Beam, resting on both Spacers. 2) Align the Short Top Track to the inside edges of the Front Left Post. 2600 Short Top Track 1 1 /2 " X 1 /4 " RSS (T 25 TO RX) Edge of Top Track to 2600 Short Top Track...
  • Page 67 Step 54 1) To facilitate the installation of the Two-Door System, remove the Short Bottom Track and the End Cap of the Top Track. Remove End Cap Remove Short Bottom Track 0400 Duke - Baker 11x14 Instructions V1.1...
  • Page 68 Step 55 1) Adjust the Pins up of the Passive Two-Door System 2753) and fit the Rollers 2606) to be placed at the same level. 2606 Roller 2753 Two-Door System (Passive) The Door System is extremely heavy. Use caution when lifting and maneuvering the product.
  • Page 69 Step 56 1) Maneuver the Two-Door System 2570) so the Top Rollers are in-line with the Top Track. 2) Carefully lift the Two-Door System up and move the Top Rollers into the Top Track. 3) Align the Bottom Pins so they enter the channel in the Bottom Track. 2570 Two-Door System Top Roller...
  • Page 70 Step 57 1) The Top of the Door Panels are to be parallel with the Top Track. 2) The Bottom Pins are to be embedded in the Bottom Track along full distance of Track. 3) If adjustment is required to meet these criteria, remove Door System from Top Track one roller at a time and spin the Top Roller in the direction necessary.
  • Page 71 Step 58 1) Re-install the Short Bottom Track and Top Track End Cap. Re-install End Cap Re-install Short Bottom Track 0400 Duke - Baker 11x14 Instructions V1.1...
  • Page 72 Step 59 1) Measure 40 inches from the floor to set the Handle 2605) to the metal frame of the Door. Two tabs on the Handle are to fit tightly to inside of metal frame of the Door. 2)Fasten the Handle to the metal frame using two self-drilling screws. 1 "...
  • Page 73 Step 60 P E NCIL 1) The Two-Door System will rest un-level. To level, lift upwards on the Handle when locating the placement of the Keeper. 2) Assemble the Handle, Pin and Keeper 2504) together. 1" #8 PAN HEAD 3) Pull the Handle inwards, upwards and tight towards the post. (#2 ROBERTSON) Pencil 2604...
  • Page 74 Veranda The 11x11 Veranda redefines outdoor living. Elevate your VISSCHER fully enclosed structure by incorporating a cov- ered outdoor space, offering a new dimension of living to your environment. If you wish to purchase optional...
  • Page 75 Phase D Roofing Only put screws at pre-punched locations. When stepping on Roof, step on Screw Line and avoid stepping on Ribs as they can dent and deform. 0400 Duke - Baker 11x14 Instructions V1.1...

  • Page 76: Side View

    Step 61 1) Fit the two Starter Ceiling Boards 2507) on the Rafters and flush to the bottom edges of the Rafters, tongue facing upwards. Ceiling boards to touch at the centre of the middle rafter. 2) Fasten to every two Rafters as shown. Six screws per Starter. Screws at Middle Rafter must 264X enter on an angle.
  • Page 77 Step 62 1) Fit two Ceiling Boards 2500), groove-to-tongue with the Starter Ceiling Boards. Ceiling Boards to touch at the centre of the Middle Rafter. 2) Fasten to every two Rafters as shown. Six screws per Ceiling Board. Screws at Middle Rafter 264X must enter on an angle.
  • Page 78 Step 63 1) Fit the remaining Full Ceiling Boards 2500), fastening each row fully before moving to the next. Ceiling Boards to touch at the centre of the Middle Rafter, tight to each end. 252X 264X 2) Fasten to every two Rafters as shown. Six screws per Ceiling Board. Screws at 2500 Full Ceiling Board 2 1 /2 "...
  • Page 79 Step 64 STA PL E R K NI FE 1) Roll Tar Paper 4191) flat across Ceiling Boards, tight to the bottom most edge of the ceiling. 2) Staple the first row of Tar Paper to the Ceiling Boards using 1/2” staples, spaced a maximum of 12”...
  • Page 80 Step 65 STA PLE R KNI FE 1) Roll four more rows of Tar Paper 4191) flat across Ceiling Boards, overlapping each previous row by 6 inches. 2) Staple to the Ceiling Board using 1/2” staples, spaced a maximum of 12” apart from each other. Fasten each row of Tar Paper before moving on the next row.

  • Page 81: Back View

    Step 66 1) Fit the Underside Drip Edge 6034) on the bottom edge of the Roof Assembly, tight to the end of the Ceiling Board. 2) Review the orientation of Tabs found on the first Roof Sheet 2493) 185X in the Back View. 2493 Roof Sheet 1834...
  • Page 82 Step 67 1) Align the first Roof Sheet, Foam Closure and Underside Flashing to the edges of the Ceiling Board. 2) Fasten through the pre-punched hole locations, and through the 185X Underside Flashing. 2493 Roof Sheet 1834 Foam Closure 2673 Underside Flashing 3 / 4 "...
  • Page 83 Step 68 1) Align the next row of Roof Sheet and Foam Closures to the edges of the Ceiling Board. 2) Fasten through the pre-punched hole locations, and through the underlapped Roof Sheet. 3) Continue Laying Foam Closures and Roof Sheets to complete the last row of Roofing. 185X 2493 Roof Sheet...
  • Page 84 Step 69 1) Fit the Short Side Flashing 2672) so it reaches the bottom edge of the bottom Roof Sheet. Fasten with two screws only at locations shown in diagram (13 inches apart). 2) Fit the Long Side Flashing 2671) over the short portion, and have it reach the top 185X edge of the top Roof Sheet.
  • Page 85 Step 70 1) Fit the Front Edge and Long Flashings (DC 2707 2671) so that it overlaps the Side Flashings. 2) Fasten to the roof metal through every second rib. 185X 2707 Front Edge Flashing 2671 Long Flashing 3 /4 " # 1 4 H EX 2707 Front Edge Flashing Overlap...
  • Page 86 CO M PLE T E You can upgrade your Visscher gazebo by adding optional accessories. 11x11 Veranda 40″ and 80″ extensions If you wish to purchase optional accessories, please contact your Insect Sliding Screen Doors local Visscher dealer. Cedar Panels...
