VISSCHER DUKE 40 EXTENSION 11X14 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
I N STRU CT ION
MANUAL
E N G L I S H
D U K E / B A K E R
1 1 X 1 4
4 0 " E XT E N S I O N

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DUKE 40 EXTENSION 11X14 and is the answer not in the manual?

Questions and answers

Related Manuals for VISSCHER DUKE 40 EXTENSION 11X14

Summary of Contents for VISSCHER DUKE 40 EXTENSION 11X14

  • Page 1 D U K E / B A K E R I N STRU CT ION 4 0 ” E XT E N S I O N MANUAL 1 1 X 1 4 E N G L I S H...
  • Page 2 Index IMPORTANT TOOLS HARDWARE COMPONENTS STEP 01 STEP 02 STEP 03 STEP 04...

  • Page 3: Before You Begin

    Assistance time: 8 hours. If you require assistence, or need to order replacement parts, contact your Visscher Dealer. For additional information call the number below. Please Product may be subject to building code requirements. If you have purchased a 40” Extension Kit, please have the serial number ready to ensure quick service.
  • Page 4 Tools Some tools are required, others are suggested: PE NCI L K N IF E P HI L LI P S SC REW DRI V ER P R OT E CT I VE GLOV E S Required TAP E ME A S URE B U B BL E L E V E L TO OL P O WER D RI LL L A D D E R ( 8 F T / 2.
  • Page 5 Hardware Hardware can be found in 0400 - Baker/Duke and 0440 - 40” Extension packages. RO B ERTS O N B IT 5- 1 / 8 " X 5 / 1 6 " R SS ( T 30 TOR X ) 3/ 8"...
  • Page 6 Components Components can be found in 0400 - Baker/Duke and 0440 - 40” Extension packages. Panels 4026 Long Threshold 4027 Short Threshold 4010 Narrow Post 1880 Foam Gasket 3544 Shear Panel 3506 Full Glass Window Panel 4110 Front Post 80” 80”...
  • Page 7 Components Components can be found in 0400 - Baker/Duke and 0440 - 40” Extension packages. Roofing Structure & Upper Windows 40” 20 15/16” 19 11/16” 1/16” 4114 Back Filler (Mid) 4113 Back Filler (End) 4112 Upright (Pre-drilled) 4127 Back Filler (Extension) 19 11/16”...
  • Page 8 Components Components can be found in 0400 - Baker/Duke packages. Door Systems 2602 Short Bottom Track 2594 Three-Door Bottom Track 2601 Two-Door Bottom Track 2593 Long Top Track 2600 Short Top Track 2603 Spacer 4006 Strike Post 2604 2605 Handle Pin and Keeper 2570 Two-Door System...
  • Page 9 Components Components can be found in 0400 - Baker/Duke and 0440 - 40” Extension packages. Roofing 6035 Drip Edge Support 120” 3282 Drip Edge Support 39 1/2” 2672 Overside Flashing 39 7/8” 2720 Overside Flashing 50” 2707 Overside Flashing 94” 2493 Roof Sheet 3187...
  • Page 10 Phases Follow the sequence of phases, as shown: Panels Roofing Roofing Structure & Upper Windows Doors System Roofing Doors System Roofing Structure & Upper Windows Panels 0440 Duke - Baker 40” Extension Instructions V1.0...
  • Page 11 Phase A Panels Shear panel Full Glass Window Shear panel Panel location can be modified to fit Shear panel Shear panel your needs. Each side must have at least one Shear Panel. Door direction can be reversed. See Door Fliping Instructions if you wish to change the orientation of the Doors.
  • Page 12 Step 1 C H A L K L I N E M A R K E R 1) Using Chalk tool (or a Floor Marking Tape), trace the inside edges of all four corners onto the ground at the exact location you wish your gazebo to be placed. These markings will be helpful in placing your corner posts and panels in the steps to come.
  • Page 13 Step 2 1) Remove the protective plastic before assembling the Shear Panels 3544). The film on the panel is meant to reduce any chance of scratches or scuffs. It is not meant to be left on and will be extremely difficult to remove if left in the sun. 3544 Shear Panel 0440 Duke - Baker 40”...

  • Page 14: Inside View

    Step 3 1) Assemble the right Back Post Assembly (DC 4111 5125). Posts are to be flush to the bottom. Pre-drilled pilot holes must be oriented as shown in the diagram. 4" X 5/ 1 6" RS S (T3 0 TORX ) Inside view 4111 Back Post...

  • Page 15: Outside View

    Step 4 K NI F E 1) Use Foam Gasket 1880) and adhere to Panel edges 3544) connecting to Back Post Assembly. Make sure the Back Post is facing the outside corner, as shown. knife 1880 Foam Gasket 3544 Shear Panel Outside view 3544 Shear Panel...

  • Page 16: Top View

    Step 5 1) Fasten the Panels 3544) to the Back post Assembly. Wall Panels are to be flush at bottom. 2 1/2" #8 WASHER HEAD (#2 ROBERTSON) Inside view Back Post Assembly (Right) Top view 3544 Shear Panel 3544 Shear Panel Screws should be in middle Do not over sink...
  • Page 17 Step 6 1) Assemble the Left Back Post Assembly (DC 4111 5125). Posts are to be flush to the bottom. Pre-drilled pilot holes must be oriented as shown in the diagram. 4" X 5/ 1 6" RS S (T3 0 TORX ) Inside view 4111 Back Post...
  • Page 18 Step 7 1) Repeat Steps 4 and 5 for the left side of the structure. 2) Arrange two sets of panels 3544) and Back Post Assemblies. 2 1/2" #8 WASHER HEAD (#2 ROBERTSON) 3544 Shear Panel KN I FE knife 1880 Foam Gasket Do not over sink...
  • Page 19 Step 8 1) Assemble the Mid Back Post Assembly (DC 4111 5125). Posts are to be flush to the bottom. Pre-drilled pilot holes must be oriented as shown in the diagram. 4" X 5/ 1 6" RS S (T3 0 TORX ) Inside view 4087 Side Post (Pre-drilled)
  • Page 20 Step 9 1) Use Foam Gasket 1880) and adhere to Panel edges (DC 3506 3544). 2) Fasten the Panels together. Wall Panels are to be flush at top and bottom. If necessary, use Trigger Clamps to assist wall assembly. 2 1/2" #8 WASHER HEAD (#2 ROBERTSON) 3506 Full Glass Window 3544...
  • Page 21 Step 10 1) Use Foam Gasket 1880) and adhere to Panel edges 3544). 2) Fit the Side Post 5125) to Shear Panel edges, then Narrow Post 4010) to Side Post edge. Posts to sit tight to floor. 3) Fasten Posts to Shear Panels, as shown. Do the same for both sides 5 - 1 / 8 "...
  • Page 22 Step 11 1) Assemble two Front Post Assemblies (DC 4110 4007), as shown. All the Posts of the Assembly are to be flush to the bottom. Front Post 4110) has 6 pre-drilled holes that must face each other. The 2 pre-drilled holes side must face the back of the structure.
  • Page 23 Step 12 1) Assemble the Side Beams 4109) to Front Post Assemblies. 2) Fasten the Side Beams through the two pre-drilled holes, as shown. 5 - 1 / 8 " X 5 /1 6 " R S S ( T 3 0 TO R X ) 4109 Side Beam 4109...
  • Page 24 Step 13 1) Carefully place the Side Beam Assemblies on both sides. 2) Fasten the Side Beam Assembly to Back Posts through the two pre-drilled holes, as shown. 5 - 1 / 8 " X 5 /1 6 " R S S ( T 3 0 TO R X ) Flush Flush Left Side Beam Assembly...
  • Page 25 Step 14 1) Assemble one Front Post Assembly 4110, DC 4007 4087), as shown. All the Posts of the Assembly are to be flush to the bottom. Front Post 4110) has 6 pre-drilled holes that must face each other. The 2 pre-drilled holes side must face the back of the structure.
  • Page 26 Step 15 1) Use Foam Gasket 1880) and adhere to Panel edges (DC 3544 3506). 2) Fasten the Panels and the Mid Front Post Assembly to the stucture from the inside, as shown. Post Assembly must be placed with the Side Post 4087) orient- ed to the inside and the 6 holes faces oriented to the right and left sides.
  • Page 27 Step 16 1) Use Foam Gasket 1880) and adhere to Panel edges 3544). 2) Fit the Side Post 5125) to Shear Panel edge, then Narrow Post 4010) to Side Post edge. Posts to sit tight to floor. 3) Fasten Posts to Shear Panel, as shown. If necessary, use Trigger Clamps 5 - 1 / 8 "...
  • Page 28 Step 17 1) Place the Beam 4107) and fasten through the Front Posts Pre-drilled holes in both sides, as shown. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) 4107 Beam 4107...
  • Page 29 Step 18 1) Place the Extension Beam 4148) between Front Posts. 2) Fasten the Extension Beam through the Mid Front Posts from the inside, using the Screw V. 3) Fasten the Left Extension Beam through Left Front Post pre- 4148 Extension Beam 4"...
  • Page 30 Step 19 1) Place the Beam 4107) and fasten through the Front Posts Pre-drilled holes in both sides, as shown. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) 4107 Beam 4107...
  • Page 31 Step 20 1) Place the Extension Beams 4148) between Back Posts. 2) Fasten the Extension Beams through the Mid Back Posts from the inside, using the Screw V. 3) Fasten the Left Extension Beam through Left Back Post pre- 4148 Extension Beam 4"...
  • Page 32 Step 21 1) Fasten the Beams to Full Glass Windows and Shear Panels from inside. Use two screws per Panel. 2 1/2" #8 WASHER HEAD (#2 ROBERTSON) Inside view Fastened from inside Use two screws per Panel 0440 Duke - Baker 40” Extension Instructions V1.0...
  • Page 33 Step 22 1) Fit the three Threshold Pieces (DC 4026 4027) between Posts and flat on the floor. 2) Fasten Thresholds to the Posts, as shown. 106X 2 3 /4 " # 1 0 R S S (T 2 5 TO R X) 4026 Long Threshold 4027...
  • Page 34 Phase B Roofing Structure & Upper Windows 0440 Duke - Baker 40” Extension Instructions V1.0...
  • Page 35 Step 23 1) Place the Side Beam 4109) and fasten through the Mid Back Post and Mid Front Post Pre-drilled holes, as shown. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) 4109 Side Beam 4109...
  • Page 36 Step 24 1) Place the first Upper Beam 4108) between Posts as shown. 2) Fasten through the pre-drilled holes following the order shown on Detail Views. Use the Torx T30 6” Bit to reach full depth. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) TO RX T 30 BIT 6”...
  • Page 37 Step 25 1) Place the first Upper Extension Beam 4149) between Posts as shown. 2) Fasten through the pre-drilled holes following the order shown on Detail Views. Use the Torx T30 6” Bit to reach full depth. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) TO RX T 30 BIT 6”...
  • Page 38 Step 26 1) Flip the second Upper Beam 4108) and Place between Posts as shown. Flip horizontaly the second Upper Beam to change the holes positions. 2) Fasten through the pre-drilled holes following the order shown on Detail Views. Use the Torx T30 6” Bit to reach full depth. 5 - 1 / 8 "...
  • Page 39 Step 27 1) Flip the second Upper Extension Beam 4149) and Place between Posts as shown. Flip horizontaly the second Upper Beam to change the holes positions. 2) Fasten through the pre-drilled holes following the order shown on Detail Views. Use the Torx T30 6” Bit to reach full depth. 5 - 1 / 8 "...

  • Page 40: Side View

    Step 28 1) Fasten the Uprights 4112) to Front Posts in the inside holes. Align the longest face to the Post and the shortest face to backwards. 4112 Upright 4" X 5/ 1 6" RS S (T3 0 TORX ) Side view Align the longest face to the Post and the shortest...
  • Page 41 Step 29 1) Fit Rafters 4106) and fasten to the Front and Back Posts. The Rafter notches must fit to the Posts. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) 4106 Rafter 4106...
  • Page 42 Step 30 1) Fit Gussets 4118) and fasten to Rafters through the pre-drilled holes, as shown. If necessary, use Rubber Mallet to push the Gussets to the back. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) R U B B E R M A L L E T 4118 Gusset...
  • Page 43 Step 31 1) Fasten Right and Left Sloped Windows (DC 4218 4219) to Beams, Rafters and Gussets, as shown. 1" #8 PAN HEAD 4218 Sloped Window (Right) 4219 Sloped Window (Left) (#2 ROBERTSON) 4218 Sloped Window (Right) Side view 4219 Sloped Window (Left) Inside view Inside view...

  • Page 44: Front View

    Step 32 1) Fit the Back Fillers 4114, DC 4113 4127) and fasten to Upper Beams. The tab side of each Filler must be fit together in the middle of the 4113 4114 structure as shown on Detail View. Use the Torx T30 Back Filler (Mid) Back Filler (End) 4 "...
  • Page 45 Step 33 TORX T30 B IT 6” 1) Fit Left, Mid, Right and Extension Front Fillers(DC 4115, 4116, 4117 4126)and fasten to Upper Beams. The tab side of each Fill- er must be fit together in the middle of the structure as shown on Detail View.
  • Page 46 Step 34 1) Fit Rafters 4106) and fasten to Front and Back Fillers. Use the Torx T30 Bit 6” to reach full depth. 5-1 / 8" X 5/1 6" RS S ( T30 TORX) TORX T30 B IT 6” 4106 Rafter 4106 Rafter...
  • Page 47 Step 35 1) Fasten the Front Extension Filler 4126) to the Mid Front Post from inside. 4 " X 5/1 6 " RS S (T3 0 TORX) Inside view 4126 Front Filler (Extension) 0440 Duke - Baker 40” Extension Instructions V1.0...
  • Page 48 Phase C Doors System Optional Sliding Screen Doors Enhance your VISSCHER fully enclosed structure with our Sliding Screen Door Kits. Embrace the fresh breeze while keeping the bugs out. Crafted with high-quality insect screens that glide effortlessly along an aluminum track,...

  • Page 49: Top View

    Step 36 1) Fit strike Post 4006) to Front Right Post Assembly. Strike Post to sit tight to floor. Follow the critical dimension on the dia- gram below before fastening. 2) Use pre-drilled pilot holes to set the locations of the fasteners. 4 "...
  • Page 50 Step 37 1) Align the Strike Plate 2577) so the Strike and Deadbolt both align with the holes. 2) Fasten Strike Plate to the Strike Post. 1 1/2" #8 FLAT HEAD - BL 2577 Strike Plate (#2 ROBERTSON) 2577 Strike Plate 4006 Strike Post Use the 3x Black...
  • Page 51 Step 38 1) Fit the Three-Door Bottom Track 2594) to the Threshold and tight to the Strike Post. 2) Fasten through the pre-drilled holes. 1" #8 PAN HEAD (#2 ROBERTSON) 2594 Three-Door Bottom Track Fit tightly to Strike Post 2594 Three-Door Bottom Track 0440 Duke - Baker 40”...
  • Page 52 Step 39 1) Fit the Short Bottom Track 2602) to the Threshold and tight to the adjacent track. 2) Push Wall Panel inwards or outwards to ensure track are in-line with each other. 1" #8 PAN HEAD (#2 ROBERTSON) 2602 Short Bottom Track Fit tightly to each other...
  • Page 53 Step 40 1) Place one Spacer 2603) near the Front Left Post and fit tightly to the Bottom Track. The Spacer will help the installation of the Top Track in the right position. 2603 Spacer Tight to bottom track 2603 Spacer 0440 Duke - Baker 40”...
  • Page 54 Step 41 1) Fit the Long Top Track 2593) to the Front Beam, resting on the Spacer and Strike Post. 2) Align the Top Track to the inside edge of the Front Right Post. 2593 Long Top Track 1 1 /2 " X 1 /4 " RSS (T 25 TO RX) 2593 Long Top Track Edge of the Top...
  • Page 55 Step 42 1) To facilitate the installation of the Three-Door System, remove the Short Bottom Track and the End Cap of the Top Track. Remove End Cap Remove Short Bottom Track 0440 Duke - Baker 40” Extension Instructions V1.0...
  • Page 56 Step 43 1) Adjust the Pins up of the Three-Door System 2560) and fit the Rollers 2606) to be placed at the same level. 2606 Roller 2560 Three-Door System The Door System is extremely heavy. Use caution when lifting and maneuvering the product.
  • Page 57 Step 44 1) Maneuver the Three-Door System 2560) so the Top Rollers are in-line with the Top Track. 2) Carefully lift the Three-Door System up and move the Top Rollers into the Top Track. 3) Align the Bottom Pins so they enter the channel in the Bottom Track. 2560 Three-Door System Top Rollers...
  • Page 58 Step 45 1) The Top of the Door Panels are to be parallel with the Top Track. 2) The Bottom Pins are to be embedded in the Bottom Track along full distance of Track. 3) If adjustment is required to meet these criteria, remove Door System from Top Track one roller at a time and spin the top Roller in the direction necessary.
  • Page 59 Step 46 1) Re-install the Short Bottom Track and Top Track End Cap. Re-install End Cap Top Track End Cap Re-install Short Bottom Track 0440 Duke - Baker 40” Extension Instructions V1.0...

  • Page 60: Inside View

    Step 47 1) Measure 40 inches from the floor to set the Handle 2605) to the metal frame of the Door. Two tabs on the Handle are to fit tightly to inside of metal frame of the Door. 2)Fasten the Handle to the metal frame using two self-drilling screws. 1 "...
  • Page 61 Step 48 P ENCIL 1) To determine the placement of the Keeper, assemble the Handle, pin and Keeper 2604) together. 2) Pull the Handle inwards and tight towards the Narrow Post. 3) Mark the edges of the Keeper on the Narrow Post with a Pencil. 1"...

  • Page 62: Top View

    Step 49 1) Fit the Two-Door Bottom Track 2601) to the threshold, as shown on Top View. 2) Fit the Short Bottom Track 2602) to the threshold, Post and tight to the adjacent track. 3) Push Wall Panel inwards or outwards to ensure track are in-line with each other. 1"...
  • Page 63 Step 50 1) Place two Spacers 2603) and fit tightly to bottom tracks. 2603 Spacer 2603 Spacer Tight to bottom track Tight to bottom track 0440 Duke - Baker 40” Extension Instructions V1.0...
  • Page 64 Step 51 1) Fit the Short Top Track 2600) to the Side Beam, resting on both Spacers. 2) Align the Short Top Track to the inside edges of the Front Right Post. 2600 Short Top Track 1 1 /2 " X 1 /4 " RSS (T 25 TO RX) Rest tightly on Spacer 2600...
  • Page 65 Step 52 1) To facilitate the installation of the Two-Door System, remove the Short Bottom Track and the End Cap of the Top Track. Remove End Cap Remove Short Bottom Track 0440 Duke - Baker 40” Extension Instructions V1.0...
  • Page 66 Step 53 1) Adjust the Pins up of the Passive Two-Door System 2753) and fit the Rollers 2606) to be placed at the same level. 2606 Roller 2753 Two-Door System (Passive) The Door System is extremely heavy. Use caution when lifting and maneuvering the product.
  • Page 67 Step 54 1) Maneuver the Two-Door System 2570) so the Top Rollers are in-line with the Top Track. 2) Carefully lift the Two-Door System up and move the Top Rollers into the Top Track. 3) Align the Bottom Pins so they enter the channel in the Bottom Track. 2570 Two-Door System Top Roller...
  • Page 68 Step 55 1) The Top of the Door Panels are to be parallel with the Top Track. 2) The Bottom Pins are to be embedded in the Bottom Track along full distance of Track. 3) If adjustment is required to meet these criteria, remove Door System from Top Track one roller at a time and spin the Top Roller in the direction necessary.
  • Page 69 Step 56 1) Re-install the Short Bottom Track and Top Track End Cap. Re-install End Cap Top Track End Cap Re-install Short Bottom Track 0440 Duke - Baker 40” Extension Instructions V1.0...
  • Page 70 Step 57 1) Measure 40 inches from the floor to set the Handle 2605) to the metal frame of the Door. Two tabs on the Handle are to fit tightly to inside of metal frame of the Door. 2)Fasten the Handle to the metal frame using two self-drilling screws. 1 "...
  • Page 71 Step 58 P E NCIL 1) The Two-Door System will rest un-level. To level, lift upwards on the Handle when locating the placement of the Keeper. 2) Assemble the Handle, Pin and Keeper 2504) together. 1" #8 PAN HEAD 3) Pull the Handle inwards, upwards and tight towards the post. (#2 ROBERTSON) Pencil 2604...
  • Page 72 Step 59 1) Fold the Two-Door System and move in front of the Wall Panel. 2) Fasten a Keeper 2604) on the Back Post at the same height as the Handle. 1" #8 PAN HEAD (#2 ROBERTSON) 2604 Pin and Keeper 2604 Pin and Keeper 2605...
  • Page 73 Step 60 1) Fit the Two-Door Bottom Track 2601) to the threshold and flush to Front Left Post. 2) Fit the Short Bottom Track 2602) to the threshold and tight to the adjacent track. 3) Push Wall Panel inwards or outwards to ensure track are in-line with each other. 1"...
  • Page 74 Step 61 1) Place two Spacers 2603) and fit tightly to bottom tracks. 2603 Spacer 2603 Spacer Tight to bottom track Tight to bottom track 0440 Duke - Baker 40” Extension Instructions V1.0...
  • Page 75 Step 62 1) Fit the Short Top Track 2600) to the Side Beam, resting on both Spacers. 2) Align the Short Top Track to the inside edges of the Front Left Post. 2600 Short Top Track 1 1 /2 " X 1 /4 " RSS (T 25 TO RX) Edge of Top Track to 2600 Short Top Track...
  • Page 76 Step 63 1) To facilitate the installation of the Two-Door System, remove the Short Bottom Track and the End Cap of the Top Track. Remove End Cap Remove Short Bottom Track 0440 Duke - Baker 40” Extension Instructions V1.0...
  • Page 77 Step 64 1) Adjust the Pins up of the Passive Two-Door System 2753) and fit the Rollers 2606) to be placed at the same level. 2606 Roller 2753 Two-Door System (Passive) The Door System is extremely heavy. Use caution when lifting and maneuvering the product.
  • Page 78 Step 65 1) Maneuver the Two-Door System 2570) so the Top Rollers are in-line with the Top Track. 2) Carefully lift the Two-Door System up and move the Top Rollers into the Top Track. 3) Align the Bottom Pins so they enter the channel in the Bottom Track. 2570 Two-Door System Top Roller...
  • Page 79 Step 66 1) The Top of the Door Panels are to be parallel with the Top Track. 2) The Bottom Pins are to be embedded in the Bottom Track along full distance of Track. 3) If adjustment is required to meet these criteria, remove Door System from Top Track one roller at a time and spin the Top Roller in the direction necessary.
  • Page 80 Step 67 1) Re-install the Short Bottom Track and Top Track End Cap. Re-install End Cap Re-install Short Bottom Track 0440 Duke - Baker 40” Extension Instructions V1.0...
  • Page 81 Step 68 1) Measure 40 inches from the floor to set the Handle 2605) to the metal frame of the Door. Two tabs on the Handle are to fit tightly to inside of metal frame of the Door. 2)Fasten the Handle to the metal frame using two self-drilling screws. 1 "...
  • Page 82 Step 69 P E NCIL 1) The Two-Door System will rest un-level. To level, lift upwards on the Handle when locating the placement of the Keeper. 2) Assemble the Handle, Pin and Keeper 2504) together. 1" #8 PAN HEAD 3) Pull the Handle inwards, upwards and tight towards the post. (#2 ROBERTSON) Pencil 2604...
  • Page 83 Veranda The 11x11 Veranda redefines outdoor living. Elevate your VISSCHER fully enclosed structure by incorporating a cov- ered outdoor space, offering a new dimension of living to your environment. If you wish to purchase optional...
  • Page 84 Phase D Roofing Only put screws at pre-punched locations. When stepping on Roof, step on Screw Line and avoid stepping on Ribs as they can dent and deform. 0440 Duke - Baker 40” Extension Instructions V1.0...
  • Page 85 Step 70 C IRC ULAR SAW 1) In order to not interfere with the Extension the Starter and the Ceiling Boards must be cut down to 84”. Use a Circular Saw to cut down the Starter and Ceiling Boards. 2507 Starter 91 3/8”...

  • Page 86: Back View

    Step 71 1) Fit the Starters (DC 2507 2512) on the Rafters and fush to the bottom edges of the Rafters, tongue facing upwards. Starters to touch at the centre of the Rafters. 264X 2) Fasten to each two Rafters as shown. Screws must enter on 2507 Starter 91 3/8”...
  • Page 87 Step 72 1) Fit the Ceiling Boards (DC 2500 2511) on the Rafters and fush to the bottom edges of the Rafters, tongue facing upwards. Ceiling boards to touch at the centre of the Rafters. 264X 2) Fasten to each two Rafters as shown. Screws must enter on 2500 Ceiling Board 91 3/8”...
  • Page 88 Step 73 1) Fit the Ceiling Boards (DC 2500 2511) on the Rafters and fush to the bottom edges of the Rafters, tongue facing upwards. Ceiling boards to touch at the centre of the Rafters. 336X 264X 264X 2) Fasten to each two Rafters as shown. Screws must enter on 2500 Ceiling Board 91 3/8”...
  • Page 89 Step 74 STA PL E R K NI FE 1) Roll Tar Paper 4191) flat across Ceiling Boards, tight to the bottom most edge of the ceiling. 2) Staple the first row of Tar Paper to the Ceiling Boards using 1/2” staples, spaced a maximum of 12”...
  • Page 90 Step 75 STA PLE R KNI FE 1) Roll four more rows of Tar Paper 4191) flat across Ceiling Boards, overlapping each previous row by 6 inches. 2) Staple to the Ceiling Board using 1/2” staples, spaced a maximum of 12” apart from each other. Fasten each row of Tar Paper before moving on the next row.
  • Page 91 Step 76 1) Fit the Underside Flashing 120” 6034) on the bottom edge of the Roof Assembly, tight to the end of the Ceiling Board. 2) Review the orientation of Tabs found on the first Roof Sheet 2493) 185X in the Back View. 2493 Roof Sheet 1834...
  • Page 92 Step 77 1) Align the first row of Roof Sheets (DC 2493 3187), Foam Closures 1834) and Underside Flashings (DC 2673 2721) to the edges of the Ceiling Board. 185X 2) Fasten through the pre-punched hole locations, and through the Underside 2673 Underside Flashing 94”...

  • Page 93: Front View

    Step 78 1) Align the next row of Roof Sheet and Foam Closures to the edges of the Ceiling Board. 2) Fasten through the pre-punched hole locations, and through the underlapped Roof Sheet. 3) Continue Laying Foam Closures and Roof Sheets to complete the last row of Roofing. Do 185X not fasten the last row holes as shown on the Detail View.
  • Page 94 Step 79 1) Place the Drip Edge Supports (DC 3282 6035) in the order as shown. Overlap the Drip Edge Supports and flush to the corners. 2) Fasten through the pre-punched hole locations, and through the underlapped 185X Roof Sheet. 3282 Drip Edge Support 39 1/2”...
  • Page 95 Step 80 1) Fit the Overside Flashing 39 7/8” 2672) so it reaches the bottom edge of the bottom Roof Sheet. Fasten with two screws only at locations shown in diagram (13 inches apart). 2) Fit the Overside Flashing 120” 2671) over the short portion, and have it reach the 185X top edge of the top Roof Sheet.
  • Page 96 Step 81 1) Fit the Overside Flashing 120” 2671), the Overside Flashing 94” 2707) and the Overside Flashing 50” 2720) so that it overlaps the Side Flashings. 2720 Overside Flashing 2707 Overside Flashing 2671 Overside Flashing 185X 2) Fasten to the roof metal through every second rib. Make sure 3 /4 "...
  • Page 97 CO M PLE T E You can upgrade your Visscher gazebo by adding optional accessories. 11x11 Veranda 40″ and 80″ extensions If you wish to purchase optional accessories, please contact your Insect Sliding Screen Doors local Visscher dealer. Cedar Panels...
