I N STRU CT ION

MANUAL

E N G L I S H

C Y P R E S S / B É L I N D A

1 1 X 1 1

Table of Contents

Need help?

Do you have a question about the CYPRESS 11X11 and is the answer not in the manual?

Questions and answers

Summary of Contents for VISSCHER CYPRESS 11X11

Page 1 C Y P R E S S / B É L I N D A I N STRU CT ION MANUAL 1 1 X 1 1 E N G L I S H...
Page 2 Index IMPORTANT TOOLS HARDWARE COMPONENTS STEP 01 STEP 02 STEP 03 STEP 04...
Page 3: Before You Begin
Assistance Estimated assembly If you require assistence, or need to order replacement time: 8 hours. parts, contact your Visscher Dealer. For additional information call the number below. Please have the serial number ready to ensure quick service. TOLL FREE 1 (877) 795-7423 0513 Cypress - Bélinda 11x11 Instructions...
Page 4 Tools Some tools are required, others are suggested: PE NCI L K N IF E P HI L LI P S SC REW DRI V ER P R OT E CT I VE GLOV E S Required TAP E ME A S URE B U B BL E L E V E L TO OL P O WER D RI LL L A D D E R ( 8 F T / 2.
Page 5 Hardware RO B ERTS O N B IT 185X 3 / 4 " # 1 4 H EX 4" X 5/ 16 " RSS ( T3 0 TORX ) 1 / 4" H EX HE AD BIT 234X 128X 1 " # 9 H E X H EA D 3 1/8 "...
Page 6 Components Panels 80” 4033 Split Truss Frame Member 5125 Post 77 7/16” 4031 Split Truss Frame Sub-Assembly 4086 Post (Pre-drilled) 3544 Shear Panel 3505 Bifold Window 4087 Header (Pre-drilled) Panel 1880 Foam Gasket 4088 Threshold 3506 Full Glass 7098 Screen Window Panel (with Bifold Window) MEASUREMENTS ARE APPROXIMATE...
Page 7 Components Roofing Parts 4036 Common Rafter 7209 Peak Cap 4 9/32” 4035 Hip Rafter 7063 Roof Installation Tool 4097 Ridge Beam Bracket 4037 Lower Roof Strapping 4044 Panel Support Left 2193 Hip Cover 4125 Peak Support Block 4045 Panel Support Right 14 5/8”...
Page 8 Components Roofing 68” 68” 36 1/2” 36 1/2” 7029 Roof Sheet 7030 Roof Sheet 7031 Roof Sheet 7032 Roof Sheet (Outside left) (Inside left) (Inside right) (Outside right) 2033 Sealing Tape 2823 Bottom Foam Closure 4104 Metal Corner Cover 2822 Top Foam Closure MEASUREMENTS ARE APPROXIMATE 0513 Cypress - Bélinda 11x11 Instructions...
Page 9 Components Door System The small parts and tools for the Door System can be found in the packaging, located on the upper left corner of the door 2569 3 Keys Set 8151 8150 7048 Wrench 5” Wrench 3” Top Right Track (Roller Bolt nut) (Roller Bolt shank) 8149...
Page 10 Phases Follow the sequence of phases, as shown: Panels Roofing Roofing Structure Roofing Door System Roofing Structure Door System Panels 0513 Cypress - Bélinda 11x11 Instructions V1.1...
Page 11 Phase A Panels Shear panel Full Glass Window Bifold Window Panel location can be modified to fit your needs. Each side must have at least one Shear Panel. Door cannot pass over Bifold Window Panels. Door direction can be reversed. CAUTION: Do not over sink Panel Screws.
Page 12 Step 1 1) Attach together Truss Frame pieces (DC 4031 4033). The components should be fit as tightly together as possible. 2) Repeat this build for a total of four 11’ Truss Frame assemblies. 4031 Split Truss Frame 264X Sub-Assembly 2 1 /2 "...
Page 13 Step 2 1) Attach together Truss Frame assemblies as shown in diagram. The components should be fit as tightly together as possible. 2) Fasten all four corners in the same fashion. 264X 2 1 /2 " #8 FL AT H E AD ( #2 RO BERTSON ) 11’...
Page 14 Step 3 C H A L K L I N E M A R K E R 1) Lay the squared Truss Frame Assembly at the exact location you wish your gazebo to be. 2) Using Chalk tool (or a Floor Marking Tape), trace the inside edges of all four corners onto the ground. 3) Once markings are complete, move the Truss Frame Assembly up and out of the way.
Page 15 Step 4 1) Remove the protective plastic before assembling the Shear Panels 3544). The film on the panel is meant to reduce any chance of scratches or scuffs. It is not meant to be left on and will be extremely difficult to remove if left in the sun. 3544 Shear Panel 0513 Cypress - Bélinda 11x11 Instructions...
Page 16 Bay Kit at this time. Bay kit The Bay Kit is the ultimate add-on to a VISSCHER fully enclosed structure. Not only does it instantly add square footage to the interior, but the bay also adds a stylish look that will set your enclosure apart from the neighbourhood.
Page 17: Outside View
Step 5 KNIF E 1) Use Foam Gasket 1880) and adhere to Panel edges 3544) connecting to Post 5125). knife 1880 Foam Gasket 3544 Shear Panel 5125 Post 3544 Shear Panel 5125 Post Outside view 1880 Foam Gasket 0513 Cypress - Bélinda 11x11 Instructions V1.1...
Page 18: Top View
Step 6 1) Fasten the Panels 3544) to the Post 5125). Wall Panels are to be flush with the inside edge of the post and flush at top and bottom. 2 1/2" #8 WASHER HEAD (#2 ROBERTSON) 5125 Post 3544 Shear Panel 3544 Shear Panel...
Page 19 Step 7 1) Use Foam Gasket 1880) and adhere to Panel edges (DC 3506 3544) connecting to Post 5125). 2) Fasten the Panels (DC 3506 3544) to the Post 5125). Wall Panels are to be flush with the inside edge of the post and flush at top 2 1/2"...
Page 20 Step 8 1) Use Foam Gasket 1880) and adhere to Panel edges (DC 3544 3506). 2) Fasten the Panels together. Wall Panels are to be flush at top and bottom. If necessary, use Trigger Clamps to assist wall assembly. 2 1/2" #8 WASHER HEAD (#2 ROBERTSON) 1880 Foam Gasket 3506...
Page 21 Step 9 1) Use Foam Gasket 1880) and adhere to Shear Panel edges 3544). 2) Fasten the Windows Panels (DC 3506 3505) together. Wall Panels are to be flush at top and bottom. If necessary, use Trigger Clamps to assist wall assembly.
Page 22: Inside View
Step 10 1) Use Foam Gasket 1880) and adhere to Panel edges (DC 3505 3544). 2) Fasten the Panels together. Wall Panels are to be flush at top and bottom. 2 1/2" #8 WASHER HEAD (#2 ROBERTSON) 1880 Foam Gasket Outside view Inside view 5125...
Page 23 Step 11 1) Use Foam Gasket 1880) and adhere to Panel edges (DC 3505 3506). 2) Fasten the Window Panel, Post and Panels Assembly together. Wall Panels are to be flush at top and bottom. If necessary, use Trigger Clamps to assist wall assembly. 5125 Post 2 1/2"...
Page 24 Step 12 1) Use Foam Gasket 1880) and adhere to Panel edges 3544). 2) Fit the two Posts 4086) in the position shown on diagram. 3) Fasten the Posts to the Panels in the pre-drilled holes. 3 1 /8 " X 5 /1 6 " RS S (T3 0 TORX ) 1880 Foam Gasket 4086...
Page 25 Step 13 1) Fasten the Header 4087) to Posts, as shown. 4" X 5/ 16 " RSS ( T3 0 TORX ) 4087 Header (Pre-drilled) 4087 Header (Pre-drilled) The side that contains 5 pre-drilled holes must be facing down 0513 Cypress - Bélinda 11x11 Instructions V1.1...
Page 26 Step 14 1) Fit the Threshold 4088) in the position shown on diagram. 2) Fasten the Threshold to the Posts in the pre-drilled holes. 106X 2 3 /4 " #1 0 RS S (T2 5 TORX ) 4088 Threshold 4088 Threshold 0513 Cypress - Bélinda 11x11 Instructions V1.1...
Page 27 Step 15 1) Carefully place the Truss Frame Assembly on top of the structure. 2) Fasten the Truss Frame Assembly through Header pre-drilled holes. 4" X 5/ 16 " RSS ( T3 0 TORX ) 0513 Cypress - Bélinda 11x11 Instructions V1.1...
Page 28 Step 16 1) Fasten the Truss Frame Assembly to the structure from inside. Use two screws per Panel. 2 1/2" #8 WASHER HEAD (#2 ROBERTSON) Inside view Fastened from inside Use two screws per Panel 0513 Cypress - Bélinda 11x11 Instructions V1.1...
Page 29 Step 17 1) Fasten the Truss Frame Assembly to the Posts 5125) in the pre-drilled holes. 4" X 5/ 16 " RSS ( T3 0 TORX ) Truss Frame Assembly 5125 Post 0513 Cypress - Bélinda 11x11 Instructions V1.1...
Page 30 Phase B Roofing structure 0513 Cypress - Bélinda 11x11 Instructions V1.1...
Page 31 Step 18 1) Fasten the Brackets 4097) to the Peak Support Block 4125) to build one Peak Support Block Assembly. The side that contains the Gazebo Serial Number must be facing down. 106X 4097 Ridge Beam Bracket 2 3 /4 " #1 0 RS S (T2 5 TORX) 4125 Peak Support Block 4097...
Page 32: Side View
Step 19 1) Attach Common Rafters 4036) to the Ridge Beam Assembly as shown in diagram. 106X 4036 Common Rafter 2 3 /4 " #1 0 RS S (T2 5 TORX) Side view 4036 Common Rafter Top view 0513 Cypress - Bélinda 11x11 Instructions V1.1...
Page 33 Step 20 1) Flip the Rafter Assembly over and place on Truss Frame. 2) Square the Rafters to the Truss Frame. Do not fasten rafters to Truss Frame at this time. Do not fasten at this time. Rafter Assembly Square the Rafters to the Truss Frame 90°...
Page 34 Step 21 1) Attach the Hip Rafters 4035) to the Rafter Assembly. 2) Fasten the Hip Rafters in the locations shown on diagram. Do not fasten Rafters to the Truss Frame at this time. 106X 2 3 /4 " #1 0 RS S (T2 5 TORX) 4035 Hip Rafter 4035...
Page 35 Step 22 1) Fit the Panel Supports (DC 4044 4045) between Rafters as shown in the diagram. 2) Fasten the Panel Supports to the Truss Frame. Use four screws for each Panel Support. 264X 4044 Panel Support Left 2 1 / 2 " # 8 F L AT H E A D ( # 2 R O B ERTS O N ) 4045 Panel Support Right Top view...
Page 36 Step 23 1) Fasten the Common and Hip Rafters to the Truss Frame. 106X 2 3 /4 " #1 0 RS S (T2 5 TORX) 0513 Cypress - Bélinda 11x11 Instructions V1.1...
Page 37 Step 24 1) Place and fasten the Upper Roof Strappings 4042) to the Rafters. Complete the upper layer. 264X 2 1 / 2 " # 8 F L AT H E A D ( # 2 R O B ERTS O N ) 4042 Upper Roof Strapping 4042...
Page 38 Step 25 1) Place and fasten the Mid Roof Strappings 4040) to the Rafters. Complete the mid layer. 264X Do not stand on the Truss Frame or Rafter Assembly 4040 Mid Roof Strapping 2 1 / 2 " # 8 F L AT H E A D ( # 2 R O B ERTS O N ) 4040 Mid Roof Strapping Top view...
Page 39 Step 26 1) Place and fasten the Lower Roof Strappings 4037) to the Rafters. Complete the lower layer. 264X 4037 Lower Roof Strapping 2 1 / 2 " # 8 F L AT H E A D ( # 2 R O B ERTS O N ) Do not stand on the Truss Frame or Rafter Assembly 4037 Lower Roof Strapping...
Page 40 Step 27 1) Attach the Metal Corner Cover 4104) at the positions shown on diagram. 2) Fasten the screws in the pre-drilled holes to the Hip Rafters. Do the same for the four corners of the structure. 1 1 /2 " # 8 F L AT H E A D 4104 Metal Corner Cover ( # 2 R O B ERTS O N )
Page 41 Step 28 1) Align the Hip Covers 2193) so it is centred on the Rafter and the bottom just touches the outside of the Panel Support, as shown. 2) Fasten the Hip Covers to the Strappings and Panel Supports. 1 1 /2 " # 8 F L AT H E A D 2193 Hip Cover ( # 2 R O B ERTS O N )
Page 42 Bay Kit at this time. Bay kit The Bay Kit is the ultimate add-on to a VISSCHER fully enclosed structure. Not only does it instantly add square footage to the interior, but the bay also adds a stylish look that will set your enclosure apart from the neighbourhood.
Page 43 Phase C Roofing Only put screws at pre-punched locations. When stepping on Roof, step on Screw Line and avoid stepping on Ribs as they can dent and deform. 0513 Cypress - Bélinda 11x11 Instructions V1.1...
Page 44: Bottom View
Step 29 KN IF E 1) Attach the Bottom Foam Closure 2823) in all 11’ and 14’ Roof Sheets. The Foam Closure should be placed in the back side of the Roof Sheet, over the bottom row of holes. 2) Use the knife to cut the overlaping parts of the Foam Closure, if necessary. knife 11’...
Page 45 Step 30 1) Attach the Roof Installation Tools 7063) at the positions shown. 7063 Roof Installation Tool 7063 Roof Installation Tool Top view 0513 Cypress - Bélinda 11x11 Instructions V1.1...
Page 46: Front View
Step 31 1) Place Roof Sheets (DC 7030 7031) using the Roof Installation Tools as base and evenly across Hip Rafters. Overlap one rib as shown. 2) Align top of sheet to the edge of the top strap. Sheets must not exceed past one-half the width 7030 Roof Sheet 7031...
Page 47: Detail View
Step 32 1) Lift the bottom of the Roof Sheets to remove the Roof Installation Tools, as shown on Side views. Side view 2) Fasten the remaining screws of the Roof Sheets, with exception of 234X one as shown on Detail view. 1 "...
Page 48 Step 33 1) Place Roof Sheet (Outside left) 7029) on the Roof strapping, overlap one rib as shown. 2) Place Roof Sheet (Outside right) 7032) on the Roof strapping, underlap one rib as shown. 3) Align Bottom of Sheets to previously installed Sheets. 7032 Roof Sheet 7029...
Page 49 Step 34 Repeat Steps 30, 31, for the remaining three sides of the Roof. Only put screws at pre-punched locations. When stepping on Roof, step on Screw Line and avoid stepping on Ribs as they can dent and deform. Resting evenly on Hip Rafters 0513 Cypress - Bélinda 11x11 Instructions V1.1...
Page 50 Step 35 KN I FE 1) Attach the top Foam Closure 2822) in all sides. Use knife to cut exceeding parts. knife 2822 Top Foam Closure 2822 Top Foam Closure 0513 Cypress - Bélinda 11x11 Instructions V1.1...
Page 51 Step 36 K NI FE 1) Carefully peel the backer and place the Sealing tape 2033) over top of the joint between the Roofing sheets. 2) Apply pressure to adhere the Tape to the contour of the Roofing sheets. 3) Once adhered fully, trim at edge of the Roofing sheet as shown. 4) Repeat this on all four sides.
Page 52 Step 37 1) Align the Hip Caps 7220) in the bottom and top so it is centered on the Hip joint. 2) Fasten through the Hip Caps into the Top Ribs of the Roofing sheets only, as shown on Top View. 3) Repeat the process for all four sides.
Page 53 Step 38 1) Place the Peak Cap 7209) at the very top of the Roof over top of the ends of the Hip flashing, as shown. 2) Make sure the Cap is pressed down tight and flat to the Roofing. 3) Secure the Peak Cap with screws on each side through the Cap and into the Roofing.
Page 54 Bay Kit at this time. Bay kit The Bay Kit is the ultimate add-on to a VISSCHER fully enclosed structure. Not only does it instantly add square footage to the interior, but the bay also adds a stylish look that will set your enclosure apart from the neighbourhood.
Page 55 Phase D Door System Optional Sliding Screen Doors Enhance your VISSCHER fully enclosed structure with our Sliding Screen Door Kits. Embrace the fresh breeze while keeping the bugs out. Crafted with high-quality insect screens that glide effortlessly along an aluminum track,...
Page 56 Step 39 1) Fit Strike Post 4006) to Front Left Post. Strike Post to sit tight to floor. Follow the critical dimension on the diagram below before fastening. 2) Use Front Left Post pre-drilled pilot holes to set the locations 4 "...
Page 57 Step 40 1) Align the Strike Plate 2577) so the Strike and Deadbolt both align with the holes. 2) Fasten Strike Plate to the Strike Post. 1 1/2" #8 FLAT HEAD - BL 2577 Strike Plate (#2 ROBERTSON) 2577 Strike Plate Use the 3x Black Screw A provided 0513 Cypress - Bélinda 11x11 Instructions...
Page 58 Step 41 1) Fit the Short Bottom Track 2602) to the Threshold and flush to the Strike Post. 2) Fasten through the pre-drilled holes. 1" #8 PAN HEAD (#2 ROBERTSON) 2602 Short Bottom Track Flush 2602 Short Bottom Track 0513 Cypress - Bélinda 11x11 Instructions V1.1...
Page 59 Step 42 1) Fit the Top Left Track 7047) to the Truss Frame and Strike Post. 2) Fasten the Top Left Track in the pre-drilled holes, using as reference the line indicated on second Detail View. 7047 Top Left Track 1 1 /2 "...
Page 60 Step 43 1) Slide the Pin Keeper 4053) through the Left Top Track to the end. The Pin Keeper hole needs to be on the right. 4053 Pin Keeper 4053 Pin Keeper This hole needs to be on the right. Slide the Pin Keeper to the end of the track.
Page 61 Step 44 1) Adjust the Pins up of the Active Two-Door System 7215) and fit the Rollers 2606) to be placed at the same level. 2606 Roller 7215 Two-Door System (Active) The Door System is extremely heavy. Use caution when lifting and maneuvering the product.
Page 62 Step 45 1) Maneuver the Active Two-Door System 7215) so the Top Rollers are in-line with the Top Track. 2) Carefully lift the Two-Door System up and move the Top Rollers into the Top Track. 3) Align the Bottom Pins so they enter the channel in the Bottom Track. 7215 Two-Door System (Active) Top Roller...
Page 63 Step 46 1) The Top of the Door Panels are to be parallel with the Top Track. 2) The Bottom Pins are to be embedded in the Bottom Track along full distance of Track. 3) If adjustment is required to meet these criteria, with the help of wrench tools, spin the 8150 Wrench 3”...
Page 64 Step 47 1) Use the Latch Switch to Fix the Pin Keeper 4053) on the Pin Lock. Do not fasten at this time. Do not fasten the Pin Keeper at this time Latch Switch 4053 Pin Keeper Pin Lock Pull the Latch Switch down in order to push the Pin Lock up.
Page 65 Step 48 1) Fit the Long Bottom Track 2601) to the Panel and Threshold. Fit tightly to Short Bottom Track, as shown. 2) Fasten through the pre-drilled holes. 1" #8 PAN HEAD (#2 ROBERTSON) 2601 Long Bottom Track 2601 Long Bottom Track Fit tightly to each other 0513 Cypress - Bélinda 11x11 Instructions...
Page 66 Step 49 1) Fit the Top Right Track 7048) tightly to the Top Left Track, as shown. Use the Rubber Mallet to help push the Top Left Track. 2) Fasten the Top Right Track in the pre-drilled holes. Keep the alignment. 7048 Top Right Track 1 1 /2 "...
Page 67 Step 50 1) Unfold and slide the Two-Door System to touch the Strike Post. 2) Fasten the Pin Keeper in the position, as shown. 4053 Pin Keeper 0513 Cypress - Bélinda 11x11 Instructions V1.1...
Page 68 Step 51 1) To prevent the Door System from tilting when swung closed, push Tilt Roller up into Track, firmly and secure in place. Door System resting un-level Push Tilt Roller up to engage with top of Track Door System must be leveled when unfolded 0513 Cypress - Bélinda 11x11 Instructions V1.1...
Page 69 I N STAL L AT IO N CO M PLE T E You can upgrade your Visscher gazebo by adding optional accessories. Bay Kit If you wish to purchase optional accessories, please contact your Insect Sliding Screen Doors local Visscher dealer. Cedar Panels...
