I N STRU CT ION
MANUAL
E N G L I S H
V E R A N D A -
1 1 X 1 1
D U K E / B A K E R

Advertisement

loading
Need help?

Need help?

Do you have a question about the VERANDA DUKE 11X11 and is the answer not in the manual?

Questions and answers

Related Manuals for VISSCHER VERANDA DUKE 11X11

Summary of Contents for VISSCHER VERANDA DUKE 11X11

  • Page 1 V E R A N D A - I N STRU CT ION D U K E / B A K E R MANUAL 1 1 X 1 1 E N G L I S H...
  • Page 2 Index IMPORTANT TOOLS HARDWARE COMPONENTS STEP 01 STEP 02 STEP 03 STEP 04...

  • Page 3: Before You Begin

    Assistance Estimated assembly If you require assistence, or need to order replacement time: 4 hours. parts, contact your Visscher Dealer. For additional information call the number below. Please have the serial number ready to ensure quick service. TOLL FREE 1 (877) 795-7423 0410 Duke/Baker Veranda 11x11 Instructions V1.1...
  • Page 4 Tools Some tools are required, others are suggested: TAP E ME A S URE K N IF E P HI L LI P S SC REW DRI V ER P R OT E CT I VE GLOV E S Required BUB BLE LE VE L TO O L P OW E R D R ILL L A D D E R ( 8 F T / 2.
  • Page 5 Hardware RO B ERTS O N B IT 5- 1 / 8 " X 5 / 1 6 " R SS ( T 30 TOR X ) 3/ 8" H E X H E AD BIT 4" X 5 / 1 6 " R SS ( T 30 TOR X ) TO R X T 3 0 B IT 3 1 / 8 "...
  • Page 6 Components Frame Structure 4010 Narrow Post 4111 Back Post 4110 Front Post 80” 4087 Side Post (Pre-drilled) 4109 Side Beam 4122 Beam 4081 Corner Brace MEASUREMENTS ARE APPROXIMATE 0410 Duke/Baker Veranda 11x11 Instructions V1.1...
  • Page 7 Components Roofing Structure & Upper Window 62” 62” 62” 4119 Front Filler (Left) 4120 Front Filler (Right) 4123 Back Filler 42 9/16” 81 1/4” 1/16” 4118 Gusset 4218 Sloped Window (Right) 4112 Upright (Pre-drilled) 4124 Upper Beam 4121 Mid Beam 4106 Rafter MEASUREMENTS ARE APPROXIMATE...
  • Page 8 Components Roofing 2509 Short Ceiling Board 2500 Full Ceiling Board 2508 Short Starter Ceiling Board 2507 Starter Ceiling Board 2672 Short Side Flashing Provided by Duke/Baker 2671 Long Flashing One is provided by Duke/Baker 1834 Foam Closure 6034 Underside Drip Edge 2493 Roof Sheet 4191...
  • Page 9 Phases Follow the sequence of phases, as shown: Frame Structure Roofing Roofing Structure & Upper Window Roofing Roofing Structure & Upper Window Frame Structure 0410 Duke/Baker Veranda 11x11 Instructions V1.1...
  • Page 10 Phase A Frame Structure Veranda side can be reversed to fit your needs. If you want to install your Veranda on the other side, contact your local dealer to order the required components for Veranda installation. 0410 Duke/Baker Veranda 11x11 Instructions V1.1...
  • Page 11 Step 1 1) Fit the Narrow Post 4010) and fasten to Front and Back Posts of the structure, as shown. Posts to sit tight to floor. 4010 Narrow Post 3 1 /8 " X 5 /1 6 " RS S (T3 0 TORX ) Flush 4010 Narrow Post...

  • Page 12: Inside View

    Step 2 1) Assemble the Front Post Assembly (DC 4110 4087), as shown. All the Posts of the Assembly are to be flush to the bottom. Front Post 4110) has 6 pre-drilled holes that must face Structure Front Post. The 2 pre-drilled holes side must face the back of the structure.
  • Page 13 Step 3 1) Stand the Front Post Assembly upright with the Front Post 4110) to the outside corner. 2) Place the Beam 4122) on the Narrow Post and Front Post Assembly as shown with the notches to the inside of the structure. 5 - 1 / 8 "...
  • Page 14 Step 4 1) Place two Corner Braces 4081) and fasten between Posts and Frame, orient as shown. The mounting face of the Corner Braces must be tight to the Post and Frame. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) 4081 Corner Brace 4081...
  • Page 15 Step 5 1) Assemble two Back Post Assemblies (DC 4111 4087). Posts are to be flush to the bottom. Pre-drilled pilot holes must be oriented as shown in the diagram. Reserve the Back Post Assemblies for the next steps. 4" X 5/ 1 6" RS S (T3 0 TORX ) Inside view 4111 Back Post...
  • Page 16 Step 6 1) Stand the Back Post Assembly upright with the Back Post 4111) to the outside corner. 2) Place the Beam 4122) on the Narrow Post and Back Post Assembly as shown with the notches to the inside of the structure. 5 - 1 / 8 "...
  • Page 17 Step 7 1) Place two Corner Braces 4081) and fasten between Posts and Frame, orient as shown. The mounting face of the Corner Braces must be tight to the Post and Frame. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) 4081 Corner Brace 4081...
  • Page 18 Step 8 1) Place the Beam 4109) on the Front and Back Post Assemblies. 2) Fasten through the pre-drilled holes. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) 4109 Side Beam 4109...
  • Page 19 Step 9 1) Place two Corner Braces 4081) and fasten between Posts and Frame, orient as shown. The mounting face of the Corner Braces must be tight to the Post and Frame. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) 4081 Corner Brace 4081...
  • Page 20 Phase B Roofing Structure & Upper Window 0410 Duke/Baker Veranda 11x11 Instructions V1.1...
  • Page 21 Step 10 1) Place the Mid Beam 4121) between Posts as shown with the notches to the inside of the structure. 2) Fasten through the notches and pre-drilled holes following the order shown on Detail Views. Use the Torx T30 6” Bit to reach full depth. 5 - 1 / 8 "...
  • Page 22 Step 11 1) Place the Upper Beam 4124) between Posts as shown with the notches to the inside of the structure. 2) Fasten through the notches and pre-drilled holes following the order shown in detail views. Use the Torx T30 6” Bit to reach full depth. 5 - 1 / 8 "...
  • Page 23 Step 12 1) Fasten the Upright 4112) to Front Post in the inside holes. Align the longest face to the Post and the shortest face to backwards. 4112 Upright 4" X 5/ 1 6" RS S (T3 0 TORX ) Align the longest face to the Post and the shortest face to backwards.
  • Page 24 Step 13 1) Fit Rafters 4106) and fasten to the Front and Back Posts. The Rafter notches must fit to the Posts. Use the Torx T30 6” Bit to reach full depth. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) 4106 Rafter 4106...
  • Page 25 Step 14 1) Fit Gusset 4118) and fasten to Rafters through the pre-drilled holes, as shown. Use the Torx T30 6” Bit to reach full depth. If neces- sary, use Rubbet Mallet to push the Gusset to the back. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) R U B B E R M A L L E T TOR X T 30 BIT 6 ”...
  • Page 26 Step 15 1) Fasten Right Sloped Window 4218) to Beams, Rafters and Gussets, as shown. 1" #8 PAN HEAD 4218 Sloped Window (Right) (#2 ROBERTSON) 4218 Sloped Window (Right) Side view Inside view Inside view 0410 Duke/Baker Veranda 11x11 Instructions V1.1...

  • Page 27: Front View

    Step 16 1) Mirror the Back Fillers 4123). The tab side of each Filler must be fit together in the middle of the structure as shown on Detail View. 2) Fasten the Back Fillers to back Beam. Use the Torx T30 4123 Back Filler 4"...

  • Page 28: Outside View

    Step 17 TORX T 30 BIT 6 ” 1) Fit Left and Right Front Fillers (DC 4119 4120) and fasten to Upper Beam. The tab side of each Filler must be fit together in the middle of the structure as shown on Detail View. Use the Torx T30 6” Bit to reach full depth.
  • Page 29 Step 18 1) Fit Rafters 4106) and fasten to the Front and Back Fillers. The Rafter notches must fit to the Fillers notches. Use the Torx T30 6” Bit to reach full depth. 5 - 1 / 8 " X 5 / 1 6 " R S S ( T 3 0 TO R X ) 4106 Rafter 4106...
  • Page 30 Phase C Roofing Phase C covers the 11x14 Base Structure and the 11x11 Veranda. you have a 40” or 80” Extension, pay atten- tion to the callouts in the following steps. When stepping on Roof, step on Screw Line and avoid stepping on Ribs as they can dent and deform.
  • Page 31 Step 19 C IRC ULAR SAW 1) In order to not interfere with the Veranda the Starter and the Ceiling Boards must be cut down to 84”. Use a Circular Saw to cut down the Starter and Ceiling Boards. 2507 Starter Ceiling Board 2500 Full Ceiling Board...

  • Page 32: Back View

    Step 20 1) Fit the Starters (DC 2507 2508) on the Rafters and fush to the bottom edges of the Rafters, tongue facing upwards. Ceiling boards to touch at the centre of the Rafters. 264X 2) Fasten to each two Rafters as shown. Screws must enter on 2507 Starter Ceiling Board 2508...
  • Page 33 Step 21 1) Fit the Ceiling Boards (DC 2500 2509) on the Rafters and fush to the bottom edges of the Rafters, tongue facing upwards. Ceiling boards to touch at the centre of the Rafters. 264X 2) Fasten to each two Rafters as shown. Screws must enter on 2500 Full Ceiling Board 2509...
  • Page 34 Step 22 1) Fit the Ceiling Boards (DC 2500 2509) on the Rafters and fush to the bottom edges of the Rafters, tongue facing upwards. Ceiling boards to touch at the centre of the Rafters. 264X 462X 2) Fasten to each two Rafters as shown. Screws must enter on 2500 Full Ceiling Board 2509...
  • Page 35 Step 23 STA PL E R K NI FE 1) Roll Tar Paper 4191) flat across Ceiling Boards, tight to the bottom most edge of the ceiling. 2) Staple the first row of Tar Paper to the Ceiling Boards using 1/2” staples, spaced a maximum of 12”...
  • Page 36 Step 24 STA PLE R KNI FE 1) Roll four more rows of Tar Paper 4191) flat across Ceiling Boards, overlapping each previous row by 6 inches. 2) Staple to the Ceiling Board using 1/2” staples, spaced a maximum of 12” apart from each other. Fasten each row of Tar Paper before moving on the next row.
  • Page 37 Step 25 1) Fit the Underside Drip Edge 6034) on the bottom edge of the Roof Assembly, tight to the end of the Ceiling Board. 2) Review the orientation of Tabs found on the first Roof Sheet 2493) in 185X the Back View.
  • Page 38 Step 26 1) Align the Roof Sheets 2493), Foam Closures 1834) and Underside Flashings (DC 2673 6034) to the edges of the Ceiling Boards. 104X 185X 2) Overlap three ribs of the Roof Sheet and cut down Foam 2673 Underside Flashing 2493 Roof Sheet 1834...
  • Page 39 Step 27 1) Align the next row of Roof Sheets 2493) and Foam Closures 1834) to the edges of the Ceiling Board. Overlap the first row of Roof Sheets as show on Side View. 2) Overlap three ribs of the Middle Roof Sheet and cut down Foam Closure to fit in three 136X 185X ribs as shown on Front View.
  • Page 40 Step 28 1) Fit the Short Side Flashing 2672) so it reaches the bottom edge of the bottom Roof Sheet. Fasten with two screws only at locations shown in diagram (13 inches apart). 2) Fit the Long Side Flashing 2671) over the short portion, and have it reach the top 185X edge of the top Roof Sheet.
  • Page 41 Step 29 1) Fit the Front Edge and Long Flashings (DC 2707 2671) so that it overlaps the Side Flashings. 2) Fasten to the roof metal through every second rib as shown on detail views. 185X 2707 Front Edge Flashing 2671 Long Flashing 3 /4 "...
  • Page 42 I N STAL L AT IO N CO M PLE T E...

This manual is also suitable for:

Veranda baker 11x11
