Hybrid Solar Inverter User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AU-1P3K2GLE-EU and is the answer not in the manual?

Questions and answers

Related Manuals for Austa AU-1P3K2GLE-EU

Summary of Contents for Austa AU-1P3K2GLE-EU

  • Page 1 Hybrid Solar Inverter User Manual...

  • Page 2: Table Of Contents

    Contents 1. Introduction 1.1 Important Safety Instructions 1.2 Explanation of Symbol 1.3 Basic features 1.4 Work Modes 1.5 Dimension 2. Interface definition and Technical Data 2.1 Interface definition 2.2 Technical Data 2.3 Basic Data 2.4 Safety and Protection 3. Installation 3.1 Check for Physical Damage 3.2 Packing List 3.3 Tools required for installation...

  • Page 3: Introduction

    1. Introduction 1.1 Important Safety Instructions Danger! Danger to life due to high voltages in the inverter! All work must be carried out by qualified electrician. The appliance is not to be used by children or persons with reduced physical sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.

  • Page 4: Explanation Of Symbol

    1.2 Explanation of Symbol This section gives an explanation of all the symbols shown on the inverter and on the type label. Symbols on the Type Label Symbol Explanation CE mark. The inverter complies with the requirements of the applicable CE guidelines.

  • Page 5: Basic Features

    1.3 Basic features Hybrid Inverter series is a high quality inverter which can convert solar energy to AC energy and store energy into battery. The inverter can be used to optimize self consumption, store in the battery for future use or feeding to public grid.

  • Page 6: Work Modes

    1.4 Work Modes Hybrid Inverter provides multiple work modes based on different requirements Work modes: Self-use 1.When PV, Grid, Battery is available: A. Solar energy provides power to the loads as first priority, if solar Grid Inverter energy is sufficient to power all connected loads, solar energy excess power will provides to charge battery, and then redundant power will feed to grid.

  • Page 7: Dimension

    Work modes: Bat priority 1. When PV, Grid, Battery is available: A. Solar energy will charge battery as first priority, if solar energy is Grid Inverter excess, the excess power will supply load. If there's still some extra energy, then the excess power will feed the power to grid . B.

  • Page 8: Interface Definition And Technical Data

    2. Interface definition and Technical Data 2.1 Interface definition Object Description Battery +/Battery - PV1+/PV1- PV2+/PV2- DC switch WiFi port for external WiFi Reserved port DRM/BMS Grid current / DRY IO USB port for upgrading POWER CAN /LEAD-NTC Pressure valve EPS output Grid output Note!
  • Page 9 2.2 Technical Data Model AU-1P3K2G- AU-1P3.6K2G AU-1P4K2G- AU-1P4.6K2G- AU-1P5K2G- AU-1P6K2G- Model -LE-EU LE-EU LE-EU LE-EU LE-EU LE-EU DC input Max. recommended DC power [W] 4600 6000 7000 Max. DC voltage[V] Norminal DC operating voltage[V] Nominal DC operating voltage[V] MPPT voltage range [V] 125-500 125-500 125-500...

  • Page 10: Basic Data

    2.3 Basic Data AU-1P5K2G AU-1P3K2G AU-1P4K2G -LE-EU -LE-EU -LE-EU Model AU-1P6K2G AU-1P3.6K2G AU-1P4.6K2G -LE-EU -LE-EU -LE-EU Dimension [W/H/D](mm) 550*520*200 Dimension of packing [W/D/H](mm) 680*660*330 Net weight [kg] Gross weight [kg] Installation modularization -25~+60 (derating at 45) Operating temperature range[℃] -25~+60 Storage temperature [℃] 4%~100% (Condensing) Storage/Operation relative humidity...

  • Page 11: Installation

    3. Installation 3.1 Check for Physical Damage Make sure the inverter is intact during transportation. If there is any visible damage,such as cracks, please contact your dealer immediately. 3.2 Packing List Open the package and take out the product, please check the accessories first. The packing list shown as below.

  • Page 12: Mounting

    Mounting Space Requirement Ø 300mm Table Available Space Size Position Min.size 300mm 300mm Left 300mm Right 300mm 300mm Bottom 300mm Front 300mm 300mm Step 1: Screw the wall bracket on the wall 1.1 Place the bracket on the wall and mark down the position of the 4 holes. 1.2 Drill holes with driller, make sure the holes are deep enough (at least 60mm) to support the inverter.

  • Page 13: Electrical Connection

    4. Electrical Connection Electrical connection diagram Ø Grid PV Breaker PV Breaker GRID Meter Grid side Main Breaker Breake BAT Breaker ..Loads AC Breaker Home Load On Grid Breaker Lithium BAT(48V) (PV MAX:500V) 4.1 Grid connection and EPS connection Hybrid inverter are designed for single phase grid.
  • Page 14 Step1. Check the grid voltage 1.1 Check the grid voltage and compare with the permissive voltage range (Please refer to technical data). 1.2 Disconnect the circuit board from all the phases and secure against re-connection. Step2. Remove the waterproof lid from the grid port on the inverter. Step3.

  • Page 15: Pv Connection

    4.2 PV connection Hybrid Inverter can be connected in series with 2-strings PV modules for 3KW,3.6KW 4KW,4.6KW, 5KW and 6KW. Select PV modules with excellent function and reliable quality. Open-circuit voltage of module arrays connected in series should be <Max. DC input voltage;operating voltage should be conformed to MPPT voltage range.

  • Page 16: Battery Connection

    Step5. Plug the PV connector into the corresponding PV connector on inverter. 4.3 Battery Connection Note Ø 1.Before choosing battery, please note the maximum voltage of battery can not exceed 59V and the rated voltage of battery can not exceed 48V, and the battery communication should be compatible with Hybrid inverter.

  • Page 17: Communication Interface Definition

    Step6. Connect the cable to the terminal of the inverter . Step7. Assemble waterproof connectors and waterproof covers plate. Step6，7 Note！ Positive and negative lines are not allowed to reverse. The positive pole on the left and the negative pole on the right. 4.4 Communication interface definition BMS PIN Definition Ø...

  • Page 18: Wifi And Gprs Connection(Optional)

    4.5 WiFi And GPRS Connection(optional) Inverter provides a WiFi port which can collect data from inverter and transmit it to monitoring-website by WiFi Step1. Plug Wifi into “COM” port at the bottom of the inverter. Step2. Build the connection between the inverter and router. Step3.

  • Page 19: Inverter Parallel Guide

    4.6 Inverter Parallel Guide 4.6.1 Parallel System Diagram Multiple inverters can be installed together to deliver more power. When AC loads are present, all units effectively share the load. The system diagram is as follows. Parallel System Diagram 1（Independent CT connection Method, Default connection method） For parallel to 3 units and more, please connect the parallel network cable to this port.
  • Page 20 Parallel System Diagram 2 （ Common CT connection Metho d） For parallel to 3 units and more, please connect the parallel network cable to this port. CAN(parallel) CAN(parallel) Master inverter Slave Inverter PV 1+ PV 2- PV 1- PV 1+ GRID PV 2+ PV 1-...
  • Page 21 For parallel communication ,CAT 5 cables are needed. The units should be connected hand by hand. When using common batteries, BMS cable needs to be connected to the master unit. The inverter shares the BMS information by inter- unit parallel communication cable. 4.6.2 Parallel Operation Notes 1) Make sure all the units in parallel are with the same sof tware version.

  • Page 22: Control Panel

    LCD Interface and Setting 5.1 Control Panel Object Description Name Display the information of the inverter. Screen lit in green: The inverter is in grid mode. Off: The inverter is in not in grid mode. lit in green: The inverter is in off-grid mode. Indicator Off: The inverter is in not in off-grid mode.

  • Page 23: Instructions For The Use Of Three Modes

    5.3 Instructions for the use of three modes WORK MODE PEAK SHIFT INDEPENDANT (Test mode) SYS SETTING Anti Reflux (Test mode) 6、HOME LOAD 7、BMS Aux MANAGE 8、ZERO EXPORT POWER 9、BAT LOW CAP STANDBY 10、NO BAT LV ALARM DC-SOURCE Lithum-48V 14 、AUTO TEST (Italian certification) 1 5、PARALLEL 1 6、ADVAN SET 5、DIAGNOSE...
  • Page 24 For example,Before selecting the mode, you can set it up ac cording to the local power grid, PV input mode and battery type. Power grid： Select 1：Set up Press Esc button Press Enter button Circular display User Enter password interface Default password 00000 Press UP/DOWN button Adjust the figure.

  • Page 25: Lcd Interface

    5.4 LCD Interface 5.4.1 Error information Interface Description Numbers represent error codes and text is error information. ERROR NO. Refer to Chapter 9 for specific contents. 02:BatDisconnect NOTE: When there is a lock mark in the upper right corner of the screen, you cannot turn the page, you need to press Enter to 27:BMS Comm.fail unlock it first.
  • Page 26 5.4.6 PV2 Input display interface Interface Description PV2 input real-time voltage, current and power. PV2 INPUT VOLT: 300V CURR: 10.00A POWER: 3000W 5.4.7 DC Voltage interface Interface Description BUS: Real-time voltage of bus capacitor of the machine. DC VOLTAGE BUS ： 384V 5.4.8 Battery interface Interface...
  • Page 27 5.4.11 Grid output Interface Description VOLT: Gird real-time voltage. GRID OUTPUT CURR: CT real-time current. VOLT: 0.0V FREQ: Grid real-time frequency. CURR: 0.00A FREQ: 0.00Hz 5.4.12 INV output Interface Description VOLT: INV real-time voltage. INV OUTPUT CURR: INV real-time current. VOLT: 0.0V FREQ:...
  • Page 28 5.4.16 Temperature Interface Description INVER: INV Temperature TEMPERATURE DCDC: DCDC Temperature . INVER: 0℃ INSIDE: Internal ambient temperature of the machine. DCDC: 0℃ INSIDE: 0℃ 5.4.17 State Interface Description System information: Display complete machine status STATE information, including: INIT, STANDBY, PV GRID, BAT GRID, BYP, AC BAT CHG, HYBRID POW etc.

  • Page 29: Settings

    5.5 Settings 5.5.1 State Interface Description SETUP: Press Enter to user settings interface. USER INQUIRE: Query machine model, serial number, software version. 1:SETUP STATISTIC: View machine run statistics. 2:INQUIRE 3:STATISTIC 5.5.2 SET Password Interface Description Enter the password required for setting. The default password PASSWORD is“00000”.
  • Page 30 5.5.4 System setting 5.5.4.1 System setting Interface Description This interface is used to access system information. SYS SETTING Press Up/Down button to move corresponding options. 1: WORK MODE Press Enter to enter the selected menu. 2: EPS ENABLE Press ESC button to return to the setting interface. 3: BAT WAKE-UP 4: REMOTE CTRL 5: START DELAY...
  • Page 31 5.5.4.2 EPS enable Interface Description When the Grid and PV are powered off, Enable the battery to EPS ENABLE supply power to the load, default option is enable. 1:DISABLE 2:ENABLE 5.5.4.3 Battery wake-up Interface Description When the battery is low and the battery relay has been WAKE-UP EN disconnected, the inverter will send instructions to the battery forcibly sucking relay by BMS, and the inverter will charge.
  • Page 32 5.5.4.7 BMS Aux MANAGE Interface Description ENABLE: When the BMS of the batter y does not have a BMS Aux MANAGE disable charge or discharge function, the inverter will 1.DISABLE automatically reduce the power to avoid overcharging or overdischarging the batter y. 2.ENABLE The default option is disabled.
  • Page 33 5.5.5 BAT SETTING 5.5.5.1 BAT SETTING Interface Description This interface is used to select battery parameters. BAT SETTING Press Up/Down button to move corresponding options; 1.BAT TYPE Press Enter button to enter the selected menu; 2.DISC-DEPTH Press ESC button to return to setting interface. 3.CHARG-CURR 4.BAT-COMM 5.5.5.1.1 BAT TYPE...
  • Page 34 Interface Description This interface is used to set the lead acid battery discharging BAT END VOLT voltage. (The input value ranges from 40 to 51V) INPUT: 45.0 Discharge cut-off voltage, as recommended by the battery UNIT: manufacturer. This interface is used to set the lead acid battery Charge BAT OVP protection voltage.
  • Page 35 5.5.7 RUN SETTING 5.5.7.1 RUN SETTING Interface Description This interface is used to select run setting. RUN SETTING Press Up/Down button to move corresponding options; 1.REACT MODE Press E nter button to enter the selected menu. 2.GRID POWER Factory default Settings. Please consult the distributor for modification.
  • Page 36 5.5.7.3 GRID POWER Interface Description The input value is power percent of grid. GRID PERCENT INPUT: 100% 5.5.7.4 DISCHARGE POWER Interface Description The input value is power percent of battery discharge. DISC PERCENT INPUT: 100% 5.5.7.5 PV POWER Interface Description The input value is power percent of PV.
  • Page 37 5.5.7.8 FAC-MIN Interface Description The input value of Grid low frequency. GRID FREQ LOW It is valid when grid mode choose custom. INPUT: 57.0 UNIT: 5.5.7.9 FAC-MAX Interface Description The input value of Grid high frequency. GRID FREQ HIGH It is valid when grid mode choose custom. INPUT: 63.0 UNIT:...
  • Page 38 5.5.8 485 Address Interface Description This interface is used to select 485 address. 485 ADDRESS INPUT: 5.5.9 485 BAUD RATE Interface Description This interface is used to select 485 baud rate. SELECT 1.2400 bps 2.4800 bps 3.9600 bps 5.5.10 LANGUAGE Interface Description This interface is used to select language.
  • Page 39 5.5.13 CLEAR REC Interface Description This interface is used to clear operation history. DEL REC 1.CANCEL 2.CONFIRM 5.5.14 PASSWORD Interface Description This interface is used to set password. PASSWORD OLD: XXXXX NEW: XXXXX CONFIRM: XXXXX 5.5.15 MAINTENANCE Interface Description This interface is used to enter maintenance. PASSWORD INPUT: XXXXX...
  • Page 40 5.5.17.1 Mode Set Interface Description There are three advanced mode available: Sell First ,SFC. Sell Mode Set EN, SFC. Sell Dis. 1.Disable Sell First:: First consider selling electricity to the grid. In this 2.Sell first mode the anti-reflux setting is automatically disabled. 3.SFC.

  • Page 41: Inquire

    5.6 INQUIRE 5.6.1 INQUIRE Interface Description Press Up/Down button to move corresponding options; INQUIRE Press Enter button to jump to the selected menu. 1.INV MODULE Press ESC button to return to other interface. 2.MODULE SN 3.FIRMWARE 4.RECORD 5.DIAGNOSE 5.6.1.1 INV MODULE Interface Description This interface show inverter model..

  • Page 42: Statistic

    5.6.4 RUNNING RECORDS Interface Description This interface show running recodes. REC(01) 02:Batdisconnect 12-25 23:00 DOWN: 5.6.5 DIAGNOSE Interface Description Factory internal use. DIAGNOSE 000000 000000 000000 000000 000000 000000 5.7 STATISTIC 5.7.1 STATISTIC Interface Description This interface show inverter operation statistic. STAT.

  • Page 43: Autotest Fast

    5.8 Autotest Fast Press the Enter button and 1. SETUP default password 00000 ↓ 14. AUTO TEST Press the Enter button to start T esting 59. S1 ... ↓ Wait Test 59.S1 OK! ↓ Wait Testing 59.S2... ↓ Wait Test 59.S2 OK! ↓...
  • Page 44 ↓ Press the up/down button to page through the test results 27.S1:228V 408ms ↓ Press the up/down button to page through the test results 27.S2:227V 205ms ↓ Press the up/down button to page through the test results 81>.S1 49.9Hz 103ms ↓...

  • Page 45: Fault Diagnosis And Solutions

    6. Fault diagnosis and solutions The inverter is easy to maintain. When you encounter the following problems, please refer to the Solutions below, and contact the local distributor if the problem remains unsolved. The following table lists some of the basic problems that may occur during the actual operation as well as their corresponding basic solutions.
  • Page 46 Grid voltage is abnormal (1) Check if the grid is abnormal. Grid over vol (2) Restart the inverter and wait until it functions normally. (3) Contact customer service if error warning Grid over vol continues. Grid Frequency is (1) Check if the grid is abnormal. Gfci low freq abnormal.
  • Page 47 Battery temperature is (1) Check the ambient temperature near the lower than the allowed battery to see if it meets the specifications. Bat UnderTemp value. (1) Check the cable, crystal, Line sequence. Communication between lithium battery and inverter (2) Checking the Battery switch. BMS comm.fail is abnormal or not in communication.
  • Page 48 V1.5...
