RUN HOURS / FAULT HISTORY
®
The PumpSaver Plus records pump run hours. Run hours can be displayed by a PumpSaver
Informer (see USING AN INFORMER on the following page). Run hours and fault history can be
cleared on the PumpSaver
p rocedure.
NOTE: Turn the SENSITIVITY knob completely to the left (counter-clockwise) or completely
t o the right (clockwise) when directed.
To Reset Run Hours and Clear Fault
1. Remove power to the PumpSaver
2. Set the RESTART DELAY/CALIBRATION knob to RESET and the SENSITIVITY knob to the
middle (12:00) position.
3. Apply power to the PumpSaver
4. Turn the SENSITIVITY knob to the right—the CAL. LIGHT will turn off and the RUN LIGHT will
turn on.
5. Turn the SENSITIVITY knob to the left—both lights will turn on.
6. Turn the SENSITIVITY knob to the right.
7. After 10 seconds, the CAL. and RUN LIGHTS will blink twice indicating the run hours and fault
history have successfully been cleared.
RAPID CYCLING
Rapid cycling is defined as more than 4 restarts in a 60-second period. The Model 233-P/233-1.5-P
is capable of detecting a rapid-cycle condition whether a control device, such as a pressure switch,
is installed before or after the PumpSaver
®
P umpSaver Plus will lock-out until power is removed and re-applied.
Protection against rapid cycling of a pressure switch installed before the PumpSaver
d isabled. Read the following instructions fully before performing the procedure.
NOTE: Turn the SENSITIVITY knob completely to the left (counter-clockwise) or completely
t o the right (clockwise) when directed.
To Disable Rapid-Cycle Protection when a Pressure Switch is Installed BEFORE the
PumpSaver Plus:
1. Remove power to the PumpSaver
2. Set the RESTART DELAY/CALIBRATION knob to RESET and the SENSITIVITY knob to the
middle (12:00) position.
3. Apply power to the PumpSaver
4. Turn the SENSITIVITY knob to the right—the CAL. LIGHT will turn off, RUN LIGHT will turn on.
5. Turn the SENSITIVITY knob to the left—both lights will turn on.
6. Turn the SENSITIVITY knob right—left—right—left—right.
7. After 2 seconds, the CAL. and RUN LIGHTS will blink once.
USING AN INFORMER
The Model 233-P/233-1.5-P is equipped with an infrared LED that will communicate to a SymCom
Informer—a handheld, battery-operated, diagnostic tool. The Informer—when directed at the Model
233-P/233-1.5-P —will display real-time voltage, current and power; dry-well and overcurrent trip
points; calibration voltage; last 20 faults; voltage, current and power at the last fault; highest/lowest
voltage and current since calibration; the model number; and the CT size if applicable. The Informer
can be used on any single-phase PumpSaver
Contact SymCom for more information at 800-843-8848 or visit our website: www.symcom.com.
© 2008 SymCom, Inc. All Rights Reserved
®
Plus. Read the following instructions fully before performing the
History:
®
Plus.
®
Plus—the CAL. LIGHT will turn on.
(to re-enable, follow the same procedure)
®
Plus.
®
Plus —the CAL. LIGHT will turn on.
®
Plus. Upon detecting either form of rapid cycling, the
®
Plus equipped with an infrared LED transmitter.
®
Plus
®
Plus can be
