QUICKSTART GUIDE W-DALI
TECHNICAL DATA
Power
Voltage range
Max power consumption
Frequency
Current Consumption
Conductor cross section (stranded)
Conductor cross section (solid)
DALI
DALI PSU guaranteed current
DALI PSU max current
Max number of DALI units on bus
Max DALI bus current consumtion
DALI start up time
Conductor cross section (stranded)
Conductor cross section (solid)
Environment
Ambient temperature range
Storage temperature range
Humidity (non-condensing)
Mechanical
Dimensions
Weight
Protection level
* with full DALI PSU load
SAFETY
Only qualified electricians may perform installations
with this product. Always follow local electrical code
and regulations.
Insulation classification: Basic insulation between
DALI terminal and all other terminals.
If W-DALI DIN RAIL is installed using an isolated
AC or DC supply, this must be in accordance with
IEC 61558-1 and applicable part 2 of IEC 61558.
Do not use the product if the product is damaged.
Only use cables within the spe-cified conductor sizes.
MANUFACTURER
LumenRadio AB
Johan Willins gata 6
416 64 Gothenburg
Sweden
1
Configure the W-DALI DIN rail and nodes to the same subnet, or alternatively,
use the app mode for setup. If the app is used the subnet on the W-DALI
nodes can be in any position.
Copyright © LumenRadio AB 2024, All Rights Reserved
W-DALI NODE
W-DALI DIN RAIL
216-253VAC
12-24VDC / 24VAC +/-10%
<1W*
<1W
50Hz
50Hz
<5mA
<100mA
0.5-2.5mm
0.2-2.5mm
2
0.5-4mm
0.2-2.5mm
2
30mA
40mA
10
120mA
<5s
0.5-2.5mm
0.5-2.5mm
2
0.5-4mm
0.5-2.5mm
2
-20 - +55 °C
-20 - +55 °C
-30 - +80 °C
-30 - +80 °C
10-95%
10-95%
46x46x21mm
36x93x59mm
21g
75g
IP20
IP20
Install W-DALI DIN rail.
2
2
2
2
(excluding antenna)
2
LUMENRADIO
W-DALI
Scan for additional
information
www.lumenradio.com
www.lumenradio.com
