- Page 1 INSTALLATION GUIDE Connect your solar inverter and smart meter wirelessly...
- Page 2 W-Modbus DIN rail /W-Modbus wall mount Transformer (230V–> 24V) You need this for installation.
- Page 3 Mount both LumenRadio devices - one by the inverter and the other by the smart meter.
- Page 4 Inverter RS485 cable + and – The device that you install by the inverter becomes your gateway.
- Page 5 Move the switch to ”COMM”.
- Page 6 Smart meter DTSU666 GNB B– A+ RS485 cable + and – The device that you install by the smart meter becomes your node.
- Page 7 The lights on your node will now sweep in blue.
- Page 8 When the lights start blinking green, the node has found the gateway. This can take up to five minutes.
- Page 9 Inverter RS485 cable + and – Go back to the inverter.
- Page 10 Move the switch to ”GATEWAY”.
- Page 11 The devices blink yellow and restart. The node reconnects to the gateway, which may take up to 5 minutes.
- Page 12 Now you have a wireless connection!
- Page 13 Inverter RS485 cable + and – To use the app, press the button on the gateway three times so that it blinks blue twice.
- Page 14 Verify your installation in the app. For a detailed overview, select Network Map.
- Page 15 Learn more at www.lumenradio.com...
