VISSCHER CYPRESS Instruction Manual

14x14
Hide thumbs

Advertisement

Quick Links

Download this manual
I N STRU CT ION
MANUAL
E N G L I S H
C Y P R E S S / B É L I N D A
1 4 X 1 4

Advertisement

loading
Need help?

Need help?

Do you have a question about the CYPRESS and is the answer not in the manual?

Questions and answers

Related Manuals for VISSCHER CYPRESS

Summary of Contents for VISSCHER CYPRESS

  • Page 1 C Y P R E S S / B É L I N D A I N STRU CT ION MANUAL 1 4 X 1 4 E N G L I S H...
  • Page 2 Index IMPORTANT TOOLS HARDWARE COMPONENTS STEP 01 STEP 02 STEP 03 STEP 04...

  • Page 3: Before You Begin

    If you require assistence, or need to order replacement time: 8 hours. parts, contact your Visscher Dealer. For additional information call the number below. Please have the serial number ready to ensure quick service. TOLL FREE 1 (877) 795-7423 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 4 R U B B E R M A L L E T C H A L K L I N E M A R K E R T R I GG ER CLA M P ( X2) Required Required OR A FLOOR MARKING TAPE 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 5 2 1 / 2 " # 8 F L AT H EA D (# 2 R O B ERTS O N ) TO R X T 3 0 B IT 1 1 / 2 " X 1 / 4 " R S S (T 25 TO RX ) MEASUREMENTS ARE APPROXIMATE 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 6 Split Truss Frame Member 4086 Post (Pre-drilled) 3544 Shear Panel 3505 Bifold Window 4087 Header (Pre-drilled) Panel 1880 Foam Gasket 4088 Threshold 3506 Full Glass 7098 Screen Window Panel (with Bifold Window) MEASUREMENTS ARE APPROXIMATE 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 7 Peak Support Block 14 5/8” 4134 Lower Roof Strapping (Right) 4139 Panel Support (Right) 4 9/32” 4042 4097 4135 Lower Mid Strapping 7063 Roof Installation Tool Upper Roof Strapping Ridge Beam Bracket MEASUREMENTS ARE APPROXIMATE 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 8 7044 Roof Sheet 7045 Roof Sheet (Outside left) (Inside left) (Middle) (Inside right) (Outside right) 2033 Sealing Tape 2823 Bottom Foam Closure 4197 Metal Corner Cover 2822 Top Foam Closure MEASUREMENTS ARE APPROXIMATE 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 9 Hey Key for M6 Bolts 7047 Top Left Track 2577 Strike Plate 2601 Long Bottom Track 2602 Short Bottom Track 4053 Pin Keeper 4006 Strike Post 2606 Roller 7215 Two-Door System MEASUREMENTS ARE APPROXIMATE 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 10 Phases Follow the sequence of phases, as shown: Panels Roofing Roofing Structure Roofing Door System Roofing Structure Door System Panels 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 11 Each side must have at least one Shear Panel. Door cannot pass over Bifold Window Panels. Door direction can be reversed. CAUTION: Do not over sink Panel Screws. Shear panel Shear panel Bifold Window Full Glass Window 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 12 2 1 /2 " #8 FL AT H E AD ( #2 RO BERTSON ) 4032 Split Truss Frame Sub-Assembly 4034 Split Truss Frame Member 4034 Split Truss Frame Member The components should be fit as tightly together as possible 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 13 Measure the Truss Frame to verify squareness. Adjust the Truss Frame until both measure- ments are equal. A to D = B to C The components should be fit as tightly together as possible 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 14 3) Once markings are complete, move the Truss Frame Assembly up and out of the way. These markings will be helpful in placing your corner posts and panels in the steps to come. Chalk Line Marker 160” 160” 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 15 The film on the panel is meant to reduce any chance of scratches or scuffs. It is not meant to be left on and will be extremely difficult to remove if left in the sun. 3544 Shear Panel 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 16 Bay Kit at this time. Bay kit The Bay Kit is the ultimate add-on to a VISSCHER fully enclosed structure. Not only does it instantly add square footage to the interior, but the bay also adds a stylish look that will set your enclosure apart from the neighbourhood.

  • Page 17: Outside View

    1) Use Foam Gasket 1880) and adhere to Panel edges 3544) connecting to Post 5125). knife 1880 Foam Gasket 3544 Shear Panel 5125 Post 3544 Shear Panel 5125 Post Outside view 1880 Foam Gasket 0515 Cypress - Bélinda 14x14 Instructions V1.1...

  • Page 18: Top View

    2 1/2" #8 WASHER HEAD (#2 ROBERTSON) 5125 Post 3544 Shear Panel 3544 Shear Panel Top view Screws should be in middle 1880 Foam Gasket Do not over sink the screws 5125 Post 3544 Shear Panel 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 19 5125 Post 3544 Shear Panel KN I FE knife 1880 Foam Gasket Do not over sink the screws Top view 5125 Post 5125 Post 3544 Shear Panel 3544 Shear Panel 3544 Shear Panel 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 20 Bifold Window 1880 Foam Gasket 3505 Bifold Window TR IGGER CLAM P ( X2 ) Top view Trigger clamp 1880 Foam Gasket Do not over sink the screws Screw from Shear panel when possible. 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 21 2 1/2" #8 WASHER HEAD (#2 ROBERTSON) 3505 Bifold Window T RI GGER CLAM P (X 2 ) 1880 Foam Gasket Trigger clamp Top view 3505 Bifold Window 3505 Bifold Window 3505 Bifold Window Fastened from inside 0515 Cypress - Bélinda 14x14 Instructions V1.1...

  • Page 22: Inside View

    Shear Panel 5125 Post 3544 Shear Panel 3506 Full Glass Window Top view of the front corner Panels 3506 3544 Shear Panel Full Glass Window Inside view Do not over sink the screws 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 23 2 1/2" #8 WASHER HEAD (#2 ROBERTSON) T RI GGER CLAM P (X 2 ) Shear Panels Assembly 1880 Foam Gasket Trigger clamp Top view Full Glass Windows Assembly Full Glass Windows Assembly Shear Panels Assembly Fastened from inside 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 24 3 1 /8 " X 5 /1 6 " RS S (T3 0 TORX ) 1880 Foam Gasket 4086 Post (Pre-drilled) Post has 2 pre-drilled sides. Use one side to attach to Panel. The other face to the inside. 4086 Post (Pre-drilled) 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 25 4087) to Posts, as shown. 4" X 5/ 16 " RSS ( T3 0 TORX ) 4087 Header (Pre-drilled) 4087 Header (Pre-drilled) The side that contains 5 pre-drilled holes must be facing down 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 26 4088) in the position shown on diagram. 2) Fasten the Threshold to the Posts in the pre-drilled holes. 106X 2 3 /4 " #1 0 RS S (T2 5 TORX ) 4088 Threshold 4088 Threshold 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 27 1) Carefully place the Truss Frame Assembly on top of the structure. 2) Fasten the Truss Frame Assembly through Header pre-drilled holes. 4" X 5/ 16 " RSS ( T3 0 TORX ) 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 28 1) Fasten the Truss Frame Assembly to the structure from inside. Use two screws per Panel. 2 1/2" #8 WASHER HEAD (#2 ROBERTSON) Fastened from inside Inside view Use two screws per Panel 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 29 Step 17 1) Fasten the Truss Frame Assembly to the Posts 5125) in the pre-drilled holes. 4" X 5/ 16 " RSS ( T3 0 TORX ) Truss Frame Assembly 5125 Post 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 30 Phase B Roofing structure 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 31 2 3 /4 " #1 0 RS S (T2 5 TORX) 4125 Peak Support Block 4097 Ridge Beam Bracket 4125 Peak Support Block Top view Please, ensure side with the Serial Number is facing down 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 32 Step 19 1) Attach two Common Rafters 4130) to the Ridge Beam Assembly as shown. 106X 4130 Common Rafter 2 3 /4 " #1 0 RS S (T2 5 TORX) 4130 Common Rafter 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 33 Collar Tie must be aligned to the notch line of the Common Rafter 4147 Collar Tie 2 1/2" #8 WASHER HEAD (#2 ROBERTSON) 4147 Collar Tie Collar Tie must be aligned to the notch line of the Common Rafter 1” 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 34 Step 21 1) Carefully flip the Rafter Assembly over and place on Truss Frame as shown. Do not fasten rafters to Truss Frame at this time. Rafter Assembly Do not fasten at this time. 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 35 4130 Common Rafter 2 3 /4 " #1 0 RS S (T2 5 TORX) Do not fasten Rafters to the Truss Frame at this time. 90° Square the Rafters to the Truss Frame 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 36 2 3 /4 " #1 0 RS S (T2 5 TORX) 4129 Hip Rafter 4129 Hip Rafter 4129 Hip Rafter 4129 Hip Rafter 4129 Hip Rafter 4129 Hip Rafter Do not fasten Rafters to the Truss Frame at this time. 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 37 2) Fasten the Collar Ties to the Common Rafters as shown. 4147 Collar Tie 2 1/2" #8 WASHER HEAD (#2 ROBERTSON) 4147 Collar Tie 1” Collar Tie must be aligned to the notch line of the Common Rafter 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 38 2 3 /4 " #1 0 RS S (T2 5 TORX) 4132 Jack Rafter (Right) Top view 4132 JR (Right) 4131 JR (Left) 4132 JR (Right) 4131 JR (Left) 4131 JR (Left) 4132 JR (Right) 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 39 2 1 / 2 " # 8 F L AT H E A D ( # 2 R O B ERTS O N ) 4137 Panel Support (Left) 4139 Panel Support (Right) Top view 4139 PS Right 4138 PS Mid 4137 PS Left 4137 PS Left 4138 PS Mid 4139 PS Right 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 40 Step 27 1) Fasten the Common, Hip and Jack Rafters to the Truss Frame as shown. 106X 2 3 /4 " #1 0 RS S (T2 5 TORX) 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 41 Upper Roof Strapping 2 1 / 2 " # 8 F L AT H E A D ( # 2 R O B ERTS O N ) 4042 Upper Roof Strapping Top view 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 42 2 1 / 2 " # 8 F L AT H E A D ( # 2 R O B ERTS O N ) 4136 Upper Mid Strapping Top view Do not stand on the Truss Frame or Rafter Assembly Screws at Hip Rafters must enter on an angle. 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 43 2 1 / 2 " # 8 F L AT H E A D ( # 2 R O B ERTS O N ) Do not stand on the Truss Frame or Rafter Assembly Top view 4135 Lower Mid Strapping Screws at Hip Rafters must enter on an angle. 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 44 Lower RS (Left) 4134 Lower RS (Right) 4134 Lower RS (Right) 4133 Lower RS (Left) 4134 Lower RS (Right) 4133 Lower RS (Left) Screws must enter on an angle whenever two strappings meet 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 45 1 1 /2 " # 8 F L AT H E A D 4197 Metal Corner Cover ( # 2 R O B ERTS O N ) 4197 Metal Corner Cover Align with end of Rafter Top view Centered on Rafter 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 46 1 1 /2 " # 8 F L AT H E A D 2155 Hip Cover ( # 2 R O B ERTS O N ) 2155 Hip Cover Top view Flush Flush 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 47 Bay Kit at this time. Bay kit The Bay Kit is the ultimate add-on to a VISSCHER fully enclosed structure. Not only does it instantly add square footage to the interior, but the bay also adds a stylish look that will set your enclosure apart from the neighbourhood.
  • Page 48 Phase C Roofing Only put screws at pre-punched locations. When stepping on Roof, step on Screw Line and avoid stepping on Ribs as they can dent and deform. 0515 Cypress - Bélinda 14x14 Instructions V1.1...

  • Page 49: Bottom View

    Foam Closure must be placed over the bottom row of holes 7045 RS (Outside right) 7044 RS (Inside right) 7043 RS (Middle) 7042 RS (Inside left) 7041 RS (Outside left) 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 50 Step 35 1) Attach the Roof Installation Tools 7063) at the positions shown. 7063 Roof Installation Tool 7063 Roof Installation Tool Top view 0515 Cypress - Bélinda 14x14 Instructions V1.1...

  • Page 51: Front View

    7042 RS (Inside left) 7044 RS (Inside right) 7043 RS (Middle) Overlap Overlap Fasten two screws Only fasten the Top view per Roof Sheet. middle line of Resting evenly screws. on Hip Rafters 0515 Cypress - Bélinda 14x14 Instructions V1.1...

  • Page 52: Side View

    1 " #9 H E X H E AD To take off the Installation Side view tool, press it upwards with your fingers. 2823 Foam Closure Detail view Do not fasten these two screws yet. 7044 RS (Inside right) 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 53 4) Fasten remaining screws for this section. 7041 RS (Outside left) 7045 RS (Outside right) 1 " #9 H EX H E AD Front view 7041 RS (Outside left) 7045 RS (Outside right) Overlap Underlap Underlap Overlap 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 54 Roof. Only put screws at pre-punched locations. When stepping on Roof, step on Screw Line and avoid stepping on Ribs as they can dent and deform. Resting evenly on Hip Rafters 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 55 Step 40 KN I FE 1) Attach the top Foam Closure 2822) in all sides. Use knife to cut exceeding parts. knife 2822 Top Foam Closure 2822 Top Foam Closure 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 56 3) Once adhered fully, trim at edge of the Roofing sheet as shown. 4) Repeat this on all four sides. knife 2033 Sealing Tape The Sealing tape must be centered on the joint. 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 57 7064) to the tabs of the Over Hip Cap 7065) Assemble four Hip Cap Assemblies. 7064 Hip Cap (Under) 7065 Hip Cap (Over) 7065 Hip Cap (Over) 7064 Hip Cap (Under) Bottom view 7064 Hip Cap (Under) 7065 Hip Cap (Over) 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 58 3) Repeat the process for all four sides. Do not over-tighten screws. 185X 3/ 4 " #1 4 H EX Hip Cap assembly Top view Screws must be fastened through the top ribs of the Roofing sheet only. 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 59 3) Secure the Peak Cap with screws on each side through the Cap and into the Roofing. 234X 7209 Peak Cap 1 " #9 H EX H E AD Top view 7209 Peak Cap Screws must be fastened through the top ribs of the Roofing sheet only. 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 60 Bay Kit at this time. Bay kit The Bay Kit is the ultimate add-on to a VISSCHER fully enclosed structure. Not only does it instantly add square footage to the interior, but the bay also adds a stylish look that will set your enclosure apart from the neighbourhood.
  • Page 61 Phase D Door System Optional Sliding Screen Doors Enhance your VISSCHER fully enclosed structure with our Sliding Screen Door Kits. Embrace the fresh breeze while keeping the bugs out. Crafted with high-quality insect screens that glide effortlessly along an aluminum track,...
  • Page 62 4 " X 5 / 1 6 " R S S ( T3 0 TO R X ) 4006 Strike Post of the fasteners. Top view 4006 Strike Post Flush 3/8” critical Flush 3/8” critical Tight to floor 0513 Cypress - Bélinda 11x11 Instructions V1.0...
  • Page 63 Strike and Deadbolt both align with the holes. 2) Fasten Strike Plate to the Strike Post. 1 1/2" #8 FLAT HEAD - BL 2577 Strike Plate (#2 ROBERTSON) 2577 Strike Plate Use the 3x Black Screw A provided 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 64 1) Fit the Short Bottom Track 2602) to the Threshold and flush to the Strike Post. 2) Fasten through the pre-drilled holes. 1" #8 PAN HEAD (#2 ROBERTSON) 2602 Short Bottom Track Flush 2602 Short Bottom Track 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 65 2) Fasten the Top Left Track in the pre-drilled holes, using as reference the line indicated on second Detail View. 7047 Top Left Track 1 1 /2 " X 1 /4 " RS S ( T2 5 TORX) 7047 Top Track Left Flush 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 66 The Pin Keeper hole needs to be on the right. 4053 Pin Keeper 4053 Pin Keeper This hole needs to be on the right. Slide the Pin Keeper to the end of the track. 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 67 2606) to be placed at the same level. 2606 Roller 7215 Two-Door System (Active) The Door System is extremely heavy. Use caution when lifting and maneuvering the product. 7215 Two-Door System (Active) Roller flush to bolt. 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 68 Do not rest Door System on ground that could cause damage to the product. It is advised to wear protective gloves when handling the Door System as edges of metal can be sharp. Bottom Pins 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 69 Top of Door Panels to be parallel to Top Track Spin the Bolt upwards or downwards to adjust door alignment if necessary. Bottom Pins to be embedded in Bottom Track along full distance of track. 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 70 Do not fasten at this time. Do not fasten the Pin Keeper at this time Latch Switch 4053 Pin Keeper Pin Lock Pull the Latch Switch down in order to push the Pin Lock up. 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 71 Fit tightly to Short Bottom Track, as shown. 2) Fasten through the pre-drilled holes. 1" #8 PAN HEAD (#2 ROBERTSON) 2601 Long Bottom Track Fit tightly to each other 2601 Long Bottom Track 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 72 1 1 /2 " X 1 /4 " RS S ( T2 5 TORX) R U B B E R M A L L E T Rubber Mallet 7048 Top Right Track Fit tightly to each other 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 73 Step 56 1) Unfold and slide the Two-Door System to touch the Strike Post. 2) Fasten the Pin Keeper in the position, as shown. 4053 Pin Keeper 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 74 1) To prevent the Door System from tilting when swung closed, push Tilt Roller up into Track, firmly and secure in place. Door System resting un-level Push Tilt Roller up to engage with top of Track Door System must be leveled when unfolded 0515 Cypress - Bélinda 14x14 Instructions V1.1...
  • Page 75 I N STAL L AT IO N CO M PLE T E You can upgrade your Visscher gazebo by adding optional accessories. Bay Kit If you wish to purchase optional accessories, please contact your Insect Sliding Screen Doors local Visscher dealer. Cedar Panels...
