2.4 Page 3
Turn individual audio loops on and off
The audio loop(L9) can be turned on of off individually by pressing the assigned switch on Page 3.
Turn individual function switches on and off
The function switches(F1~F4) can be turned on of off individually by pressing the assigned switch on Page 3.
BPM change
Tapping the TAP switch will change the MIDI Time Clock or F1~F4 rate to the tempo of your taps.
At this time, the Global BPM will be changed to the tempo of your taps and the changed BPM is display on the
LCD. The changed Global BPM is applied to the current bank or song. In other words, the Preset BPM stored in the
current bank or song is ignored.
The table below shows the functions of the switches in Page 3.
SW1
Normal
L9
Hold
None
2.5 Page 4
Turn input buffer on and off
The input buffer(BUF) can be turned on of off by pressing the assigned switch on Page 4.
Turn two outputs on and off
The two outputs(OL and OR) can be turned on of off individually by pressing the assigned switch on Page 4.
Select either IN1 or IN2
The two inputs(IN1 and IN2) can be selected by pressing the assigned switch on Page 4.
Increase/decrease BPM
The BPM(Preset BPM) can be increased/decreased by pressing the assigned switch on Page 4.
The table below shows the functions of the switches in Page 4.
SW1
Normal
OUT L
Hold
None
EFX-10D Audio Controller Owner's Manual
SW2
SW3
SW4
F1
F2
F3
None
None
None
SW2
SW3
SW4
Input
OUT R
IN2
Buffer
None
None
Vol.A-
SW5
SW6
SW7
Page+
F4
Tap
IA Store
None
None
SW5
SW6
SW7
Pst.
Pst.
Page+
BPM-
BPM+
Pst.
Pst.
IA Store
BPM-
BPM+
8
