2. BASIC OPERATION (PRESET MODE)

2.1 Initial Power Up

The EFX-10D requires a DC9V power supply. At initial power-up, the EFX-10D displays the operating mode on the
LCD display and starts with the first preset on bank 1 or song 1.
2.2 Page 1
Select a Preset
The EFX-10D has 800 presets and 1 global preset that you can choose from, and they're arranged in banks of five.
When the EFX-10D powers up, it selects Page 1, Preset 1 and Bank 1.
Press/hold BANK▼ or BANK▲ switch to shift other banks, pressing one of the four switches (P1~P4) selects a preset
in the new bank.
① Press/hold the BANK▼ or BANK▲ switch to scroll through the 200 available banks.
② The bank number on the LCD display will blink and the LEDs above P1~P4 switches will turn off.
③ The preset is selected via pressing any switches from P1 through P4.
④ The bank number on the LCD display will stop blinking and the LED above the switch will be turned on in blue.
The Global Preset is a preset with all the capabilities of Preset 1 through 4, but is the same for all banks. Pressing
the switch of a preset that is already on selects the global preset and will cause the LED above the switch to be
turned off. To enable/disable the Global Preset, refer to the 4.5.3 Other > 2nd.Press Pst on the page 24 of the manual.
Page change
The Page switch is set to have two functions. Press for a short time to increase the page number, and hold to save
the changed IA combination to the current preset.
The table below shows the functions of the switches in Page 1.
SW1
Normal
Preset1
Hold
None
2.3 Page 2
Turn individual loops on and off
The audio loops(L1-L7) can be turned on of off individually by pressing the assigned switch on Page 2.
The table below shows the functions of the switches in Page 2.
SW1
Normal
L1
Hold
None
EFX-10D Audio Controller Owner's Manual
SW2
SW3
SW4
Preset2
Preset3
Preset4
None
None
None
SW2
SW3
SW4
L2
L3
L4
None
None
None
SW5
SW6
SW7
Page+
BANK-
BANK+
IA Store
BANK-
BANK+
SW5
SW6
SW7
Page+
L5
L7
IA Store
None
None
7
