Unpacking and Inspection
Battery Module
Battery module
Item
Battery module
M5*14 Phillips cheese head screws
Document
Base Support (For wall mounting only)
Base support
M5*8 Phillips
countersunk head
screw
Item
Base supports
Transverse plate
Expansion screws
M5*20 Phillips countersunk head screws
M5*8 Phillips countersunk head screws
54
M5*14 Phillips cheese
head screw
Table 5-4 Packing list of battery module
Transverse plate
Table 5-5 Packing list of base support
Document
Expansion screw
Quantity
1 pc
2 pcs
1 pc
M5*20 Phillips
countersunk head
screw
Quantity
2 pcs
1 pc
6 pcs
6 pcs
4 pcs
