Summary of Contents for Hidoes HD-B10
- Page 1 HD-B10 ELECTRIC BIKE USER MANUAL...
- Page 2 USER MANUAL PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE RIDING Scan QR Code Or Enter URL for Online Installation Video https://www.youtube.com/watch?v=2aq8yV5rTNo...
- Page 3 1、 This manual was written to help you understand the proper use and maintenance of the Hidoes line of Electric electric bike. 2、 It is important to understand the functions and features of the new Hidoes before operating it as it will allow you to enjoy it from every ride.
-
Page 4: Table Of Contents
CONTENT Product & Component Display ······································································· 1~2 Product Parameters ···················································································· 3 Products & Accessories ··············································································· 4 Product Installation ···················································································· 5~8 Power On & Unlock···················································································· 9 Safe Driving Warning ················································································· 10~11 Battery & Charging ··················································································· 12~14 Cleaning&Storage&Disposal at End-of-Life························································15~16 Error Code ····························································································· 17 Troubleshooting ·······················································································... -
Page 5: Product & Component Display
Product & Component Display 01:Meter 06:Front wheel 11:Motor 02:Charging port 07:Front fork 12:Rear wheel 03:Brake 08:Brake pad 13:Rear fender 04:Headlight 09:Cowboy-style bike bag 14:Saddle shock absorption 05:Front fender 10:Foot pedal 15:Saddl... - Page 6 Product & Component Display 01:Brake 05:Downshift/Boost mode 09:Speed 02:Upshift 06:Headlight switch 10:Gear 03:Power switch 07:Mileage display 11:Brake 04:Settings 08:Battery displa 12:Accelerator...
-
Page 7: Product Parameters
Product Parameters Mode HD-B10 Tire Size 20 inch(20" x 4.0" Fat Tire) Battery 48V/13Ah Tyre Typ Off-road Air tires Power 1000 Charging time 6~8 hours Display Screen Color Frame Material Iron&Aluminum alloy Max Speed 25-45KM/H Net Weight 37.5KG Rang 25-40KM Gross Weigh 46.5KG... -
Page 8: Products & Accessories
Products & Accessories SERIAL NUMBE ITEM QUANTITY Charger Pump Instructions Taillight Toolkit Bicycle bell... -
Page 9: Product Installation
Product Installation Remove the two screws from Remove the electric bike Place the handlebars into the the rod from the packaging box corresponding lock mouth Use a tool to tighten the two Ensure the waterproof Adjust the position of the screws at the lock opening to connector hole is aligned front light's mounting patch... - Page 10 Use a tool to tighten the screws Align the front fender with the Remove the screws in the to secure the front fender into hole on the front fork center of the front fork the middle of the front fork Insert the bearing screws Place the disc brake disc into the Lift the body and align the front...
- Page 11 By turning the right pedal Each pedal comes with an "L" clockwise and the left pedal Take out the screws sticker or "R" sticker that counterclockwise identifies it as the left or right Seat shock absorber installation Align the screws at the front Tighten the screws is complete end of the shock absorber...
- Page 12 Align the rear light with the Tighten the screws Mounting screw gasket mounting holes Push the button to switch Rear light installation is Hold down the power on the rear lights complete button for 3-5 seconds When the instrument display Turn the half handle on the right lights up, it is successfully Assembly completed...
-
Page 13: Power On & Unlock
Power On & Unlock The display is equipped with five buttons on the corresponding operating unit powe on/off ,plus ,minus ,light and toggle Long press to power on/off the display. If you do not use the electric bike for more than 10 minutes, the meter will automatically shut down. -
Page 14: Safe Driving Warning
If you are uncertain about any part of his manual, please bring your Hidoes and this manual to a local bike shop for professional inspection,assembly and instructions. To keep yourself safe and to prolong the lifespan of your Hidoes, it is extremely important that you follow the safety guidelines in this manual. - Page 15 Do not lend your Hidoes to someone who is unfamiliar with operating the bike. If you do choose to lend your Hidoes to anyone, make sure that they read and understand the instructions in this manual.
-
Page 16: Battery & Charging
Battery & Charging BATTER Do not charge indoors. - Do not turn on and operate the electric bike while charging. - Keep the battery away from children, pets or direct heat. - Do not expose the battery to high temperature and pressure. - Please use the charger included with the electric bike for charging. - Page 17 Battery & Charging First Charg It is important to fully charge the battery before your first use of the electric bike. Your electric bike’s battery comes with these built-in features: 1. Balanced charging protection: During charging, the battery automatically balances the voltage among the internal cells to protect each cell.
- Page 18 Battery Maintenance Do not store the battery in a location that exceeds the temperature range of 20℃-25℃/68F-77F. Do not pierce the battery. Refer to local laws and regulations on battery recycling and/or disposal. If maintained properly, a battery can continue to perform at optimal levels well even powering your bike for many miles.
-
Page 19: Cleaning&Storage&Disposal At End-Of-Life
Storage Here are some tips on how to store your Hidoes E-Bike. Before storing the bike, charge the battery fully to prevent over-discharge due to lack of use. Even if you have not been using your E-Bike for more than one month, you should discharge and charge the battery at east once a month. - Page 20 The chemicals inside the battery are chemical pollutants. We recommend that all Hidoes products be disposed of as a whole or through an e-waste recycling center, program, or facility.
-
Page 21: Error Code
Error Code Error Code Fault Diagnostic Step Solution E001 Controller failure Controller failure Replace controller The instrument cannot receive the signal from the controller. E002 Communication fail Check whether the green line of the controller is connected Replace Instrument properly. Check whether the motor wires are connected properly or If there is no problem with each circuit, the E003... -
Page 22: Troubleshooting
Troubleshooting Malfunction Possible Cause Possible Solution 1.Under-charged battery. 1.Charge battery. Follow battery care procedures. 2.Battery no longer serviceable. 2.Have battery checked. Replace if faulty. Pedal assistance not working 3.Battery charger faulty. 3.Have charger checked. Replace if faulty. 4.Motor electrics or switches damaged / faulty. 4.Seek diagnosis and repair from authorised service centre. - Page 23 5.Loose pedal arm bolts. 5.Tighten. Malfunction Possible Cause Possible Solution 1.Pedal bearings too tight. 1.Adjust. 2.Bottom bracket bearings too tight. 2.Adjust. Grinding noise when pedalling 3.Rear wheel not straight. 3.Align so chain is straight. 4.Chain too tight. 4.Adjust. 5.Derailleur dirty. 5.Clean and lubricate.
- Page 24 3.Front forks or frame bent. 3.Straighten. Malfunction Possible Cause Possible Solution Motor "clicks" / has reduced 1.Under-charged battery. 1.Charge battery. Follow battery care procedures. power and / or shuts off 2.Motor internal fault. 2.Replace. 1.Blown fuse. 1.Replace. No power when pedal assistance 2.Loose connectors / wiring damage.
-
Page 25: Maintenance Schedule
Maintenance Schedule Check Before *Check Clean / Adjust / Tighten / Component / Condition Every Ride Periodically Lubricate Replace as Required Tyre Pressure Tyre Wear / Damage Brake Adjustment Handlebar Tightness Controls and Display Seat Post Tightness Fasteners / Mounting Hardware Brake Pads / Shoes Brake Cable Wear Chain... - Page 26 Derailleur Wheel Spoke Tension Wheel Trueness Wheel Bearings Bottom Bracket (Crank) Bearings * Every 5 to 10 rides depending on ride length and conditions.
-
Page 27: After Sales
We hope these videos will help you better understand and use our product. If you still have questions or concerns after watching the videos, please feel free to contact our customer service team, and we will be happy to assist you. Thank you again for your purchase and support! Wishing you a pleasant user experience https://www.Hidoes.com https://www.youtube.com/@Hidoes https://www.facebook.com/HidoesBike/... -
Page 28: Limited Warranty
11. Defects or damages from improper storage, exposure to moisture or dampness, modifications, connections, repairs (except as carried out by Hidoes or its authorised centres), misuse, neglect, abuse, accident, alteration, improper installation, or other acts which are not the fault of Hidoes, including damage caused by dropping, blown fuses, liquid entering the interior of the product. -
Page 29: Warranty Card
Battery serial number Name Distributor Contact Note Shenzhen Tianshengle Technology Co., Ltd. Address: Room 502, 5th Floor, Building 1, Liuwei Business Center, No.5, Longjing Community, Yangmei Community, Bantian Street, Longgang District, Shenzhen, China WhatsApp: +8613612953725 Customer support: support@hidoes.com Official website: www.Hidoes.com...
