Summary of Contents for Hidoes HD-B3
- Page 1 HD-B3 ELECTRIC BIKE USER MANUAL...
- Page 2 USER MANUAL PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE RIDING Scan QR Code Or Enter URL for Online Installation Video https://youtu.be/FIFlMB4KVjw?si=VZp53s0XCNXwISMC...
- Page 3 1、 This manual was written to help you understand the proper use and maintenance of the Hidoes line of Electric electric bike. 2、 It is important to understand the functions and features of the new Hidoes before operating it as it will allow you to enjoy it from every ride.
-
Page 4: Table Of Contents
CONTENT Product & Component Display ······································································· 1~2 Product Parameters ···················································································· 3 Products & Accessories ··············································································· 4 Product Installation ···················································································· 5~9 Power On & Unlock···················································································· 10 Safe Driving Warning ················································································· 11~12 Battery & Charging ··················································································· 13~15 Cleaning&Storage&Disposal at End-of-Life························································16~17 Error Code ····························································································· 18 Troubleshooting ·······················································································... -
Page 5: Product & Component Display
Product & Component Display 01: Transmission 07: Disc brake 13: Rear wheel 02: meter 08: Brake discs 14: Dental disc 03: Brake 09: Front wheel 15: Motor 04: Front headlights 10: Battery box 16: Rear mudguard 05: Front mudguard 11: Foot pedal 17: Seat 06: Front fork 12: Foot brace... - Page 6 Product & Component Display 01: Brake 05: Gear reduction 09: Transmission 02: Gear Plus 06: Electricity level 10: Accelerator 03: Speed 07: Total mileage 11: Brake 04: On/Off button 08: Gear position...
-
Page 7: Product Parameters
Product Parameters Model HD-B3 Tire Size 26 inch(26" x 4.0" Fat Tire) Battery 48V/18.2Ah Tyre Type Off-road Air tires Power 1200 Charging time 6~8 hours Black and white LCD Display Screen Frame Material Aluminum alloy display Max Speed 25-60KM/H Net Weight... -
Page 8: Products & Accessories
Products & Accessories SERIAL NUMBER ITEM QUANTITY Charger Toolkit Instructions Inflator Button tail lights... -
Page 9: Product Installation
Product Installation Loosen the fixing screws Remove the electric bike Turn the stand towards the of the handle from the packaging box front direction Cover the upright cover and Loosen the screws on the Place the threaded part of tighten the screws handle cover the crossbar into the... - Page 10 Find the arrows at both ends of Loosen the screws on the Lower the handle forward the instrument line and insert front fender and tighten the screws them relative to each other First, insert front Place the front wheel Screw in the nut and tighten fender, then insert the into the front fork the screw...
- Page 11 After tightening the quick Insert the quick release into Loosen the fixing screws of release, press and fix the the flower drum the disc brake handle Adjust the position of the disc Step your right foot into Place the disc brake into brake to avoid grinding the the crank and tighten it the fixed position of the...
- Page 12 Remove the tail light and unscrew Step the left foot into the Insert the tail light fixing the fixing screw, securing it in the crank and tighten it with a screws into the vehicle right rear fork position wrench to secure it If there is a transparent Tighten the tail light fixing Insert the tail light from top...
- Page 13 Long press the M key to turn Assembly completed on the device...
-
Page 14: Power On & Unlock
Power On & Unlock Long press to power on/off the display. If you do not use the electric bike, the meter will automatically shut down. Static state, long press to enter boost mode, release to exit boost mode. The walk boost mode can only be used when pushing the electric bicycle, please do not use it while riding. -
Page 15: Safe Driving Warning
If you are uncertain about any part of his manual, please bring your Hidoes and this manual to a local bike shop for professional inspection,assembly and instructions. To keep yourself safe and to prolong the lifespan of your Hidoes, it is extremely important that you follow the safety guidelines in this manual. - Page 16 Do not lend your Hidoes to someone who is unfamiliar with operating the bike. If you do choose to lend your Hidoes to anyone, make sure that they read and understand the instructions in this manual.
-
Page 17: Battery & Charging
Battery & Charging BATTERY Do not charge indoors. - Do not turn on and operate the electric bike while charging. - Keep the battery away from children, pets or direct heat. - Do not expose the battery to high temperature and pressure. - Please use the charger included with the electric bike for charging. - Page 18 Battery & Charging First Charge It is important to fully charge the battery before your first use of the electric bike. Your electric bike’s battery comes with these built-in features: 1. Balanced charging protection: During charging, the battery automatically balances the voltage among the internal cells to protect each cell.
- Page 19 Battery Maintenance Do not store the battery in a location that exceeds the temperature range of 20℃-25℃/68F-77F. Do not pierce the battery. Refer to local laws and regulations on battery recycling and/or disposal. If maintained properly, a battery can continue to perform at optimal levels well even powering your bike for many miles.
-
Page 20: Cleaning&Storage&Disposal At End-Of-Life
Storage Here are some tips on how to store your Hidoes E-Bike. Before storing the bike, charge the battery fully to prevent over-discharge due to lack of use. Even if you have not been using your E-Bike for more than one month, you should discharge and charge the battery at east once a month. - Page 21 The chemicals inside the battery are chemical pollutants. We recommend that all Hidoes products be disposed of as a whole or through an e-waste recycling center, program, or facility.
-
Page 22: Error Code
Error Code Error Code Fault Diagnostic Step Solution 1.Under-charged battery. 1.Charge battery Follow battery care procedures. Battery undervoltage 2.Motor internal fault. 2.Replace. If reinserting or unplugging the cable does not Check if the connector between the controller and the motor is Motor malfunction solve the problem, the motor needs to be loose. -
Page 23: Troubleshooting
Troubleshooting Malfunction Possible Cause Possible Solution 1.Under-charged battery. 1.Charge battery. Follow battery care procedures. 2.Battery no longer serviceable. 2.Have battery checked. Replace if faulty. Pedal assistance not working 3.Battery charger faulty. 3.Have charger checked. Replace if faulty. 4.Motor electrics or switches damaged / faulty. 4.Seek diagnosis and repair from authorised service centre. - Page 24 Malfunction Possible Cause Possible Solution 1.Pedal bearings too tight. 1.Adjust. 2.Bottom bracket bearings too tight. 2.Adjust. Grinding noise when pedalling 3.Rear wheel not straight. 3.Align so chain is straight. 4.Chain too tight. 4.Adjust. 5.Derailleur dirty. 5.Clean and lubricate. 1.Pads worn. 1.Replace.
- Page 25 Malfunction Possible Cause Possible Solution Motor "clicks" / has reduced 1.Under-charged battery. 1.Charge battery. Follow battery care procedures. power and / or shuts off 2.Motor internal fault. 2.Replace. 1.Blown fuse. 1.Replace. No power when pedal assistance 2.Loose connectors / wiring damage. 2.Check connectors / wiring.
-
Page 26: Maintenance Schedule
Maintenance Schedule Check Before *Check Clean / Adjust / Tighten / Component / Condition Every Ride Periodically Lubricate Replace as Required Tyre Pressure Tyre Wear / Damage Brake Adjustment Handlebar Tightness Controls and Display Seat Post Tightness Fasteners / Mounting Hardware Brake Pads / Shoes Brake Cable Wear Chain... - Page 27 Derailleur Wheel Spoke Tension Wheel Trueness Wheel Bearings Bottom Bracket (Crank) Bearings * Every 5 to 10 rides depending on ride length and conditions.
-
Page 28: After Sales
We hope these videos will help you better understand and use our product. If you still have questions or concerns after watching the videos, please feel free to contact our customer service team, and we will be happy to assist you. Thank you again for your purchase and support! Wishing you a pleasant user experience! https://www.Hidoes.com https://www.youtube.com/@Hidoes https://www.facebook.com/HidoesBike/... -
Page 29: Limited Warranty
11. Defects or damages from improper storage, exposure to moisture or dampness, modifications, connections, repairs (except as carried out by Hidoes or its authorised centres), misuse, neglect, abuse, accident, alteration, improper installation, or other acts which are not the fault of Hidoes, including damage caused by dropping, blown fuses, liquid entering the interior of the product. -
Page 30: Warranty Card
Battery serial number Name Distributor Contact Note Shenzhen Tianshengle Technology Co., Ltd. Address: Room 502 ,5th Floor, Building 1, Liuwei Business Center, No.5, Longjing Community, Yangmei Community, Bantian Street, Longgang District, Shenzhen, China WhatsApp: +8613612953725 Customer support: support@hidoes.com Official website: www.Hidoes.com...
