  • Page 1 JFX600-2513/UJF-7151plusII/UCJV330 Guide 2.5D Texture Maker MIMAKI ENGINEERING CO., LTD. https://mimaki.com/ D203632-15...

  • Page 2: Table Of Contents

    Table of Contents Introduction .................. 3 Precautions...................  3 Chapter 1 Overview of Functions 1.1 2.5D Texture Maker .............. 6 Effect of 2.5D Texture Maker.............. 6 Different Types of Printing .............. 6 Software Used .................. 7 Chapter 2 Usage Environment and Limitations 2.1 Usage Environment and Limitations ........

  • Page 3: Introduction

    • With the exception of what is provided in the warranty provisions, Mimaki Engineering Co. Ltd. does not assume any liability for any damage (including, but not limited to, the loss of profit, indirect damage, special damage, or other monetary damages) resulting from the use or inability to use this product.

  • Page 5: Chapter 1 Overview Of Functions

    Chapter 1 Overview of Functions This chapter This chapter provides an overview of 2.5D Texture Maker. 2.5D Texture Maker...........6 Different Types of Printing ......6 Effect of 2.5D Texture Maker ....... 6 Software Used ..........7...

  • Page 6: D Texture Maker

    Chapter 1 Overview of Functions / 1.1 2.5D Texture Maker 1.1 2.5D Texture Maker 2.5D Texture Maker takes advantage of UV ink characteristics to print in layers and make images look three- dimensional. Effect of 2.5D Texture Maker Textural printing, with layers at various heights Tonal values of grayscale images are used to create a sense of texture.

  • Page 7: Software Used

    Chapter 1 Overview of Functions / 1.1 2.5D Texture Maker Advantages Clear Color • Expression of subtle differences in texture is Clear Clear possible. Clear Clear • Clear ink creates a three-dimensional effect with Clear Clear transparency. Color Clear Disadvantages Media Media •...
  • Page 8 Chapter 1 Overview of Functions / 1.1 2.5D Texture Maker...

  • Page 9: Chapter 2 Usage Environment And Limitations

    Chapter 2 Usage Environment and Limitations This chapter This chapter describes the usage environment and limitations for 2.5D Texture Maker. Usage Environment and Limitations....10 Limitations with RasterLink7 ......1 3 Printer Environment ........10...

  • Page 10: Printer Environment

    You can also download it from the "Download" - "Profile" page in the printer product page on our official website. Flatbed models JFX600 Printer system JFX600-2513 System Pack Ver. 2.1.0 or later Ink type and corresponding software version JFX600 Version Ink type...
  • Page 11 UJF-7151 plusII System Pack Ver. 1.80 or later Ink type and corresponding software version UJF7151plusII Version Ink type Ink set Special Colorset RasterLink7 Mimaki Driver RasterLink Tools LH-100 CMYK ClPWW v3.0.0 or later v5.7.0 or later v1.11.0 or later CMYKLcLm v3.0.0 or later...
  • Page 12 Use of an ionizer is recommended. For details on ionizers, refer to your printer operation manual. Vertical models UCJV330 Ink type and corresponding software version UCJV330 Version Ink type Ink set Special Colorset RasterLink7 Mimaki Driver RasterLink Tools LUS-170 CMYK ClClWW v3.1.0 or later v5.8.0 or later v1.11.0 or later LUS-175 CMYK ClClWW v3.1.0 or later...

  • Page 13: Limitations With Rasterlink7

    Chapter 2 Usage Environment and Limitations / 2.1 Usage Environment and Limitations Limitations with RasterLink7 Functions not available in jobs that include 2.5D Texture Maker printing (1) The following functions cannot be used in combination with this kind of printing. Function •...
  • Page 14 Chapter 2 Usage Environment and Limitations / 2.1 Usage Environment and Limitations...

  • Page 15: Chapter 3 Printing With 2.5D Texture Maker

    Chapter 3 Printing with 2.5D Texture Maker This chapter This chapter describes 4 ways to perform printing. Settings ............16 Printing in Standard Mode by Using a Vector Image ............... 2 7 Printing in Standard Mode by Using a Grayscale [Illustrator] Creating Print Data..... 2 7 Image ..............17 [RasterLink] Check and change settings ..

  • Page 16: 3.1 Settings

    Chapter 3 Printing with 2.5D Texture Maker / 3.1 Settings 3.1 Settings This section describes the settings for 2.5D Texture Maker. [ RasterLink7 ] [ RasterLinkTools ] [Mode] Select [Standard] or [High speed]. For details, see "Differences Between Modes"(P. [Level] Printing is performed for the number of layers selected.

  • Page 17: Printing In Standard Mode By Using A Grayscale Image

    Chapter 3 Printing with 2.5D Texture Maker / 3.2 Printing in Standard Mode by Using a Grayscale Image 3.2 Printing in Standard Mode by Using a Grayscale Image Standard mode can express subtle differences in texture. It is suitable for images with gradual color transitions.

  • Page 18: [Rasterlink] Setting Up The Job

    Chapter 3 Printing with 2.5D Texture Maker / 3.2 Printing in Standard Mode by Using a Grayscale Image [RasterLink] Setting Up the Job Open your grayscale image in RasterLink7. Click the [Properties] icon. Change [Job Attribute] to [2.5D Texture Maker]. Select [Standard mode].
  • Page 19 Chapter 3 Printing with 2.5D Texture Maker / 3.2 Printing in Standard Mode by Using a Grayscale Image Select the two jobs. Select the [Composite] icon. Set the output order of composite jobs to Color -> 2.5D Texture (standard mode). •...
  • Page 20 Chapter 3 Printing with 2.5D Texture Maker / 3.2 Printing in Standard Mode by Using a Grayscale Image Select the [Print Condition] icon. Make sure the appropriate profile is selected. • [2.5D Texture Standard Speed] jobs: Confirm that [Media] is set to a [2.5D Texture Standard Speed] device profile.

  • Page 21: Rasterlink: Printing

    Chapter 3 Printing with 2.5D Texture Maker / 3.2 Printing in Standard Mode by Using a Grayscale Image RasterLink: Printing Click the [Execute] icon. Select [RIP and Print] and click [Start]. Print as you usually do with your printer.

  • Page 22: Printing In High Speed Mode By Using A Grayscale Image

    Chapter 3 Printing with 2.5D Texture Maker / 3.3 Printing in High Speed Mode by Using a Grayscale Image 3.3 Printing in High Speed Mode by Using a Grayscale Image High speed mode prints faster than standard mode. [Photoshop] Creating Print Data Open an image in Photoshop.

  • Page 23: [Rasterlink] Setting Up The Job

    Chapter 3 Printing with 2.5D Texture Maker / 3.3 Printing in High Speed Mode by Using a Grayscale Image [RasterLink] Setting Up the Job Open the grayscale image in RasterLink7. Click the [Properties] icon. Change [Job Attribute] to [2.5D Texture Maker]. Select [High speed mode].
  • Page 24 Chapter 3 Printing with 2.5D Texture Maker / 3.3 Printing in High Speed Mode by Using a Grayscale Image Select the two jobs. Select the [Composite] icon. Set the output order of composite jobs to Color -> 2.5D Texture (High speed mode). •...
  • Page 25 Chapter 3 Printing with 2.5D Texture Maker / 3.3 Printing in High Speed Mode by Using a Grayscale Image Make sure the appropriate profile is selected. • [2.5D Texture High Speed] jobs: Confirm that [Media] is set to a [2.5D Texture High Speed] device profile.

  • Page 26: Rasterlink: Printing

    Chapter 3 Printing with 2.5D Texture Maker / 3.3 Printing in High Speed Mode by Using a Grayscale Image RasterLink: Printing Click the [Execute] icon. Select [RIP and Print] and click [Start]. Print as you usually do with your printer.

  • Page 27: Printing In Standard Mode By Using A Vector Image

    Chapter 3 Printing with 2.5D Texture Maker / 3.4 Printing in Standard Mode by Using a Vector Image 3.4 Printing in Standard Mode by Using a Vector Image In standard mode, you can print the slanted edges of ink more smoothly. [Illustrator] Creating Print Data Create data to print with Illustrator.
  • Page 28 Chapter 3 Printing with 2.5D Texture Maker / 3.4 Printing in Standard Mode by Using a Vector Image Click the [2.5D RLOutput] icon of RasterLink Tools. • Alternatively, from the [File] menu, select [RasterLink] - [2.5D RLOutput]. • The [2.5D RLOutput] dialog appears. Set [Mode], [Level], [Slant], and [Order], and then click [OK].

  • Page 29: [Rasterlink] Check And Change Settings

    Chapter 3 Printing with 2.5D Texture Maker / 3.4 Printing in Standard Mode by Using a Vector Image [RasterLink] Check and change settings Start RasterLink7. • Any files saved in the Hot Folder are automatically opened in RasterLink7 and prepared as a composite job.
  • Page 30 Chapter 3 Printing with 2.5D Texture Maker / 3.4 Printing in Standard Mode by Using a Vector Image Make sure the appropriate profile is selected. • [2.5D Texture Standard Speed] jobs: Confirm that [Media] is set to a [2.5D Texture Standard Speed] device profile.

  • Page 31: Rasterlink: Printing

    Chapter 3 Printing with 2.5D Texture Maker / 3.4 Printing in Standard Mode by Using a Vector Image RasterLink: Printing Click the [Execute] icon. Select [RIP and Print] and click [Start]. Print as you usually do with your printer.

  • Page 32: Printing In High Speed Mode By Using A Vector Image

    Chapter 3 Printing with 2.5D Texture Maker / 3.5 Printing in High Speed Mode by Using a Vector Image 3.5 Printing in High Speed Mode by Using a Vector Image High speed mode prints faster than standard mode. [Illustrator] Creating Print Data Create data to print with Illustrator.
  • Page 33 Chapter 3 Printing with 2.5D Texture Maker / 3.5 Printing in High Speed Mode by Using a Vector Image Click the [2.5D RLOutput] icon of RasterLink Tools. • Alternatively, from the [File] menu, select [RasterLink] - [2.5D RLOutput]. • The [2.5D RLOutput] dialog appears. Set [Mode], [Level], [Slant], and [Order], and then click [OK].

  • Page 34: [Rasterlink] Check And Change Settings

    Chapter 3 Printing with 2.5D Texture Maker / 3.5 Printing in High Speed Mode by Using a Vector Image [RasterLink] Check and change settings Start RasterLink7. • Any files saved in the Hot Folder are automatically opened in RasterLink7 and prepared as a composite job.
  • Page 35 Chapter 3 Printing with 2.5D Texture Maker / 3.5 Printing in High Speed Mode by Using a Vector Image Make sure the appropriate profile is selected. • [2.5D Texture High Speed] jobs: Confirm that [Media] is set to a [2.5D Texture High Speed] device profile.

  • Page 36: Rasterlink: Printing

    Chapter 3 Printing with 2.5D Texture Maker / 3.5 Printing in High Speed Mode by Using a Vector Image RasterLink: Printing Click the [Execute] icon. Select [RIP and Print] and click [Start]. Print as you usually do with your printer.

  • Page 37: Chapter 4 Error Messages

    Chapter 4 Error Messages This chapter This chapter describes the error messages displayed by 2.5D Texture Maker. Displayed Messages and the Conditions Under Which They Are Displayed ......38...

  • Page 38: Displayed Messages And The Conditions Under Which They Are Displayed

    Chapter 4 Error Messages / 4.1 Displayed Messages and the Conditions Under Which They Are Displayed 4.1 Displayed Messages and the Conditions Under Which They Are Displayed The following table describes the messages displayed by 2.5D Texture Maker and the conditions under which they are displayed.
  • Page 39 JFX600-2513 / UJF-7151plusII / UCJV330 2.5D Texture Maker Guide March, 2024 MIMAKI ENGINEERING CO.,LTD. 2182-3 Shigeno-otsu, Tomi-shi, Nagano 389-0512 JAPAN D203632-15-29032024...
