Scarlett
Two Handle Roman Tub Bathroom Faucet
STANDARDS
•
ASME A112.18.1/CSA B125.1
•
ASME A112.18.2/CSA B125.2
•
LISTED IAPMO/cUPC
•
1.8 gpm/6.8 L/min
2021-03-25 MAAN4532-2
Helpful Information
Tools:
Gather the necessary tools as shown below to complete the installation of
this faucet. Some may not be needed depending on the model of faucet you
are installing. Check with your local hardware store on the requirements of
your installation situation.
©
®
PLUMBERS PUTTY
SAFETY GLASSES
CHANNELLOCKS
SEALED-TUBE
Attention:
For easy installation, you will need:
• To read all the installation instructions completely before beginning.
• To read all the warning, attention and maintenance information.
• To purchase the proper supply lines.
Important
FLASHLIGHT
SCREWDRIVER
ADJUSTABLE WRENCH
HEX-KEY
WARNING:
Please keep the tools for future use!
Tighten connection with two wrenches to prevent
damage to tube body. Be careful not to bend the
stem as this will void the product warranty.
BASIN WRENCH
PLIERS
TAPE
Advertisement
Related Manuals for Ancona Scarlett AN-4533
Summary of Contents for Ancona Scarlett AN-4533
- Page 1 Helpful Information Tools: Gather the necessary tools as shown below to complete the installation of this faucet. Some may not be needed depending on the model of faucet you are installing. Check with your local hardware store on the requirements of Scarlett your installation situation.
- Page 2 Installation size map Faucet Installation 23.5 cm (9.2 in.) 8.3 cm (3.2 in.) 11 cm (4.3 in.) 18.8 cm 19.2 cm (7.4 in.) (7.5 in.) 8.1 cm (3.2 in.) 6.2 cm (2.4 in.) Disassemble the parts as shown. 5.4 cm 10.2 cm 10.4 cm 5.9 cm...
- Page 3 Maintenance If faucet leaks from the handle or drips from spout, please replace cartridge following the steps: Connect the parts with supply lines as shown and tighten them with wrench. Disassemble the screw ② with ③ ① Cold water allen key , take out the handle ④...
- Page 4 PART NAME Cleaning and care Parts list Screw Handle Handle base Daily cleaning and care are required in order to keep the product shining and working properly. Screw nut O-ring 1. Clean it with water and dry it with soft cloth. Handle spline 2.
