Ancona Palermo AN-4107 Manual

Palermo
AN-4107
Flow Rate Chart
L/Min
2017-05-31 MAAN4107-03

Helpful Information

Tools:
Gather the necessary tools as shown below to complete the installation of this
faucet. Some may not be needed depending on the model of faucet you are
installing. Check with your local hardware store on the requirements of your
installation situation.
PLUMBERS
SAFETY
A .
Important
Bar
PUTTY FLASHLIGHT
GLASSES
CHANNEL LOCKS ADJUSTABLE WRENCH
SEALED-TUBE HEX-KEY
Connect to water supply lines with either
A 3 8 O D copper tubing ball nose
risers with the coupling nuts or
B . C .
B 3 8 copper tubing no ball with
supplied tube head interior connector or
C IPS faucet connectors 1 2
Tighten connection
with two wrench to
prevent damage to
tube body. Be
careful not to bend
the stem as this will
void the product
warranty.
BASIN WRENCH
SCREW DRIVER
PLIERS
TAPE
