Eleganzia
Widespread Lavatory Bathroom Faucet
STANDARDS
ASME A112.18.1/CSA B125.1
ASME A112.18.2/CSA B125.2
LISTED IAPMO/cUPC
Flow Rate Chart
G P M
2017-12-22 MAAN4321-1
Helpful Information
Tools:
Gather the necessary tools as shown below to complete the installation of
this faucet. Some may not be needed depending on the model of faucet you
are installing. Check with your local hardware store on the requirements of
your installation situation.
©
®
PLUMBERS PUTTY
SAFETY GLASSES
CHANNELLOCKS
Attention:
For easy installation, you will need:
- To read all the installation instructions completely before beginning.
- To read all the warning, attention and maintenance information.
- To purchase the proper supply lines.
Important
Connect to water supply lines with either
P S I
risers with the coupling nuts or
supplied tube head interior connector or
FLASHLIGHT
ADJUSTABLE WRENCH
SEALED-TUBE
HEX-KEY
WARNING:
Please keep the tools for future use!
Tighten connection with two wrench to prevent
damage to tube body. Be careful not to bend the
stem as this will void the product warranty.
A.
BASIN WRENCH
SCREWDRIVER
PLIERS
TAPE
B.
C.
