SERVICE PARTS
98068T-4DR
1271408**
1119280
835696
**Color code must be specified when ordering.
1284743-AN2-A
ARTIFACTS
Lever Handles
1187607**
1271406
832940
1271409**
1205739**
78125
1271298
871021
22352
1110332
1131955
77539
1119281
1156038
INSTALLATION INSTRUCTIONS
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. An in line water filter must be used with this product.
3. Inspect the supply tubing for damage and leakage. Replace and maintain as necessary.
4. Observe local plumbing codes.
5. If possible, install this faucet before installing the sink.
6. Shut off the water supplies to the fitting.
7. The lever handles must be used with the spout 77368T or 72760T-ND.
8. All installations should comply with the relevant requirements of AS/NZS 3500.
HANDLE OPERATION
Right handle opens with turning clockwise, left handle opens with turning counter-clockwise.
ROUGH-IN DIMENSIONS
4
1284743-AN2-A
98068T-4DR
Lever Handles
Ø32~Ø35
203
ARTIFACTS
85
Ø57
98068T-4DR
