SERVICE PARTS
72275K-4
Single Handle Lavatory Faucet
98868K-4
Single Handle Tall Lavatory Faucet
3016002**
3015547**
1219254
1219253
3008414
871472
1213964
836664
**Color code must be specified when ordering
1212002-K2-D
833438
3008523
3015836**
1213964
98868K:1176997
3004460
837056**
ALEO
INSTALLATION INSTRUCTIONS
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. If possible, install this faucet before installing the lavatory.
3. Inspect the supply tubing for damage and leakage. Replace and maintain as necessary.
4. Observe local plumbing codes.
5. Shut off the water supplies to the fitting.
HANDLE OPERATION
Lift handle gently. Turn clockwise for hot water, turn counter-clockwise for cold water.
ROUGH-IN DIMENSIONS
72275K-4
4
1212002-K2-D
72275K-4
Single Handle Lavatory Faucet
98868K-4
Single Handle Tall Lavatory Faucet
14º
18º
159
Ø31~Ø37
100
Ø31~Ø37
G3/8˝
G3/8˝
98868K-4
ALEO
Ø63
146
G1˝ 1/4
1
