Halsey Taylor Sanitary FR 4720 Quick Installation Instructions

MODEL 4720 Sanitary FR
This fountain is certified to
NSF/ANSI 61.
GENERAL
Pedestal, Endura ™ steel fountain with textured
powder coat finish and E-Coat immersion for
year-round beauty with minimum maintenance.
The E-Coat immersion process coats the
outside and inside of the fountain for the
ultimate in corrosion protection. Contour
formed stainless steel basins with rounded
corners and edges reduces splatter, insures
proper drainage and prevents standing waste
water. Designed to be easily accessible to both
physically challenged and able-bodied
individuals. Ideally suited for installation in
public areas. Model meets state and federal
requirements as defined by the Americans with
Disabilities Act.
SANITARY FREEZE-RESISTANT
VALVE SYSTEM
Fully sealed assembly minimizes chance of
ground water contamination, and prevents
drain water from mixing with fresh water.
Freeze-resistant valve designed for ground
installation 18" below the frost line.
BUBBLER
Exclusive one-piece, vandal-resistant, chrome-
plated two-stream mound-building bubbler
with non-removable anti-squirt feature and
integral hood insures a satisfying drink of
water.
PUSHBUTTON ACTUATION MECHANISM
Self-closing, vandal-resistant pushbutton does
not require grasping or twisting.
AUTOMATIC STREAM HEIGHT REGULATOR
Dual stream height regulator is located inside
sanitary freeze-resistant valve system to prevent
tampering. Unit resists corrosion and liming.
A constant stream height is automatically
maintained under line pressures that vary
from 20 to 105 psi.
INLET STRAINER
Easily cleaned in-line strainer screen traps
particles of 140 microns or larger before they
enter the waterway.
WATER INLET
1/2" male NPT fitting.
DRAIN OUTLET
Drain requirements are detailed in owner's manual.
ACCESS PANEL
Manufactured of heavy-gauge steel with
vandal-resistant screws. Provides access for
easy hook-up of all plumbing connections.
SUGGESTED SPECIFICATIONS
Fountains shall include pushbuttons on the front
and back. Shall include contour-formed basins
to eliminate splashing and standing water, and
shall have rounded corners and edges.
Projectors shall be two-stream, mound-building
type with integral hood guard and anti-squirt
feature. Fountain shall comply with ANSI 117:1
and ADA for visual and motion disabilities. The
manufacturer shall certify the unit to meet the
requirements of NSF/ANSI 61, and the Safe
Drinking Water Act.
halseytaylor.com
HALSEY TAYLOR, 2222 CAMDEN COURT, OAK BROOK, ILLINOIS 60523
Sanitary Freeze-Resistant
Bi-Level Endura
Barrier-Free Fountain
™ Steel Pedestal
Standard Finish is Evergreen textured
powder-coat Endura II
™
Each 4720 Sanitary FR consists of 2 cartons
of the following:
Fountain
Sanitary Freeze-Resistant Valve System
Service stop not included.
Shipping weight: 129 lbs.
NOTE: Continued product improvement makes
specifications subject to change without notice.
See Halsey Taylor website for most current
spec sheet.
JOB NAME:
ENGINEER/CONTRACTOR NAME:
APPROVAL:
DATE:
B44 /
6-2008
