Rails
14 Rails
To clean the rails and cooking compartment thor-
oughly, you can remove the shelf supports.
14.1 Unhooking the rails
WARNING ‒ Risk of burns!
The rails can be very hot.
Never touch the rails when they are hot.
▶
Allow the appliance to cool down.
▶
Keep children at a safe distance.
▶
Hold the bottom of the shelf support and pull it
1.
slightly towards the front. Pull the extension pins in
the lower section of the rails out of the mounting
openings.
2. Pull the entire shelf support downwards first and
then pull it forwards and remove it.
14.2 Attaching the rails
Place the two hooks at the top of the rail into the up-
1.
per holes.
2. ATTENTION!
Incorrect assembly
Never move the rail before the two hooks are se-
▶
cured fully in the upper holes. Otherwise the
enamelled coating may be damaged and break.
Both hooks must be inserted fully into the upper
3.
holes. Move the rail down slowly and carefully, and
hook it into the lower holes.
Hook both rails into the side walls of the oven.
4.
If the rails are fitted correctly, the distance between
the two upper shelf positions is greater.
