- Page 1 2000 Series Frequency-agile True Diversity UHF Wireless System Installation and Operation...
- Page 2 2000 Series Installation and Operation Important information For customers in Canada Warning: ISED statement To prevent fire or shock hazard, do not expose this apparatus to rain or moisture. CAN ICES-003(B)/NMB-003(B) Caution: CAN RSS-Gen/CNR-Gen This device contains licence-exempt transmitter(s)/receiver(s) that comply with •...
-
Page 3: Receiver Installation
2000 Series Installation and Operation Receiver Installation Each wireless system includes a receiver and either a body-pack or handheld transmitter. UniPak body-pack transmitter systems include ® accessory microphones for particular applications. All A-T Wireless Location Essentials microphones and cables, available separately, are pre- ®... -
Page 4: Receiver Controls And Functions
2000 Series Installation and Operation Receiver Controls and Functions Fig. B – Front Panel Controls and Functions Fig. C – Receiver LCD Window Display 1. POWER SWITCH: Press the Power switch in to turn the receiver on. The LCD window will light, and the operating channel number will be displayed in the window. - Page 5 2000 Series Installation and Operation Fig. D – Rear Panel Controls and Functions 15. AF LEVEL CONTROL: Adjusts audio output level of both AF output 10. ANTENNA INPUT JACK: BNC-type antenna connector for Tuner “B.” Attach the antenna directly, or extend it with a low-loss jacks.
-
Page 6: Transmitter Controls And Functions
2000 Series Installation and Operation Transmitter Controls and Functions Handheld Transmitter Battery Installation 1. While holding the upper part of the transmitter body below the ball- screen, unscrew the lower body cover, slide it downward, and Battery Selection remove it to expose the battery compartment. Two 1.5V AA alkaline batteries or rechargeable AA NiMH batteries for use with Audio-Technica’s ATW-CHG2 Recharging Station are 2. -
Page 7: System Operation
2000 Series Installation and Operation System Operation Setting Levels Correct adjustment of transmitter audio input, receiver audio output, and mixer/amplifier input and output levels is important for optimum Switch on the receiver. Do not switch on the transmitter yet. system performance. Receiver On…... - Page 8 2000 Series Installation and Operation Setting Levels (Continued) Fig. E – UniPak Transmitter Open ® ATW-T210c UniPak Transmitter ® Trimmer adjustments in the UniPak transmitter (Fig. E ) will enable ® you to use microphones or instruments with different output levels. 1.
-
Page 9: Specifications
2000 Series Installation and Operation Specifications † Overall System ATW-T210c UniPak Transmitter ® UHF Operating Frequencies RF Power Output (50 ohms) High: 30 mW, Low: 10 mW Frequency Range Number of Channels (switchable) Band D: 656.125 to 678.500 MHz 10 Spurious Emissions Following federal and national Band I:... - Page 10 2000 Series Installation and Operation 2000 Series Frequency Channel Plan CAUTION: U.S. Public Safety/Security Restrictions Band D (Private Land Mobile Radio Services) Channel Frequency-MHz 656 . 125 Pertains to Band I Only. 659 . 375 660 . 000 Avoid the frequencies/channels listed below in each of the following 662 .
