- Page 1 2000 Series Professional UHF Wireless Systems ATW-2110 UniPak ™ Transmitter System ATW-2120 Handheld Dynamic Microphone System Installation and Operation...
- Page 2 Professional UHF Wireless Systems Installation and Operation The ATW-R2100 receiver features true diversity reception. Two This device complies with part 15 of the FCC Rules. antennas feed two completely independent RF sections on Operation is subject to the condition that this device does the same frequency;...
-
Page 3: Receiver Installation
Receiver Installation Antennas Location Attach the included pair of UHF antennas to the antenna input For best operation the receiver should be at least 3 ft. (1 m) jacks. The antennas are normally positioned in the shape of a above the ground and at least 3 ft. away from a wall or metal “V”... -
Page 4: Receiver Controls And Functions
Receiver Controls and Functions Figure B-Front Panel Controls and Functions SET/SCAN POWER DOWN UHF SYNTHESIZED DIVERSITY RECEIVER ATW-R2100 Figure C-Receiver LCD Window Display 1. POWER SWITCH: Press the Power switch in to turn the receiver on. The LCD window will light, and the operating channel number will be displayed in the window. - Page 5 Receiver Controls and Functions (Continued) Figure D-Rear Panel Controls and Functions LEVEL ANT. B ANT. A SQUELCH GROUND AF OUT AF OUT 12~18V DC GROUND LIFT BALANCED 500 mA UNBALANCED 10. ANTENNA INPUT JACK: BNC-type antenna connector for 15. BALANCED AUDIO OUTPUT JACK: XLRM-type connector. Tuner “B.”...
- Page 6 Transmitter Controls And Functions Battery Selection Handheld Transmitter Battery Installation Two 1.5V AA alkaline batteries are recommended. 1. While holding the upper part of the transmitter body by the translucant ring below the ball-screen, unscrew the lower UniPak™ Transmitter Battery Installation body cover, slide it downward, and remove it to expose the 1.
-
Page 7: System Operation
System Operation Switch on the receiver. Do not switch on the transmitter yet. Setting Levels Correct adjustment of transmitter audio input, receiver audio Receiver On… output, and mixer/amplifier input and output levels is important The LCD display will light up and one of the tuner operation for optimum system performance. - Page 8 System Operation (Continued) Setting Levels (Continued) Figure E-UniPak Transmitter Open ATW-T210 UniPak™ Transmitter Trimmer adjustments in the UniPak™ transmitter (Fig. E) will enable you to use microphones or instruments with different output levels. Antenna 1. For MIC: Set microphone level trim control fully clockwise (maximum) and instrument level trim control fully counterclockwise (minimum).
-
Page 9: Specifications
Specifications † UNIPAK ™ TRANSMITTER OVERALL SYSTEM RF Power Output 12 mW Operating Frequency UHF band, 656.125 to 678.500 MHz Spurious Emissions Under federal regulations Number of Channels 10 total Input Connections High impedance, low impedance, bias Frequency Stability ±0.005%, Phase Lock Loop frequency control Batteries (not included) Two 1.5V AA alkaline... - Page 10 Optional System Accessories WIRELESS ESSENTIALS ™ MICROPHONES AND CABLES RECEIVER ACCESSORIES AT829cW Miniature cardioid condenser lavalier microphone. AEW-DA660D UHF (655-680 MHz) active unity-gain antenna distribution Includes clothing clip and windscreen. system provides two “1-in, 4-out” RF channels; connects a MT830cW Miniature omnidirectional condenser lavalier pair of antennas to as many as four diversity receivers;...
- Page 11 2000 Series Frequency Channel Plan Channel Frequency - MHz TV Channel 656.125 659.375 660.000 662.125 665.125 669.750 671.500 677.000 678.125 678.500 Note: All frequencies selected to avoid standard analog TV carrier interference. Ten Tips to Obtain the Best Results 1. Use only fresh alkaline batteries. Do not use “general 7.
- Page 12 One-Year Limited Warranty Audio-Technica professional wireless systems purchased in the U.S.A. are warranted for one year from date of purchase by Audio-Technica U.S., Inc. ( A. T .U.S.) to be free of defects in materials and workmanship. In event of such defect, product will be repaired promptly without charge or, at our option, replaced with a new product of equal or superior value if delivered to A.
