Assa Abloy NORTON RIXSON P7500 Quick Start Manual

P7500
Non Handed Door Closer
Parallel Arm Mount
With or without DA suffix (delayed action)
With or without M suffix (metal cover)
WARNING
This product can expose you to lead which is known to the state of
California to cause cancer and birth defects or other reproductive harm.
For more information go to www.P65warnings.ca.gov.
Included Components (See page 2 for mounting hardware)
DA Option
(5 Valves)
Cover
1/8" Hex Wrench
Standard Plastic
or Optional Metal
TO DETERMINE
HAND OF
To Determine Your Hand of Door:
YOUR DOOR:
Right Hand
Reverse
LEFT
HAND
DOOR
Copyright © 2001, 2014, 2021, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9377-1219-020 Rev 3 12/21
Left Hand Door - LH
Right Hand Reverse - RHR
Closer
Regular Arm/
Shoe
Top Jamb Shoe
Connecting Rod
Screw Pack
To Identify Your Model:
Older models may
be stamped "1-6",
"1-4" or "2-6". They
Left Hand
can be replaced
Reverse
with a newer "1-6"
model which has
RIGHT
no stamp.
HAND
DOOR
Standard S7500 = 4 valves
Delayed Action S7500DA = 5 valves
Non Hold Open Arm Models
Adjustable
(Sizes 1-6)
Ce produit peut vous exposer au plomb qui, dans l'état de la Californie,
est reconnu pour causer le cancer, des anomalies congénitales ou d'autres
problèmes de reproduction. Pour plus d'informations, visitez:
www.P65warnings.ca.gov.
Parallel Arm
Main Arm
Pinion Screw
Arm Assembly
Main Arm
Forearm
Screw
Arm Slide
Right Hand Door - RH
Left Hand Reverse - LHR
Optional Components
1618 Parallel Arm
Bracket
(Used with
Parallel Arm
Installation Only)
Tools Needed
NORTON
RIXSON
7788
Drop Plate
