instructions carefully and familiarize yourself with the different parts.
please contact afifurnishings at customerservice@afifurnishings.com or 1-800-955-3726
PARTS LIST
1
SIDE RAILS
2
SUPPORT BOARD
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
Step 1
Attach side rails (1) to the headboard and footboard. For assembly, follow
the assembly instructions included with your headboard and footboard.
PO:
BED FRAME
ASSEMBLY INSTRUCTIONS
Before assembling your bed frame, please read through these
ATTENTION! If you receive a damaged or defective item,
2 PCS
3 PCS
1
TWIN
A
Wood screw(1 1/4") - 6 pcs
1
CODE
FR-UBN2-FNM
HARDWARE
Spare - 1 pc
lower set of pins.
ITEM
R-26512X
READY
TO
ASSEMBLE
Adult assembly
Page 1 of 2
Advertisement
Related Manuals for AFi FR-UBN2-FNM
Summary of Contents for AFi FR-UBN2-FNM
- Page 1 NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY. Step 1 Attach side rails (1) to the headboard and footboard. For assembly, follow the assembly instructions included with your headboard and footboard. Adult assembly lower set of pins. CODE ITEM FR-UBN2-FNM R-26512X Page 1 of 2...
- Page 2 TWIN Attach support board (2) to the bed as shown below using wood screws 1 1/4" (A). Step 2 Tighten with Phillips head screw driver. (customer supplied) Adult assembly Wood screw 1 1/4" Congratulations! Your bed is now ready for use. We recommend that you periodically recheck that all screws are tight to ensure lasting safety.
- Page 3 BED WITH MATCHING FOOTBOARD ASSEMBLY INSTRUCTIONS READY Before assembling your bed, please read through these instructions carefully and familiarize yourself with the different parts. ASSEMBLE ATTENTION! If you receive a damaged or defective item, please contact afifurnishings at customerservice@afifurnishings.com or 1-800-955-3726 Instructions apply for bed sizes PARTS LIST HARDWARE...
- Page 4 HARDWARE HEADBOARD BOX 1 FOOTBOARD Adult assembly SIDE RAILS BOX 2 Step 1 Attach the side rails (04) to the headboard (02) and footboard (03) using the bed hook as shown below. UPPER LOWER Use the upper set of pins when using mattress only, storage drawers or Trundle bed.
