AFi R-28272X Assembly Instructions

instructions carefully and familiarize yourself with the different parts.
please contact afifurnishings at customerservice@afifurnishings.com or 1-800-955-3726
PARTS LIST
1 HEADBOARD PANEL 1 PC
2 LEFT LEG
3 RIGHT LEG
4 WOOD DOWELS 4 PCS
(Factory Installed)
5 FOOTBOARD
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
Attach the legs (2) and (3) to headboard panel (1), using JCB (A) and barrel nut (B).
Step 1
Tighten with the Allen wrench (C).
A
B
A
2
B
To ensure lasting safety, we recommend that you periodically check
BED WITH MATCHING FOOTBOARD
ASSEMBLY INSTRUCTIONS
Before assembling your bed, please read through these
ATTENTION! If you receive a damaged or defective item,
Instructions apply for bed sizes
A JCB M6 X 110mm (4 3/8") - 4 pcs
1 PC
1 PC
B Barrel nut - 4 pcs
1 PC
1
4
A
Congratulations!
Your headboard is now assembled.
that all screws are tight and all parts are secure.
TWIN > FULL
Spare - 1 pc
Spare - 1 pc
B
A
B
A
3
HARDWARE
C Allen wrench - 1pc
Spare - 1pc
FRONT VIEW
TAPER INSIDE AND
HOLES TO THE FRONT.
CODE ITEM
HBFB-NKT R-28272X R-28273X
PO : PO :
READY
TO
ASSEMBLE
Adult assembly
ITEM
Page 1 of 2
