- Page 1 CHARITY EDITION OPERATOR’S MANUAL The actual product you have received may differ slightly from the illustration. DANGER ● To ensure safe operation of the product, be sure to read this Operation Manual before use. ● Keep this Operation Manual in a safe place for easy reference when needed.
- Page 2 No part of this publication may be reproduced by any mechanical photograph- ic, or electronic process, or in the form of a photographic recording, nor may it be stored in a retrieval system, transmitted, or otherwise copied for public or private use, without permission from BANDAI NAMCO Amusement America.
-
Page 3: Safety Precautions
Owner’s Manual PAC-MAN’S™ PIXEL BASH SAFETY PRECAUTIONS The following symbols are used in labels on the game to draw attention to potentially hazardous situations: WARNING : Failure to avoid the risk may result in serious injury or death. Electrical Shock Hazard. Disconnect power before removing cover. Should only be done by a qualified technician. - Page 4 Operator’s Manual PAC-MAN’S™ PIXEL BASH DOLLAR BILL ACCEPTOR PAC-MAN PIXEL BASH CHARITY EDITION COMES PRE-EQUIPPED ● WITH A DOLLAR BILL ACCEPTOR AND COIN COMPARITOR. THE BILL ACCEPTER IS AN ICT STACKERLESS DBA AND COIN ● COMPARITOR...
-
Page 5: Specifications
Operator’s Manual PAC-MAN’S™ PIXEL BASH 1.0 SPECIFICATIONS 115 VAC/230 VAC, 60 Hz, 1.5 Input Power: Amp 130 Watts Maximum Installed Dimensions: 84.28" H, 29.35" D, 24.88" W WARNING REMOVAL OF SERIAL NUMBERS AND/OR BAR-CODES FROM PRODUCT OR COMPONENTS WILL VOID THE WARRANTY THIS GAME CONTAINS NO SERVICEABLE PARTS INSIDE AND ANY ATTEMPT TO ACCESS INTERNAL PARTS MAY RESULT IN ELECTRIC SHOCK DUE TO THE PRESENCE OF HIGH VOLTAGE 2.0 IMPORTANT SAFETY INSTRUCTIONS 2.1 INSTRUCTIONS Read these instructions. Keep these instructions Heed all warnings. Follow all instructions Do not use apparatus near water. Clean only with a dry cloth. Do not block any ventilation openings, Install in accordance with the manufacturers instructions. -
Page 6: Inspection & Installation
Operator’s Manual PAC-MAN’S™ PIXEL BASH Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point it exits from the product. Only use the attachments/accessories specified by the manufacturer. Unplug this apparatus during lightning storms or when unused for long periods of time. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. When replacing fuses heed the following warning: CAUTION: For continued protection against risk of fire, replace only with the same type of fuse having the same electrical ratings. 2.2 INSTALLATION This game is designed for indoor use only. It must not be installed outdoors. The following conditions must be avoided. Direct exposure to sunlight, high humidity, direct water contact, dust, high heat, or extreme cold. Vibration. The game must be installed on a level surface. Do not install in an area such that the game would present an obstacle in case of an emergency (i.e., near fire equipment or emergency exits). 2.3 HANDLING Before operating the game, make sure that the main AC power hookup includes a safety ground. This will ensure safe operation as well as compliance with FCC and UL regulations. Measure the AC power line voltage. Verify that the voltage source is between 220 and 230 VAC. Before replacing any parts, turn the AC power OFF and unplug the game. When unplugging the game from an electrical outlet, always grasp the plug, not the line cord. The game power supply includes areas of high voltage. Take care at all times to avoid electrical shock whenever inspecting or adjusting the game. 3.0 INSPECTION & INSTALLATION ™... - Page 7 Operator’s Manual PAC-MAN’S™ PIXEL BASH Carefully remove the game cabinet from its shipping platform and inspect it for visible signs of damage. When installing, please ensure there is at least 3 inches of clearance around the cabinet for adequate ventilation. If your game exhibits signs of damage be sure to document it and contact your distributor and transportation carrier immediately Examine the contents of the package, It should contain the following: ™ One PAC-MAN’S game. PIXEL BASH One Power cord. One operator’s manual (this manual). If any of these items are missing please contact your distributor immediately. Plug in the game and turn on the power switch, (the switch is located on the back of the cabinet on the power supply) The game consists of the following video games in one package: Bosconian...
-
Page 8: Test Mode
Operator’s Manual PAC-MAN’S™ PIXEL BASH 4.0 TEST MODE Located inside of the back door of the cabinet on top of the cash box are the controls to access test mode and the game volume. There are 3 buttons 2 of which are volume controls and one is a test button to access the game test menus. - Page 9 Operator’s Manual PAC-MAN’S™ PIXEL BASH When the test switch is operated, the following menu is displayed: Choosing Common Adjustments gives you the following menu : The game cost can be adjusted for 1 through 19 credits or set for free play.
- Page 10 Operator’s Manual PAC-MAN’S™ PIXEL BASH Choosing Game Adjustments gives you the following menu : This will allow you to tailor each of the games characteristics individually by adjusting things like the game difficulty, the speed, the number of lives, and the number of points required for a bonus. It also allows you to return each game to default factory settings. The next menu is under the Diagnostic test menu: The switch test only has one function in this game: checking switch operation.
- Page 11 Operator’s Manual PAC-MAN’S™ PIXEL BASH Accessing the cash box On the back of the cabinet is a back door with an eyebolt hasp for a padlock, you can place a padlock here for enhanced security to the cash box. Remove the back door of the cabinet and once inside remove the 2 silver phillips screws ...
- Page 13 Operator’s Manual PAC-MAN’S™ PIXEL BASH NOTES:...
- Page 14 Operator’s Manual PAC-MAN’S™ PIXEL BASH NOTES:...
-
Page 15: Warranty
BANDAI NAMCO Amusement America Inc.. parts or accessories. BANDAI NAMCO Amusement America Inc. cannot be responsible for the quality, suit-ability or safety of any non-BANDAI NAMCO part or any modification including labor which is performed by such distributor. - Page 16 Part No:PY45-19569-00 1550 Glenlake ave Itasca, IL 60143...
