Bandai Namco PAC-MAN’S PIXEL BASH Owner's Manual

Hide thumbs

Advertisement

Quick Links

OWNER'S MANUAL
To ensure safe operation of the product, be sure to read this Operation Manual before use.
Keep this Operation Manual in a safe place for easy reference when needed.
Bandai Namco Amusement America Inc.
The actual product you have received may differ slightly from the illustration.
DANGER

Advertisement

loading

  Summary of Contents for Bandai Namco PAC-MAN’S PIXEL BASH

  • Page 1 The actual product you have received may differ slightly from the illustration. DANGER ● To ensure safe operation of the product, be sure to read this Operation Manual before use. ● Keep this Operation Manual in a safe place for easy reference when needed. Bandai Namco Amusement America Inc.
  • Page 2 IMPORTANT Read PRECAUTIONS and INSTALLATION Sections before operating game RF Notice FCC REGULATORY AND SAFETY INFORMATION (USA ONLY) WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference In a residential installation.
  • Page 3: Safety Precautions

    Owner’s Manual PAC-MAN’S™ PIXEL BASH SAFETY PRECAUTIONS The following symbols are used in labels on the game to draw attention to potentially hazardous situations: WARNING : Failure to avoid the risk may result in death or serious injury Electrical Shock Hazard. Disconnect power before removing cover. Should only be done by a qualified technician.
  • Page 4: Specifications

    Owner’s Manual PAC-MAN’S™ PIXEL BASH 1.0 SPECIFICATIONS Input Power: 120 VAC, 60 Hz, 1.5 Amp 180 Watts Maximum Installed Dimensions: 33” W 21 7/8” L 60” H WARNING REMOVAL OF SERIAL NUMBERS AND/OR BAR-CODES FROM PRODUCT OR COMPONENTS WILL VOID THE WARRANTY THIS GAME CONTAINS NO SERVICEABLE PARTS INSIDE AND ANY ATTEMPT TO ACCESS INTERNAL PARTS MAY RESULT IN ELECTRIC SHOCK DUE TO THE PRESENCE OF HIGH VOLTAGE 2.0 IMPORTANT SAFETY INSTRUCTIONS 2.1 INSTRUCTIONS Read these instructions. Keep these instructions Heed all warnings. Follow all instructions Do not use apparatus near water. Clean only with a dry cloth. Do not block any ventilation openings, Install in accordance with the manufacturers instructions. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including amplifiers) that produce heat. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
  • Page 5: Inspection & Installation

    Owner’s Manual PAC-MAN’S™ PIXEL BASH Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point it exits from the product. Only use the attachments/accessories specified by the manufacturer. Unplug this apparatus during lightning storms or when unused for long periods of time. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. When replacing fuses heed the following warning: CAUTION: For continued protection against risk of fire, replace only with the same type of fuse having the same electrical ratings. 2.2 INSTALLATION This game is designed for indoor use only. It must not be installed outdoors. The follow- ing conditions must be avoided. Direct exposure to sunlight, high humidity, direct water contact, dust, high heat, or extreme cold. Vibration. The game must be installed on a level surface. Do not install in an area such that the game would present an obstacle in case of an emergency (i.e., near fire equipment or emergency exits). 2.3 HANDLING Before operating the game, make sure that the main AC power hookup includes a safety ground. This will ensure safe operation as well as compliance with FCC and UL regulations. Measure the AC power line voltage. Verify that the voltage source is between 110 and 125 VAC. Before replacing any parts, turn the AC power OFF and unplug the game. When unplugging the game from an electrical outlet, always grasp the plug, not the line cord. The game power supply includes areas of high voltage. Take care at all times to avoid electrical shock whenever inspecting or adjusting the game. 3.0 INSPECTION & INSTALLATION ™...
  • Page 6 Owner’s Manual PAC-MAN’S™ PIXEL BASH Carefully remove the game cabinet from its shipping platform and inspect it for visible signs of damage. When installing, please ensure there is at least 3 inches of clearance around the cabinet for adequate ventilation. If your game exhibits signs of damage be sure to document it and contact your distributor and transportation carrier immediately Examine the contents of the package, It should contain the following: ™ One PAC-MAN’S game. PIXEL BASH One Line cord. One Owners Warranty registration Card. One owners manual.(this manual). One FCC Regulatory and Safety Information Sheet. If any of these items are missing please contact your distributor immediately. Turn on the game. Plug in the game and turn on the power switch, (the switch is located inside the front door on the metal plate below the adjustment switches.) The cabaret game consists of the following video games in one package:...
  • Page 7: Test Mode

    Operator’s Manual PAC-MAN’S™ PIXEL BASH 4.0 TEST MODE Located behind the front door are access controls to the test mode. In addition to the main power switch there are 3 switches and a volume control provided to tweak the settings to the owners specifications. The Test toggle switch causes the game to enter test mode, showing the available catagories from which the tests can be selected. When the test toggle is returned to its previous position, the game returns to attract mode any changes performed by the owner are saved into memory. The Select toggle switch is used to move up and down through the menus or catagories, and the Enter pushbutton is used to make the selection. After making any changes to a setting, use the EXIT function to step out of that section. When complete, return the test toggle switch to its normal position before turning the game off.
  • Page 8 Owner’s Manual PAC-MAN’S™ PIXEL BASH When the test switch is operated, the following menu is displayed: Choosing Game Options gives you the following menu : This will allow you to tailor each of the games characteristics individually by adjusting things like the game difficulty, the speed, the number of lives, and the number of points required for a bonus. It also allows you to return each game to default factory settings.
  • Page 9 Owner’s Manual PAC-MAN’S™ PIXEL BASH Choosing Common Adjustments gives you the following menu :...
  • Page 10 Notes...
  • Page 11: Warranty

    Namco Amusement America Inc. which is performed by such distributor. SERVICE If you have questions regarding any Bandai Namco Amusement America Inc. product or require technical support: Contact Bandai Namco Amusement America Inc. Customer Service at: 1 (847) 264-5614 or FAX 1 (847) 264-5613...
  • Page 12 Part No: PY45-19816-00 712 N. Central Avenue Suite B Wood Dale, IL 60191...
