EPC700-Module
Installation Guide
EPC700 Module A
Prior to installation and assembly, make sure you have read and understood the "Supplemental Directives" and
"Safety" chapters in the User Manual for the corresponding basic unit (EPC710, EPC720, or EPC730).
Intended Use
The EPC700 Module A program module (the "program module" or "product") is a pre-programmed module for
controlling a fixed cleaning cycle on a retractable fitting.
Use of the product is only permitted in compliance with the operating conditions stated in the Specifications.
Package Contents
• EPC700 Module A
• Installation Guide
Nameplate
The product is identified by a nameplate.
3
EPC700 Module A
2
1
7
Installation
Use the mounting locations on the right-hand side of the base plate. The following figure shows the recom-
mended mounting location.
NOTICE! Product damage due to electrostatic discharge (ESD). Take protective measures against electrostatic
discharge.
01. Loosen the screws (2)
Note: All screws are pre-installed on the base plate.
02. Insert the cable (1) (EPC700 Air 5/2-Way Valve) into mounting
03. Insert the cable (6) (EPC700 Water 2/2-Way Valve) into mounting
Function
Control of a fixed cleaning cycle (move sensor out of the process, clean sensor, and move sensor into the
process) of the retractable fitting.
For a description, see the User Manual for the basic unit (EPC710, EPC720, or EPC730).
Read before installation.
Keep for future use.
6
1 2
3
4
5
6
7
and fasten the program
1
Item number, serial number, year/month
2 Model designation
4
3 Manufacturer
4
Product family
5 CE mark
Manufacturer address
6
5 7 For temperature range and max. operating
pressure, see Specifications
Pin assignments
2 1
3 4
5
M12 connector
Pin Function
1 24 V DC
2 Not used
3 GND reference potential
4 Trigger signal input
5 PE protective conductor
module (5) to the base plate (7)
location (3)
location (4)
1
2
3
5
M12 sockets
Function
Not used
Not used
GND reference potential
Switched 24 V DC
PE protective conductor
(see figure).
(Probe) and tighten.
(Cleaning) and tighten.
