D - INST ALLATION

1 - WIRING

• The wiring diagrams for the various configurations can be found in:
- Fig. 7: 1 family – 1 monitor
- Fig. 8: 1 family – 2 monitors
- Fig. 9: 2 families – 1 monitor in each (2 monitors in total)
• Do not increase the number of insulating screw joints or connectors on the connecting wire between the
intercom panel and the monitor.
• To prevent risks of interference and malfunction, do not pass the wire for your videophone through the same
sheath as the electrical wires.
• Keep the connecting wire between the intercom panel and the monitor more than 50 cm away from any
electromagnetic interference (230 V cable, WiFi equipment, microwave ovens, etc.).
• Y ou can connect and use the electric strike plate (not provided) with your intercom panel, with or without
mechanical memory.
• To ensure good audio and video quality, it is advised to not use more than 100 m of cable between the intercom
and the intercom panel. The cable size to be used is shown in Fig. 10.
Warning: Do not under any circumstances double wires to increase the wire size.
• If a wire is incorrectly connected or disconnected after powering up, the entire system must be disconnected
before any intervention. Y our gate can be connected to the power supply again once the defective connection
has been repaired.
Note: if you are testing the product prior to installing it, it is recommended that you place the unit on a flat surface.
2 - INSTALLING THE INTERCOM PANEL
Note: If you test your product before installing it, put the monitor on a flat surface and make sure not to test it with
the intercom panel and the monitor in the same room. If you do so, the videophone will emit a piercing sound
(feedback effect).
Installing the intercom panel (fig. 4, 5.1 and 5.2)
• Remove the screw under the intercom panel (1).
• Tilt the intercom panel forwards (2).
• The lens of the panel must be placed at a height of around 1.60 m (5).
• Firmly attach the weather-proof shield with screws (2) and apply a silicon seal (3) between the shield and the
wall to prevent water from running between the two. *Do not use acetic acid-based silicone (vinegar odour).
• After wiring, fit the intercom panel onto its weather-proof shield (4).
• Re-install the attachment screw (5).
Important: Do not have the camera directly exposed to the sun or facing a reflective surface. At
the same time, remember to properly insert the intercom panel lug in the hole on the weather-proof
shield.
Tip: it is recommended that the wires be passed through a sheath to protect them from
impacts and weather.
Installing the monitor (fig. 4, 6.1 and 6.2)
• Attach the wall bracket so that the screen of the monitor will be around 1.60 m high.
• Connect the wires coming from the intercom panel.
• Insert the adapter wires in the back of the monitor (without plugging it into the wall socket).
Warning: you must comply with the polarity (red and black terminals).
• Install the monitor (1) on the wall bracket.
