F - INTERCOM P ANEL USER MANUAL

1 - DEFAULT CODES

The default codes are as follows:
• 1 1 1 1 1 1 1 1: administrator code (8 x 1)
• 1 0 0 0: opens the gate motor drive
• 2 0 0 0: opens the electric strike plate
By default, the opening pulses are 1 second for the gate motor drive and 1.1 seconds
for the electric strike plate. These values can be changed but are compatible with the vast majority of strike plates
and motor drives on the market. Consult the instruction manual for your particular motor drive.

2 - OPENING THE ELECTRIC STRIKE PLATE OR MOTOR DRIVE

Only the first digit in the codes for opening the strike plate and the motor drive differ. To open, the codes are as
follows:
• 1 + "3- to 7-digit code" + "#" = motor drive opening code
• 2 + "3- to 7-digit code" + "#" = electric strike plate opening code
Example: If the code entered in the next step is 1234
To control the motor drive, press 1 1 2 3 4 + #
To control the electric strike plate, press 2 1 2 3 4 + #
Default:
• 1 0 0 0 # = opens the motor drive
• 2 0 0 0 # = opens the electric strike plate
The "3- to 7-digit code" is the same but may be changed in administrator mode.

3 - CODE MANAGEMENT

In settings, you can exit this mode by waiting for 15 s or pressing the # key 3 times.
If you make a mistake with the code, press the * key before entering the code again.
