Satel SO-MF5 Quick Installation Manual

4
Description of terminals for the standalone door control module
Terminal
NC relay output normally closed contact
C relay output common contact
NO relay output normally open contact
DATA/D1
not used
RSA RS-485 bus terminal [OSDP]
RSB RS-485 bus terminal [OSDP]
TMP tamper output
+12V +12 VDC power input
COM common ground
CLK/D0
not used
IN1 door status input
IN2 request-to-exit input
IN3
not used
BELL OC type output
Hereby, SATEL sp. z o.o. declares that the radio equipment type SO-MF5 is in
compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity
is available at the following internet address: www.satel.pl/ce
SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND
tel. +48 58 320 94 00
www.satel.pl
4
Description of terminals for the standalone door control module
Terminal
NC relay output normally closed contact
C relay output common contact
NO relay output normally open contact
DATA/D1
not used
RSA RS-485 bus terminal [OSDP]
RSB RS-485 bus terminal [OSDP]
TMP tamper output
+12V +12 VDC power input
COM common ground
CLK/D0
not used
IN1 door status input
IN2 request-to-exit input
IN3
not used
BELL OC type output
Hereby, SATEL sp. z o.o. declares that the radio equipment type SO-MF5 is in
compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity
is available at the following internet address: www.satel.pl/ce
SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND
tel. +48 58 320 94 00
www.satel.pl
SO-MF5
Description
SO-MF5
Description
SATEL
SO-MF5
Keypad with MIFARE proximity card reader
Full manual is available on
to our website and download the manual.
The SO-MF5 keypad can operate as:
 INT-SCR partition keypad in the INTEGRA alarm system,
 ACCO-SCR keypad with proximity card reader in the ACCO access control system,
 keypad with proximity card reader in systems of other manufacturers,
 standalone door control module.
Before you mount the keypad, program the settings required for the selected operating mode
in the CR SOFT program. The exception is a keypad that is to operate in the ACCO NET
system and is to be connected to the ACCO-KP2 controller using the RS-485 bus (OSDP
protocol). The OSDP protocol is supported by the ACCO-KP2 controllers with firmware
version 1.01 (or newer). In that case, you can program the required settings in the
ACCO Soft program (version 1.9 or newer).
Installation
The device should be installed by qualified personnel.
Prior to installation, please read the full manual.
Disconnect power before making any electrical connections.
1. Open the keypad enclosure.
2. Connect the keypad to the computer. Use the USB / RS-485 converter (e.g. ACCO-USB
by SATEL). Follow the instructions in the converter manual.
Do not connect more than 24 access control devices with the MIFARE card reader
(SO-MF5, SO-MF3, CR-MF5 and CR-MF3) to the converter. The CR SOFT program
may not be able to support more devices correctly.
3. Program the keypad in the CR SOFT program.
3.1. Create a new project or open an existing project.
3.2. Establish connection between the program and the device.
3.3. Program the settings and upload them to the keypad.
4. Disconnect the keypad from the computer.
5. Run the cables to where you want to install the keypad. To connect the RS-485 bus,
we recommend using a UTP cable (unshielded twisted pair). To make other connections,
use unshielded straight-through cables.
SATEL
SO-MF5
Keypad with MIFARE proximity card reader
Full manual is available on
to our website and download the manual.
The SO-MF5 keypad can operate as:
 INT-SCR partition keypad in the INTEGRA alarm system,
 ACCO-SCR keypad with proximity card reader in the ACCO access control system,
 keypad with proximity card reader in systems of other manufacturers,
 standalone door control module.
Before you mount the keypad, program the settings required for the selected operating mode
in the CR SOFT program. The exception is a keypad that is to operate in the ACCO NET
system and is to be connected to the ACCO-KP2 controller using the RS-485 bus (OSDP
protocol). The OSDP protocol is supported by the ACCO-KP2 controllers with firmware
version 1.01 (or newer). In that case, you can program the required settings in the
ACCO Soft program (version 1.9 or newer).
Installation
The device should be installed by qualified personnel.
Prior to installation, please read the full manual.
Disconnect power before making any electrical connections.
1. Open the keypad enclosure.
2. Connect the keypad to the computer. Use the USB / RS-485 converter (e.g. ACCO-USB
by SATEL). Follow the instructions in the converter manual.
Do not connect more than 24 access control devices with the MIFARE card reader
(SO-MF5, SO-MF3, CR-MF5 and CR-MF3) to the converter. The CR SOFT program
may not be able to support more devices correctly.
3. Program the keypad in the CR SOFT program.
3.1. Create a new project or open an existing project.
3.2. Establish connection between the program and the device.
3.3. Program the settings and upload them to the keypad.
4. Disconnect the keypad from the computer.
5. Run the cables to where you want to install the keypad. To connect the RS-485 bus,
we recommend using a UTP cable (unshielded twisted pair). To make other connections,
use unshielded straight-through cables.
Quick installation guide
www.satel.pl
. Scan the QR code to go
Quick installation guide
www.satel.pl
. Scan the QR code to go
so-mf5_sii_en 04/24
so-mf5_sii_en 04/24
