QUICK START
GUIDE
T SERIES
N SERIES
ACTIVE & HITECH
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Valtra T Series

Summary of Contents for Valtra T Series

  • Page 1 QUICK START GUIDE T SERIES N SERIES ACTIVE & HITECH...

  • Page 2: Valtra Connect

    Direct help with suitable & fast solutions European IT security standards – Ask about retrofit Plan services in advance around seasonal peaks and maximise your uptime. For Valtra G, N and T Series machines. Check now if your machine is ready for Connect: get.agcoconnect.com...

  • Page 3: Table Of Contents

    N & T Series Quick Guide / Active & HiTech VALTRA N & T SERIES YOUR Valtra connect ..........2 Valtra N & T Series Active & Hitech ...3 ACTIVE & HITECH Smart A-pillar display .........4 A-pillar display settings ......6 Valtra ARM & Side panel ......7 A-B-C-D = four speed ranges ....9...

  • Page 4: Smart A-Pillar Display

    N & T Series Quick Guide / Active & HiTech SMART A-PILLAR DISPLAY The brand new Valtra smart A-pillar display brings all the information you need to exactly where you need it. With the essential information always displayed up top in a clear and easy way you’ll never be left searching for what you need to know.
  • Page 5 N & T Series Quick Guide / Active & HiTech SMART A-PILLAR DISPLAY Use the wheel encoder and two buttons to navigate screen Via the settings menu select “Drive Display Mode” and select whether you want two, one or zero displays...

  • Page 6: A-Pillar Display Settings

    N & T Series Quick Guide / Active & HiTech A-PILLAR DISPLAY SETTINGS Settings are now easy to make with the A pillar display. Clear text and graphics tell you what to do. There are settings for engine, transmission, PTO , hydraulic (front valves), counter,...

  • Page 7: Valtra Arm & Side Panel

    N & T Series Quick Guide / Active & HiTech VALTRA ARM & SIDE PANEL DRIVER’S ARMREST AND MAIN CONTROLS Basic controls Valtra ARM Front hydraulics on/off button HiShift push button Button for hydraulic implement locking Range speed push button...
  • Page 8 N & T Series Quick Guide / Active & HiTech Emergency brake button / lever in DE Hydraulic control lever 1 Hydraulic control lever 2 Hydraulic control lever 3 Hydraulic control lever 4 Switch for 4WD Fuel-operated heater in-cab start button...

  • Page 9: A-B-C-D = Four Speed Ranges

    N & T Series Quick Guide / Active & HiTech A-B-C-D = FOUR SPEED RANGES Four speed ranges – less strain = increased efficiency. With a choice of speed ranges YOU can set the transmission to work as effectively as possible, cutting fuel usage and increasing component life.

  • Page 10: How To Select Speed Range

    N & T Series Quick Guide / Active & HiTech HOW TO SELECT SPEED RANGE Valtra ARM Basic controls Selecting the correct speed range for the task means that the tractor will perform best of its ability. TO CHANGE RANGE Simply push + or - button located on gear lever or use the lower rocker switch on the basic handle.

  • Page 11: How To Select Powershift Gear

    N & T Series Quick Guide / Active & HiTech HOW TO SELECT POWERSHIFT GEAR Valtra ARM Basic controls To change the Powershift gear in manual mode (move gear lever to the left position) simply push the gear lever forward to increase the Powershift gear or backward to decrease the Powershift gear.

  • Page 12: Driving With Gear Lever

    N & T Series Quick Guide / Active & HiTech DRIVING WITH GEAR LEVER DRIVING VALTRA HITECH AND ACTIVE IS EXTREMELY EASY Valtra ARM Basic controls Start the engine with the clutch pedal depressed and release the clutch pedal. Select the desired range (C-range is default).

  • Page 13: Auto Shift

    N & T Series Quick Guide / Active & HiTech AUTO-SHIFT (AUTO 1, AUTO 2) This feature lets the tractor manage the gear changes within a range, Basic controls or if selected from settings, including changing the range automatically when required. When driving with Auto 1 the accelerator pedal is changing into drive pedal.

  • Page 14: Features

    N & T Series Quick Guide / Active & HiTech FEATURES POWERSHIFT REVOLUTION Your Valtra tractor is packed with features to make your working day easier…. LIMITING MAX. POWERSHIFT GEAR (not with basic controls) Limit max desired powershift gear with the push button next to the gear lever.

  • Page 15: Autotraction

    N & T Series Quick Guide / Active & HiTech POWERSHIFT REVOLUTION AUTOTRACTION STANDARD FEATURE Standard AutoTraction - a feature that revolutionizes the driving of a powershift tractor. With a Active or HiTech tractor you need the clutch pedal only when starting the engine. Otherwise you need only brakes and drive pedal for controlling the tractor.

  • Page 16: Hillhold

    N & T Series Quick Guide / Active & HiTech POWERSHIFT REVOLUTION HILLHOLD STANDARD FEATURE The new HillHold function is a standard feature in Active and HiTech tractors. With this function you don’t have to keep the brakes pressed down when the tractor is standing still in up- or downhill, for example when waiting for turn in a junction.

  • Page 17: Ecopower Mode

    N & T Series Quick Guide / Active & HiTech ECOPOWER-MODE Only on N155e and T175e models ECO mode is designed especially for work that requires high torque, but not constant engine revs e.g. pulling work on the field. With EcoPower the tractor will give highest torque already at very low engine revs.

  • Page 18: Cruise Control

    N & T Series Quick Guide / Active & HiTech CRUISE CONTROL (with Valtra ARM) Traditionally most drivers have used the hand throttle to hold a steady speed, especially on the road. Cruise disengages automatically when clutch or brakes are depressed.

  • Page 19: Engine Rpm Cruise

    N & T Series Quick Guide / Active & HiTech ENGINE RPM CRUISE Valtra ARM Basic controls Valtra Active and HiTech have cruise control also for engine RPM that will keep engine RPM constant regardless of speed. Engine RPM cruise can be stored whilst stationary or moving.

  • Page 20: Machine Hydraulics - Front

    N & T Series Quick Guide / Active & HiTech ENGINE BRAKING Engine braking can be done normally in manual mode, keeping small enough gear and powershift step engaged In AUTO 1 the engine braking can be set to work automatically GO TO ENGINE SETTINGS Rotate the scroll wheel to select between 1 and 5.

  • Page 21: Hydraulics Assistant

    N & T Series Quick Guide / Active & HiTech HYDRAULICS POWERSHIFT REVOLUTION HYDRAULIC FRONT HYDRAULICS ASSISTANT (with Valtra ARM) STANDARD FEATURE WITH You can use joystick to control front valves. FRONT VALVES Every time tractor is turned on, the spools must...

  • Page 22: Hydraulics - Rear

    N & T Series Quick Guide / Active & HiTech HYDRAULICS HYDRAULICS REAR VALVES ADJUSTING REAR VALVES In HiTech you have Open Centre and in Active Depending on your hydraulics lay-out you Load Sensing hydraulics with mechanically are able to adjust the rear spool valves controlled rear valves.

  • Page 23: Hydraulics - Front Valve Operations

    N & T Series Quick Guide / Active & HiTech HYDRAULICS FRONT VALVE OPERATIONS Front valves are fully adjustable via A-pillar display SETTING OF FRONT VALVE FROM A-PILLAR DISPLAY, HYDRAULICS SETTINGS Hydraulic assistant (ON/OFF) Then select which front valve to be set...
  • Page 24 N & T Series Quick Guide / Active & HiTech HYDRAULICS FRONT VALVE OPERATIONS FLOW ADJUSTMENT OF EACH FRONT VALVE Select valve Plus (+) Port Max Flow Minus (-) Port Max Flow Plus (+) Port (valve Function) Certain function time or Continuous...

  • Page 25: Rear Controls And Connections

    N & T Series Quick Guide / Active & HiTech REAR CONTROLS AND CONNECTIONS Front linkage shut-off valve (optional) Trailer coupling, Duo-Matic (optional) Trailer socket for trailer with ABS brakes Trailer coupling, 2-line system (optional) Trailer socket Quick coupling for air pressure devices (optional)

  • Page 26: Asr - Automatic Slip Regulator

    N & T Series Quick Guide / Active & HiTech ASR - AUTOMATIC SLIP REGULATOR Automatic Slip Regulator (ASR, Option), which offers a completely new way of managing wheel slip, when working on the field or in slippery conditions. ASR uses the radar to measure the ground speed and the wheel sensor to calculate the wheel slip.

  • Page 27: Pick-Up Hitch And Linkage

    N & T Series Quick Guide / Active & HiTech PICK-UP HITCH TO UNLOCK THE PICK-UP HITCH: Press the symbol side of the lifting/lowering switch to fully raise the linkage. Pull the hitch latch lever open to unlatch the hitch.

  • Page 28: Pulling Work On The Field

    N & T Series Quick Guide / Active & HiTech Valtra ARM Basic controls PULLING WORK ON THE FIELD HIGH NEED FOR POWER, LOWER SPEED Start the engine. Select the range B using the + and – buttons. Switch 4WD ON (symbol side position) and set differential lock to AUTO.

  • Page 29: Transport On The Road

    N & T Series Quick Guide / Active & HiTech Valtra ARM Basic controls TRANSPORT ON ROAD HIGH NEED FOR SPEED, TEMPORARY NEED FOR FULL POWER Start the engine. Select the desired range according to the situation (max C-range always when start driving).

  • Page 30: Pto Work Auto 1

    N & T Series Quick Guide / Active & HiTech Valtra ARM Basic controls PTO WORK AUTO 1 PTO USE – HIGH POWER NEEDED – MEDIUM/HIGH SPEEDS Start the engine. Select work area B or C. Select PTO speed and start PTO.

  • Page 31: Front Loader Work

    N & T Series Quick Guide / Active & HiTech Valtra ARM Basic controls FRONT LOADER WORK Start the engine with the clutch pedal depressed. Select the desired range (B or C recommended). Move the shuttle to the forward/reverse position to initiate drive.
  • Page 32 AGCO Valtra Inc. Valmetinkatu 2 Tel. +358 (0)2045 501 FI-44200 Suolahti www.valtra.com...
