- Page 1 AXI8, AXI9 USER’S MANUAL Air Curtain AXI 8, AXI 9 USER'S MANUAL Email: sales@stavoklima.com.sa Tel: + 966 (011) 22 00 313 Fax: + 966 (011) 22 00 313 Ext. 116 www.stavoklima.com.sa STAVOKLIMA s.r.o. MPN-AXI-CZ-2022...
-
Page 2: Table Of Contents
9.4 ON/OFF Indicator ......................35 9.5 Door Contact ......................... 35 10.0 Maintenance ........................36 10.1 Fan maintenance ......................37 10.2 Maintenance schedule ....................37 11.0 Troubleshooting ......................39 12.0 Important Warnings ......................40 13.0 Contact Info ........................40 STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... -
Page 3: Foreword
Customer’s satisfaction is our highest priority. The core component of every air curtain are the fans. Inside every Stavoklima unit you will find long-lasting maintenance-free fans from the World fan industry leader – German company Ziehl-Abegg. -
Page 4: Introduction
(splashing water from multiple directions). The unit is fully capable of running 24/7 in temperatures ranging from -25°C to +50°C. Default finish is RAL 7035 (light gray) or stainless steel for an additional cost. STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... -
Page 5: Dimensions
AXI8, AXI9 USER’S MANUAL 3.1 Dimensions STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... -
Page 6: Product Info
The height of suspension is informative and has to be considered according to building conditions. The AXI air curtain houses axial fans with outstanding performance and industrial-grade durability (IP protection level 54). IP54 protection level definition (fans + electrical connector box) STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... -
Page 7: Technical Parameters
2,4/1,3 3,0/2,1 IP protection level Controller type industrial industrial Outlet width Noise level at 5 m Weight fans: safety margin 15% for 60 Hz voltage frequency technical data can differ according to product models and installed components STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... - Page 8 Δ/Y A IP protection level Controller type industrial industrial Outlet width Noise level at 5 m Weight fans: safety margin 15% for 60 Hz voltage frequency technical data can differ according to product models and installed components STAVOKLIMA s.r.o. MPN-AXI-CZ-2022...
-
Page 9: Package Contents
Wall suspension (2x) with M8 screws (4x) Allen key – size 6 (1x) Screw driver (1x) RT industrial wall controller (1x) Not part of the packaging Mechanical door contact (1x) Not part of the packaging User’s manual (1x) STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... -
Page 10: Unboxing
RECYCLING: Please recycle the packaging in compliance with your local environmental standards. STORAGE: Storage conditions for unopened packaging is temperature range from -10 °C to+50 °C, humidity 50-85% non-condensing. STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... -
Page 11: Safety Precautions
– degrees of combustibility. Install the unit 150 mm from combustible materials of classes B, C1, C2, 400 mm from easily combustible materials (class C3), and 1000 mm in the direction of radiation (air outlet of the unit). STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... -
Page 12: Unit Description
Air curtain backplate with fan collars for better airflow and ErP 2015 compliance Air curtain chassis Axial fans with connector boxes Main connector box (loosely stored within the packaging) Connecting material (screws) Air curtain outlet with positionable louvre STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... -
Page 13: Installation
Follow all local safety regulations and use common sense to avoid injury of self or others. For proper performance, please respect recommended maximal mounting heights/widths. WARNING: Installation is performed at one's own risk. Any damage resulting from inappropriate handling is not covered by the warranty. STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... -
Page 14: Required Tools
Not part of the packaging Screwdriver (1x) or multi-purpose tool Meter measure (1x) Not part of the packaging WARNING: Any damage resulting from the use of unsuitable tools or inadequate fasteners is not covered by the warranty. STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... -
Page 15: Connection Kit
The connection kit consists of 4 pieces of triangle-shaped profiles, 12 pieces of M8x30 screws, 4 pieces of M8 nuts, 12 pieces of spring washers – size 8 and 12 pieces of washers – size 8. connection profile 12 x STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... - Page 16 Securing the top of the vertically-mounted unit to the wall The connection kit is assembled using supplied screws and attached to the air curtain using supplied screws. The air curtain has threaded rivets at designated spots for connection kit. STAVOKLIMA s.r.o. MPN-AXI-CZ-2022...
-
Page 17: Silent Blocks
The connection kit consists of 4 pieces of M8x30 silent blocks, 4 pieces of M8 nuts, 4 pieces of spring washers – size 8, 4 pieces of washers – size 8 and 4 pieces of cylindrical spring. STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... - Page 18 AXI8, AXI9 USER’S MANUAL The silent blocks have M8 thread that requires corresponding connection diameter in the floor. Use equivalent form of floor anchor with M8 nut to establish a firm connection to the silent blocks. STAVOKLIMA s.r.o. MPN-AXI-CZ-2022...
-
Page 19: Electro-Connection Box
Use the supplied self-tapping screws to mount the electroconnection box onto the unit at a suitable location. Screwing in the self-tapping screws STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... -
Page 20: Wall Mounting
9) Tighten the screws. If done properly, the wall bracket should be tightly attached to the wall. 10) Use supplied screws to attach the air curtain to the wall bracket and tighten all the screws using the supplied Allen key. Drilling spacing and recommended mounting STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... - Page 21 OPTIMAL MOUNTING: In order to achieve the best performance, make sure the unit is centered above the door, it covers the entire width of the door and it is mounted in proximity of the top of the door. The offset of the door should be minimal. STAVOKLIMA s.r.o. MPN-AXI-CZ-2022...
- Page 22 AXI8, AXI9 USER’S MANUAL There are two alternative mounting options for the supplied wall brackets: Standard mounting Reverse mounting STAVOKLIMA s.r.o. MPN-AXI-CZ-2022...
-
Page 23: Ceiling Mounting
9) Attach the hinge eyes at the ends of threaded rods to the air curtain using the supplied screws and tighten all the screws using the supplied Allen key. The ceiling threaded rods use 4 connection points (threaded rivets) located on the top of the left and right side panel: STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... - Page 24 OPTIMAL MOUNTING: In order to achieve the best performance, make sure the unit is centered above the door, it covers the entire width of the door and it is mounted in proximity of the top of the door. The offset of the door should be minimal. STAVOKLIMA s.r.o. MPN-AXI-CZ-2022...
-
Page 25: Custom Horizontal Mounting
8.7 Custom Horizontal Mounting In situations where none of the above-described methods is applicable, a custom solution may be required. Contact your local Stavoklima supplier for more information. 8.8 Vertical Mounting Vertical mounting is more suitable for situations where the height of the door exceeds the width and the vertical installation is not compromised by insufficient space around the door, suboptimal offset or nature of the door (e.g. - Page 26 AXI8, AXI9 USER’S MANUAL STAVOKLIMA s.r.o. MPN-AXI-CZ-2022...
- Page 27 Make sure the air curtain covers the entire height of the door. The offset of the door should be minimal. If units are installed on both sides of the door, the outlets are to be positioned directly against each other. STAVOKLIMA s.r.o. MPN-AXI-CZ-2022...
-
Page 28: Minimal Distances
Respect the minimal distances from the ceiling and the wall in order to use the full potential of the unit. Regardless the mounting orientation, always make sure the inlet of the air curtain is at least one fan diameter distant from the wall or ceiling: STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... -
Page 29: Connecting The Unit
If you detect any damage, do not connect the unit and contact the supplier. Any damage resulting from inadequate handling is not covered by the warranty. STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... - Page 30 AXI8, AXI9 USER’S MANUAL Wiring diagram STAVOKLIMA s.r.o. MPN-AXI-CZ-2022...
- Page 31 It is meant to be mounted on the door frame with the wheel intersecting the opening radius of the door. The distance of the sensor wheel and the door edge should be as close as conditions allow. Installation spots on sliding and standard door Mechanical Door contact STAVOKLIMA s.r.o. MPN-AXI-CZ-2022...
-
Page 32: Commission
From this point the fans of the unit should be working and air should be coming out of the unit’s outlet. STARTUP ISSUES: If you encounter difficulties commissioning the unit, refer to the Troubleshooting chapter (11.0) prior to contacting the supplier. Follow the steps! STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... -
Page 33: Wall Controller
The air curtain reacts to turning of the fan speed controller switch. The controller is universal and can be used to control multiple Stavoklima air curtains, provided that the total amperage capacity of the controller is not exceeded. -
Page 34: Control
Zero fan speed level The fans are set OFF Fist fan speed level The fans are set on low speed Fist fan speed level The fans are set on high speed STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... -
Page 35: On/Off Indicator
Minute setting – minutes Range from 3 minutes to 60 minutes 10 h Long-lasting setting – hours Range from 30 minutes to 10 hours 100 h Ultra-long setting – hours Range from 5 hours to 100 hours STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... -
Page 36: Maintenance
Such damage is not covered by the warranty. WARNING: Disconnect the unit from electrical supply prior to any work on the device. Risk of electric shock and/or injury. STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... -
Page 37: Fan Maintenance
(once a month) is recommended. The environments with high density of airborne particles would require more frequent maintenance. Do not use a chemicallytreated duster, benzene, thinner, polishing powder, or similar solvents for wiping. It may damage or fade the surface of the unit. STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... - Page 38 Check the mounting of the door contact. If necessary, relocate it to a more secure position. WARNING: Disregarding the maintenance schedule may result into poor performance or irreversible damage to the unit. Such damage is not covered by the warranty. STAVOKLIMA s.r.o. MPN-AXI-CZ-2022...
-
Page 39: Troubleshooting
There are factors that can have negative impact the air barrier generated by the air curtain ‒ for example chimney effect, pressure difference, draft, etc. These factors need to be minimized in order to provide best conditions for the air curtain to function properly. STAVOKLIMA s.r.o. MPN-AXI-CZ-2022... -
Page 40: Important Warnings
Installation, wiring and repairs must be performed by qualified personnel in accordance with applicable country-specific regulations and standards. 13.0 Contact Info STAVOKLIMA Saudi Email: sales@stavoklima.com.sa Tel: + 966 (011) 22 00 313 Fax: + 966 (011) 22 00 313 Ext. 116 www.stavoklima.com.sa...
