- Page 1 A I R H E A T I N G U N I T S T A V O K L I M A Installation and operation manual Warmex model www.stavoklima.cz version B...
-
Page 2: Table Of Contents
Installation and operation manual Table of Contents Table of Contents ................................2 Unpacking, check after transport or warehousing ......................3 Unpacking and check .............................. 3 Storing of the unit, additional transport recommendations ................... 3 Safety measures ................................4 Basic information about the unit and its use ........................4 Dimensions of the unit .............................. -
Page 3: Unpacking, Check After Transport Or Warehousing
Warmex heating unit Unpacking, check after transport or warehousing Unpacking and check Carefully check the delivery note attached to the delivery. For components identified as extra accessories in the delivery note (not included in the unit or installed therein), please check completeness to the parcel and perfect condition (usually delivered in a separate box). -
Page 4: Safety Measures
Installation and operation manual Safety measures The unit has been manufactured in line with the government decrees and Czech standards harmonized with the EU regulations mentioned in the manufacturer’s declaration of conformity. The above mentioned product complies with the following standards: ČSN EN 60335-1 ed.3 ČSN EN 60335-2-30 ed. -
Page 5: Dimensions Of The Unit
Warmex heating unit Dimensions of the unit Dimension (mm) Model Warmex 0 3/4“ Warmex 1 3/4“ Warmex 2 1170 5/4“ Unit installation Installation ceiling Installation under ceiling Technical changes reserved... -
Page 6: Suspensions Ceiling
Installation and operation manual Suspensions ceiling The heating unit is suspended through the suspension holes accessible from the outside on the beams. Measure position of the unit, mark the anchoring points and drill holes in the ceiling for installation of wall plugs (not included in the supply). -
Page 7: Connection Of The Unit To Heating System
Warmex heating unit Pay attention to correct fitting of all nuts to all assembly components. Pay attention to the end position of the threads to avoid loosening and falling the unit by rotation. Use quality anchors and wall plugs only. Consider installation situation and suitability of anchoring and installation material, including loading capacity of the structure properly. -
Page 8: Heat Exchanger Control Using A Valve With Thermostatic Heat
Installation and operation manual Instructions for electric connection of the valve is included in the wiring scheme for connection of the unit. Specific wiring scheme or valve instructions are available upon request only. Connection of 2-way TV, Connection of 3-way TV, ETVT ETVQ valve valve Heat exchanger control using a valve with thermostatic heat... -
Page 9: Setting Of Independent Valve Flow Pressure (Etvq)
Warmex heating unit Setting of independent valve flow pressure (ETVQ) Setup Closing Turn the setting wheel to required value, e.g., 5.0. Turn the setting wheel counterclockwise to position X. values Setup DN 20 1080 1150 DN 25 1050 1270 1490 1720 1870 2050... -
Page 10: Commissioning, Starting Of The Unit
Installation and operation manual Commissioning, starting of the unit Before commissioning make and check: covers and shell of the unit are in perfect condition, mechanic fixing and anchoring of the unit, fixing of thermostatic head and its setting,* ... -
Page 11: Troubleshooting
Warmex heating unit Re-test tightness of the unit or of installed fittings on the water side. If a sludge filter is installed before the unit – clean the filter and check deaeration of the heat exchanger. Check unit safety with respect to electric shock hazard according to applicable ČSN or national standards, including earthing inspection. - Page 12 Installation and operation manual STAVOKLIMA s.r.o. Budějovická 450, 370 01 Homole Tel.: +420 387 001 931 e-mail: info@stavoklima.cz www.stavoklima.cz Technical changes reserved...
