Free Standing Gas Cooker
Installation and Operating Instructions
To avoid the risk of accidents or damage to the Gas Cooker,
it is essential to read these operating instructions
before it is installed or used for the first time.
And please keep this manual for later reference.
LF96105SS
LF66105SS
P/No.: MFL62060304

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LF66105SS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Smeg LF66105SS

Summary of Contents for Smeg LF66105SS

  • Page 1 To avoid the risk of accidents or damage to the Gas Cooker, it is essential to read these operating instructions before it is installed or used for the first time. And please keep this manual for later reference. LF96105SS LF66105SS P/No.: MFL62060304...

  • Page 2: Table Of Contents

    Contents Introduction ... 3 1. Instructions for safe and proper use ...3 Instructions for the installer ... 6 2. Installation of the appliance ...6 3. Adaptation to different types of gas ...11 4. Final operations ...14 Instructions for the user ... 17 5.

  • Page 3: Introduction

    Introduction 1. Instructions for safe and proper use This manual is an integral part of the appliance and therefore must be kept in its entirety and in an accessible place for the whole working life of the cooker. We advise reading this manual and all the instructions therein before using the cooker.
  • Page 4 Introduction DO NOT MODIFY THIS APPLIANCE When not in use, make sure that the control knobs are in the correct (OFF) position ● ● . Never put inflammable objects in the oven: They could be accidentally catch fire and burn. The I.D plate with technical date, serial number and brand name is positioned visibly in the storage compartment.
  • Page 5 Where this appliance is installed in marine craft or in caravans, it shall not be used as a space heater. Do not apply decorative panels to the lower part of the cooker as they may prevent correct air circulation and cause overheating. Before the appliance is put into operation, all the labels and protective films applied inside or outside must be removed.

  • Page 6: Instructions For The Installer

    Instructions for the installer 2. Installation of the appliance It is the law that all gas appliances are installed by authorised persons. Clearance around the cooker must comply with the requirements of AS5601. The manufacturer declines all responsibility for damage to persons or things caused by non-observance of the above prescriptions or by interference with any part of the appliance.
  • Page 7 2.1 Electrical connection Make sure that the power line voltage matches the specifications indicated on the rating plate located inside the storage compartment. This rating plate must never be removed. If the appliance is connected to the supply by means of a fixed connection, install a multipolar cut-out device on the line, with contact opening distance equal to or greater than 3 mm, located near the appliance and in an easily reachable position.
  • Page 8 Instructions for the installer 2.2 Gas connection Use pipe-joint compound made for use with Natural and U.L.P. gas. This appliance is suitable for installation with Natural Gas or ULPG (propane). Refer to page 12 for the relevant burner pressure and appropriate injector sizes.
  • Page 9 U.L.P.G: Can be connected to the inlet fitting directly. The pressure must be checked to ensure it is operating at 2.75kPa. A separate test point fitting must be installed between the piping & the appliance for the pressure to be checked to ensure it is operating at 2.75kPa. Make the connection to the gas mains using a continuous wall flexible steel pipe whose specifications comply with the current regulations.
  • Page 10 Instructions for the installer 2.5 Clearance above and around domestic cookers Extract from AS5601 REQUIREMENTS 1. Overhead clearances – (Measurement A) Range hoods and exhaust fans shall be installed in accordance with the manufacturer’s instructions. However, in no case shall the clearance between the highest part of the hob of the cooking appliance and a range hood be less than 600 mm or, for an overhead exhaust fan, 750 mm.

  • Page 11: Adaptation To Different Types Of Gas

    a height C of not less than 150 mm above the hob for the full dimension (width or depth) of the cooking surface area. Where the cooking appliance is fitted with a ‘splashback’, protection of the rear wall is not required. 3.
  • Page 12 Instructions for the installer 3.1 Replacement of nozzles on the hob This operation requires no primary air regulation. 1. Extract the grids and remove all the caps and flame-spreader crowns; 2. unscrew the burner nozzles with a 7 mm socket wrench; 3.
  • Page 13 3.3 Arrangement of the burners on the hob (Mod. 90 cm.) 3.4 Arrangement of the burners on the hob (Mod. 60 cm.) BURNERS 1. Auxiliary 2. Semi rapid 3. Rapid 4. Triple crown BURNERS 1. Auxiliary 2. Semi rapid 3. Rapid 4.

  • Page 14: Final Operations

    Instructions for the installer 4. Final operations After replacing the nozzles, reposition the flame-spreader crowns, the burner caps and the grids. Following adjustment to a gas other than the preset one, replace the gas adjustment label fixed to the appliance with the one corresponding to the new gas.
  • Page 15 4.3 Mounting the rear top skirtboard (where applicable) • Loosen nuts B. • Position the skirt above the top, taking care to align pins C with holes D. • Secure the skirt to the top by tightening screws A. 4.4 Instruction for Wall fixing 1.
  • Page 16 Instructions for the installer 2. Attach the chain to the cooker. 3. Stretch out the chain attached to the cooker horizontally so that the other end touches the wall. 4. Mark the wall in the position where the hole is to be drilled. 5.

  • Page 17: Instructions For The User

    Instructions for the user 5. Description of controls 5.1 Front control panel All the cooker controls and commands are on the front panel. If the cooker is equipped with an electronic programmer, before using the oven make sure that the symbol display.
  • Page 18 Instructions for the user VARIABLE GRILL KNOB This allows to vary heat intensity when cooking with the grill. The knob can be set with continuity between “ ” and the stop release position, which corresponds to maximum heat. ELECTRIC OVEN CONTROL KNOB Each of the functions listed below can be used (except the oven light and the small grill) only together with the correct temperature thermostat...

  • Page 19: Use Of The Hob

    6. Use of the hob 6.1 Lighting of the hob burners Before lighting the hob burners check that the flame caps are in the correct position and that their burner caps are in place, making sure that the holes A in the flame caps correspond to the spark plugs and thermocouples.
  • Page 20 Instructions for the user 6.2 Practical advice for using the hob burners For better use of the burners and lower gas consumption, use covered vessel that are proportional in size to the burner to prevent the flame from heating the sides (see paragraph “6.3 Diameter of the vessels to be used on each burner”).
  • Page 21 6.3 Diameter of the vessels to be used on each burner BURNERS 1. Auxiliary 2. Semi rapid 3. Rapid 4. Triple crown Ø min. and max. (in cm) 12-14 16-24 18-26 18-26...

  • Page 22: Use Of The Oven

    Instructions for the user 7. Use of the oven For the models with electronic programmer, before using the oven make sure that the display shows the symbol 7.1 Warnings and general advice Using the oven and the grill for the first time, heat them to the maximum temperature (260°C) for as long as it takes to burn off any production oil residues which could give a nasty flavour to the food.
  • Page 23 7.2 Use of the electric grill For short cooking times, for example for browning already-cooked meat, select the static grill function ; set the thermostat knob to maximum temperature (260°C) and adjust grill intensity by means of the variable grill knob. The ventilated grill function allows actual cooking to be done, thanks to the forced ventilation which lets heat penetrate inside the food.
  • Page 24 Instructions for the user 7.2.2 Using the rotisserie in cookers with maxi oven Fit the supporting frame onto the second runner up from the bottom so that the seat to take the rod projects outside the oven. Place the rod as shown in the diagram (1) and push the frame into the oven until the end of the rod reaches the hole in the rotisserie...
  • Page 25 7.3 Storage compartment A storage compartment, accessible by pulling on the top edge of the door, is located beneath the oven. Never store inflammable materials such as rags, paper or the like. The compartment is intended only for holding the metal accessories of the range. The inside of the compartment becomes very hot during operationof the oven: turn off the oven and let it cool down before opening the compartment door.

  • Page 26: Electronic Programmer (Only On Equipped Models)

    Instructions for the user 8. Electronic programmer (Only on equipped models) LIST OF FUNCTIONS Minute-Counter key Cooking time key End-of-Cooking key Decrease time key Increase time key 8.1 Clock adjustment When using the oven for the first time, or after a power failure, the display flashes regularly and indicates 0:00 .
  • Page 27 8.2 Semiautomatic cooking Use this setting for automatic oven switch-off at the end of cooking time. By pressing key , the display lights up, showing 0:00 ; keep the key pressed and at the same time, press keys cooking time. Release key to start the programmed cooking time count.
  • Page 28 Instructions for the user 8.4 End of cooking When cooking is over, the oven will automatically switch off and, at the same time, an intermittent alarm will sound. After switching off the alarm, the display will once again show the right time together with the symbol , indicating that the oven has returned to manual operation mode.

  • Page 29: Available Accessories

    9. Available accessories The oven has 4 support for positioning plates and racks at various heights. Oven grill: for cooking food on plates, small cakes, roasts or food requiring light grilling. Plate grill: for placing above plate for cooking foods that might drip. Oven plate: useful for catching fat from foods on the grill above.

  • Page 30: Cleaning And Maintenance

    Instructions for the user 10. Cleaning and maintenance 10.1 Cleaning stainless steel and enamelled versions To maintain stainless steel in good condition clean it regularly after each use, once it has cooled down. 10.1.1 Ordinary daily cleaning To clean and preserve the stainless steel surfaces, always use only specific products that do not contain abrasives or chlorine-based acids.
  • Page 31 10.2.2 Burner caps and flame cap crowns The caps and flame-spreader crowns are extractable to facilitate cleaning. Wash them in hot water with non-abrasive detergent, taking care to remove any encrustations, and wait until they are perfectly dry. WARNING: do not wash these components in the dishwasher.
  • Page 32 Instructions for the user 10.3 Cleaning of oven For best oven upkeep clean regularly after having allowed to cool. Take out all removable parts. • Clean the oven grill with hot water and non-abrasive detergent. Rinse and dry. • Do not allow residues of sugary foods (such as jam) to set inside the oven.

  • Page 33: Extraordinary Maintenance

    11. Extraordinary maintenance The oven may require extraordinary maintenance or replacement of parts subject to wear such as seals, bulbs, and so on. The following instructions describe how to carry out these minor maintenance operations. Before any intervention, disconnect the power supply of the device.
  • Page 36 FOR WARRANTY SERVICE PLEASE CONTACT LG Service on 1300 LG CARE (1300 54 2273) AUSTRALIA or 0800 LG CARE (0800 54 2273) NEW ZEALAND LG Electronics Australia 2 Wonderland Drive Eastern Creek NSW 2766 (ABN : 98 064 531 264) LGEAP...
