Smeg A11A-6 Instruction Manual

Smeg gas cooktop instruction manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

1.
2.
INSTALLATION OF THE APPLIANCE_________________________ 6
3.
4.
FINAL OPERATIONS _____________________________________ 13
5.
DESCRIPTION OF CONTROLS ____________________________ 15
6.
USE OF THE COOKING HOB ______________________________ 21
7.
USE OF THE OVEN ______________________________________ 23
8.
AVAILABLE ACCESSORIES _______________________________ 24
9.
COOKING HINTS ________________________________________ 25
10.
CLEANING AND MAINTENANCE ___________________________ 29
11.
EXTRAORDINARY MAINTENANCE _________________________ 32
THESE INSTRUCTIONS ARE VALID ONLY FOR END USER COUNTRIES WHOSE
IDENTIFICATION SYMBOLS APPEAR ON THE COVER OF THIS MANUAL.
INSTRUCTIONS FOR THE INSTALLER: these are for the qualified
technician who must carry out a suitable check of the gas system,
install the appliance, set it functioning and carry out an inspection test.
INSTRUCTIONS FOR THE USER: these contain user advice,
description of the commands and the correct procedures for cleaning
and maintenance of the appliance.
Contents
3

Advertisement

Table of Contents
loading

Related Manuals for Smeg A11A-6

Summary of Contents for Smeg A11A-6

  • Page 1: Table Of Contents

    INSTRUCTIONS FOR SAFE AND PROPER USE________________ 4 INSTALLATION OF THE APPLIANCE_________________________ 6 ADAPTATION TO DIFFERENT TYPES OF GAS _______________ 11 FINAL OPERATIONS _____________________________________ 13 DESCRIPTION OF CONTROLS ____________________________ 15 USE OF THE COOKING HOB ______________________________ 21 USE OF THE OVEN ______________________________________ 23 AVAILABLE ACCESSORIES _______________________________ 24 COOKING HINTS ________________________________________ 25 CLEANING AND MAINTENANCE ___________________________ 29...

  • Page 2: Instructions For Safe And Proper Use

    Introduction 1. INSTRUCTIONS FOR SAFE AND PROPER USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE AND THEREFORE MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE COOKER. WE ADVISE READING THIS MANUAL AND ALL THE INSTRUCTIONS THEREIN BEFORE USING THE COOKER.
  • Page 3 Introduction DO NOT INSTALL THIS APPLIANCE ON A RAISED PLATFORM. THE I.D. PLATE WITH TECHNICAL DATA, REGISTRATION NUMBER AND BRAND NAME IS POSITIONED VISIBLY IN THE STORAGE COMPARTMENT. THE PLATE MUST NOT BE REMOVED. DO NOT PUT PANS WITHOUT PERFECTLY SMOOTH AND FLAT BOTTOMS ON THE COOKING HOB GRIDS.

  • Page 4: Installation Of The Appliance

    Instructions for the installer 2. INSTALLATION OF THE APPLIANCE It is the law that all gas appliances are installed by authorised persons. Clearance around the cooker must comply with the requirements of AS5601. 2.1 Electrical connection Make sure that the power line voltage matches the specifications indicated on the rating plate located inside the storage compartment.

  • Page 5: Gas Connection

    Instructions for the installer 2.2 Gas connection This appliance is suitable for installation with Natural Gas or LPG (propane). Refer to page 12 for the relevant burner pressure and appropriate injector sizes. When the appliance is to be connected to Natural Gas then the pressure regulator supplied must be fitted to the gas inlet.
  • Page 6 Instructions for the installer 2.3 Room ventilation Caution – This cooker may only be installed and operated in rooms permanently ventilated in accordance with current regulations. For proper operation of a gas appliance it is essential for the air necessary for combustion of the gas to be able to flow naturally into the room.
  • Page 7 Instructions for the installer 1 Overhead clearances – (Measurement A) Range hoods and exhaust fans shall be installed in accordance with the manufacturer’s instructions. However, in no case shall the clearance between the highest part of the hob of the cooking appliance and a range hood be less than 600 mm or, for an overhead exhaust fan, 750 mm.
  • Page 8 Instructions for the installer 2.5 Instruction for wall fixing Fix the screw to the wall and hook the chain (B); Hook the chain to the hole positioned at the rear of the cooker by the gas pipe (A); Once the chain is in position, push the cooker against the wall; The height of the screw hole from floor level must not exceed 800 mm (C).

  • Page 9: Adaptation To Different Types Of Gas

    Instructions for the installer 3. ADAPTATION TO DIFFERENT TYPES OF GAS Before performing any cleaning or maintenance work, detach the appliance from the electrical socket. The cooker hob is set for natural gas G20 (2H) at a pressure of 20 mbar. In the case of functioning with other types of gas the burner nozzles must be changed and the minimum flame adjusted on the gas taps.

  • Page 10: Burner And Nozzle Characteristics Table

    Instructions for the installer 3.2 Burner and nozzle characteristics table Nominal gas Burner consumption (MJ/h) Auxiliary Semi-rapid Rapid 10.8 13.5 Fish pan Nominal gas Burner consumption (MJ/h) Auxiliary Semi-rapid Rapid Fish pan 3.3 Arrangement of burners on cooking hob LPG – 2.75 kPa Turn-down gas consumption (MJ/h)

  • Page 11: Final Operations

    Instructions for the installer 4. FINAL OPERATIONS After replacing the nozzles, reposition the flame-spreader crowns, the burner caps and the grids. After adjustment to a different kind of gas from the one for which the cooker has been tested, replace the plate inside the storage compartment with one corresponding to the new kind of gas.
  • Page 12 Instructions for the installer Mounting the rear top upstand • Position the upstand above the top, taking care to align holes A with holes B. • Secure the upstand to the top by tightening screws C.

  • Page 13: Description Of Controls

    Instructions for the user 5. DESCRIPTION OF CONTROLS 5.1 Front control panel All the cooker controls and commands are on the front panel. DESCRIPTION OF SYMBOLS OVEN THERMOSTAT OVEN FUNCTIONS FRONT LEFT-HAND COOKING ZONE REAR LEFT-HAND COOKING ZONE THERMOSTAT KNOB Selection of cooking temperature is carried out by turning the knob clockwise to the required temperature, between 50°...
  • Page 14 Instructions for the user Turn the knob to select from the following functions: NO FUNCTION SET UPPER AND LOWER HEATING ELEMENT UPPER AND LOWER HEATING ELEMENT + VENTILATION GRILL ELEMENT GRILL ELEMENT + VENTILATION To light the flame, press and turn the knob anticlockwise to the large flame symbol.
  • Page 15 Instructions for the user 5.2 Electronic Analogue Clock (on some models only) LIST OF FUNCTIONS MINUTE-MINDER BUTTON AUTOMATIC SWITCH-OFF TIMING BUTTON TIME SETTING AND RESET VALUE DECREASE BUTTON VALUE INCREASE BUTTON 5.2.1 Setting the time When the oven is used for the first time, or after a power blackout, the display flashes on and off at regular intervals.
  • Page 16 Instructions for the user 5.2.2 Minute-minder This function does not stop cooking but just triggers the beeps. When the illuminates, appearing as shown in figure 1; Press the set the minute-minder. pressed, 1 outside segment, representing 1 cooking minute will light up (figure 2 shows 10 cooking minutes).
  • Page 17 Instructions for the user 5.2.3 Programming Cooking duration time: the 2 time. Before setting it, turn the thermostat to the cooking temperature of choice and the function selector knob to any setting. To set the cooking time, proceed as follows: Press the key for 1/2 seconds;...
  • Page 18 Instructions for the user Cooking start: as well as setting a cooking duration time, the user can also set the cooking start time (up to 12 hours after the current time). To set the cooking start/end time, proceed as follows. Set the cooking duration time as described in the previous point.

  • Page 19: Use Of The Cooking Hob

    Instructions for the user 6. USE OF THE COOKING HOB 6.1 Lighting of the cooking hob burners Before lighting the hob burners check that the flame caps are in the correct position and that their burner caps are in place, making sure that the holes A in the flame caps correspond to the spark plugs and thermocouples.

  • Page 20: Diameter Of Containers

    Instructions for the user 6.2 Practical advice for using the cooking hob burners For better use of the burners and lower gas consumption, use covered containers that are proportional in size to the burner to prevent the flame from licking the sides (see paragraph “6.3 Diameter of containers"). When water reaches the boiling point, lower the flame so that it doesn’t overflow.

  • Page 21: Use Of The Oven

    Instructions for the user 7. USE OF THE OVEN Before using the oven make sure that the the analog programmer shows symbol (see paragraph "5.2.4 Manual mode cooking "). In models equipped with analogue digital timer, the user has only to press the central key for 1/2 seconds to enable use of the oven on first use or after a power blackout.

  • Page 22: Available Accessories

    Instructions for the user 8. AVAILABLE ACCESSORIES The oven features 4 support positions for plates and racks of different height. Oven grill: for cooking food on plates, small cakes, roasts or food requiring light grilling. Plate grill: for placing above plate for cooking foods that might drip.

  • Page 23: Cooking Hints

    Instructions for the user 9. COOKING HINTS 9.1 Traditional cooking FUNCTION SWITCH THERMOSTAT SELECTOR SWITCH FROM 50° TO 250°C This traditional cooking method, in which heat comes from above and below, is suitable for cooking food on a single level. You have to pre- heat the oven until the set temperature is reached.
  • Page 24 Instructions for the user Multiple cooking is possible as long as the cooking temperature of the different foods is the same. Keep the oven door closed during grilling. Grilling with the door open could permanently damage the oven and affect safety of operation.
  • Page 25 Instructions for the user 9.4 Hot-air grilling FUNCTION SWITCH THERMOSTAT SWITCH FROM 50° TO 250°C Ensures uniform heat distribution with greater heat penetration into the food. Food will be lightly browned on the outside and remain soft inside. Keep the oven door closed during cooking. 9.5 Defrosting FUNCTION SWITCH THERMOSTAT SWITCH IN POSITION 0...
  • Page 26 Instructions for the user 9.6 Spit cooking FUNCTION SWITCH THERMOSTAT SWITCH FROM 50° TO 200°C Prepare the spit with the food, blocking fork screws A. Insert frame B into the third guide from the bottom. Remove handle D and position the spit shaft so that pulley E is guided on the link of frame B in the right side.

  • Page 27: Cleaning And Maintenance

    Instructions for the user CLEANING AND MAINTENANCE 10.1 Cleaning stainless steel Before performing any operations requiring access to powered parts, switch off the power supply to the machine. To keep stainless steel in good condition it should be cleaned regularly after use.
  • Page 28 Instructions for the user 10.2.2 Burner caps, flame cap crowns and burners To facilitate cleaning, caps, flame cap crowns, and burners are all removable. To remove the flame separating crown of the fish hob, loosen the two screws exposed after having removed the cap. Wash all parts with warm water and non-abrasive detergent taking care to remove all tough spots.

  • Page 29: Door Glass

    Instructions for the user For easier cleaning, the storage drawer underneath the oven can be completely removed. Pull it right out and raise the front (as for an ordinary drawer). 10.3.1 Self-cleaning liners The main oven is equipped with continuous self-cleaning enamelled liners. These liners make the oven easier to clean and ensure its efficiency over time.

  • Page 30: Extraordinary Maintenance

    Instructions for the user EXTRAORDINARY MAINTENANCE The oven may require extraordinary maintenance or replacement of parts subject to wear such as seals, bulbs, and so on. The following instructions describe how to carry out these minor maintenance operations. Before any intervention, disconnect the power supply of the device. 11.1 Replacement of light bulb Remove cover A by twisting anticlockwise, replace bulb B with another similar bulb.

  • Page 31: Removing The Door

    Instructions for the user 11.2 Removing the door Open the door completely and fit the pins (supplied) into the holes from the inside. Close the door to an angle of about 45°, lift it and remove it from its seat. To replace, fit the hinges into the grooves provided, then lower the door until it comes to rest and extract the pins.
  • Page 32 914773199/ B...
