- Page 1 LBS106F Washing Machine Lavatrice...
-
Page 2: General Safety
1 Warnings General Safety • Never place your machine on a carpet covered floor. Otherwise, lack of airflow from below of your machine may cause electrical parts to overheat. This may cause problems with your washing machine. • If the power cable or mains plug is damaged you must call Authorized Service for repair. • Fit the drain hose into the discharge housing securely to prevent any water leakage and to allow machine to take in and discharge water as required. It is very important that the water intake and drain hoses are not folded, squeezed, or broken when the appliance is pushed into place after it is installed or cleaned. • Your washing machine is designed to continue operating when the power restores after a power interruption. The machine will resume its program when the power restores. Press the “Start/Pause/Cancel” button for 3 seconds to cancel the program (See, Canceling a Program) • There may be some water in your machine when you receive it. This is from the quality control process and is normal. It is not harmful to your machine. • Some problems you may encounter may be caused by the infrastructure. Press “Start/ Pause/Cancel” button for 3 seconds to cancel the program set in your machine before calling the authorized service. -
Page 3: Installation
2 Installation Removing packaging reinforcement Tilt the machine to remove the packaging reinforcement. Remove the packaging reinforcement by pulling the ribbon. Opening the transportation locks Transportation safety bolts must be removed before operating the washing machine! Otherwise, the machine will be damaged! 1. Loosen all the bolts with a spanner until they rotate freely (“C”) 2. Remove transportation safety bolts by turning them gently. 3. Fit the covers (supplied in the bag with the Operation Manual) into the holes on the rear panel. (“P”) Keep the transportation safety bolts in a safe place to reuse when the washing machine needs to be moved again in the future. Never move the appliance without the transportation safety bolts properly fixed in place! Adjusting the feet Do not use any tools to loosen the lock nuts. Otherwise, they can be damaged. 1. Manually (by hand) loosen the lock nuts on the feet. 2. Adjust them until the machine stands level and firmly. -
Page 4: Initial Preparations For Washing
• The specified voltage must be equal to your mains voltage. • Connection via extension cords or multi-plugs should not be made. A damaged power cable must be replaced by a qualified electrician. The appliance must not be operated unless it is repaired! There is the risk of electric shock! 3 Initial preparations for washing Preparing clothes for washing Laundry items with metal attachments such as, bras, belt buckles and metal buttons will damage the machine. Remove metal attachments or place the items in a clothing bag, pillow case, or something similar. • Sort the laundry according to type of fabric, color, and degree of soiling and permissible water temperature. Always follow the advice on the garment labels. • Place small items like infants’ socks and nylon stockings, etc. in a laundry bag, pillow case or something similar. This will also save your laundry from getting lost. • Wash “machine washable” or “hand washable” labeled products only with an appropriate program. • Do not wash colors and whites together. New, dark colored cottons may release a lot of dye. -
Page 5: Selecting A Program And Operating Your Machine
4 Selecting a program and operating your machine Control panel 1 - Spin Speed Adjustment Knob * 2 - Time Delay Button * 3 - Temperature Adjustment Knob * 4 - Start/Pause/Cancel Button 5 - Auxiliary Function Keys 6 - Program Selection Knob Turning the machine on You can prepare the machine for program selection by pressing the “On/Off” button. When the “On/Off” button is pressed, the “Ready” light illuminates indicating that the door is ulocked. Press the “On/Off” button again to shut down the machine. Program selection Select the appropriate program from the program table and the following washing temperature table according to type, amount and degree of soiling of the laundry. Select the desired program with the program selection button. Each of these programs consist of a complete washing process, including wash, rinse and, if required, spin cycles. -
Page 6: Spin Speed Selection
shorter washing cycle is used compared to the “Cottons” program. It is recommended for your synthetic clothes (such as shirts, blouses, synthetic/cotton blended garments, etc.). For curtains and lace, the “Synthetic 40” program with pre-wash and anti-creasing functions selected is recommended. • Lana (Woollens) You can wash your machine-washable woolen garments on this program. Wash by selecting the proper temperature according to the labels of your clothes. It is recommended to use appropriate detergents for woolens. Additional programs For special cases, there are also extra programs available: Additional programs may differ according to the model of your machine. • Camicie 40 • Babycare You can use this program to wash the shirts made Increased hygiene is provided by a longer of cotton, synthetic and synthetic blended fabrics. heating period and an additional rinse cycle. It is recommended for baby clothes and clothes worn by allergic people. • Delicati 30 (Delicate) You can wash your delicate clothes on this program. It has more sensitive washing movements and does not make intermediate spinning compared to “Synthetic” program. •... -
Page 7: Program Selection And Consumption Table
Program selection and consumption table Programme Cotone Cotone Cotone Cotone Intensivo 60 Sintetici Sintetici Sintetici Camicie 40 Delicati 30 Lana Lana Lavaggio a Mano 30 • : Selectable * : Automatically selected, not cancellable. **: Energy Label programme (EN 60456) Water and power consumption and programme duration may differ from the table shown, subject to changes in water pressure, water hardness and temperature, ambient temperature, type and amount of laundry, selection of auxiliary functions, and fluctuations in the supply voltage. The auxiliary functions in the table may differ according to the model of your machine. 60** 1.02 0.65 Cold 0.21 1.35 0.85 Cold 0.12 0.39 0.25... -
Page 8: Auxiliary Functions
Auxiliary functions Auxiliary function selection keys Select the required auxiliary functions before starting the program. Auxiliary function buttons may differ according to the model of your machine. Auxiliary function selection If an auxiliary function that should not be selected together with a previously selected function is chosen, the first selected function will be cancelled and the last auxiliary function selection will remain active. Auxiliary function that is not compatible with the program cannot be selected. (see “Program Selection Table”) • Prelavaggio (Prewash) A pre-wash is only worthwhile for heavily soiled laundry. Without pre-wash you save energy, water, detergent and time. Pre-wash without detergent is recommended for lace and curtains. • Rapido (Quick Wash) This function can be used for cottons and synthetics programs. It decreases the washing times for lightly soiled laundries and also the number of rinsing steps. Shortens the program time approximately 45 minutes. • Risciacquo Aggiuntivo (Rinse Plus) With this function, you can increase the number of current rinsing steps. Thus, sensitive skins’ risk of being affected by the remainder detergent on the... -
Page 9: Maintenance And Cleaning
Auxiliary functions can be cancelled or selected in accordance with the step the program is at. The door can be opened if the water level is suitable. Laundry may be added / taken out by opening the door. Child-proof lock This function protects the appliance from being tampered by children. In this case, all of the buttons are inactive except On/Off button; by On/ Off button you can whether stop or resume (while child-lock on) the program of your machine. The machine is switched to child-lock by pressing the 1st and 2nd auxiliary functions from the left for 3 sec. Child-proof lock lamp on the program follow-up indicator will light up when the child-proof lock is activated. To deactivate the child-proof lock, press the same buttons for 3 sec. Ending the program through canceling In order to cancel the selected program, press the “Start/Pause/Cancel” button for 3 seconds. You can select and start a new program when the “Ready” light is lit. The “Spin” light illuminates if the cancellation process is activated in the middle of the program and the machine can either drain all the water or can take in water 3 times at most to cool down the clothes and perform the draining process. The program which is selected first will keep on going even if the position of the program selection button is changed. A new program can be selected or started after “Program is cancelled” in order to change the washing program. End of program The “Ready” lamp on the program follow-up indicator will light up when the program comes to an end. The door can be opened and the machine... - Page 10 buttons, coins and fabric fibers from clogging the pump propeller during discharge of the washing water. • If your machine fails to drain the water, the pump filter may be clogged. You may have to clean it every 2 years or whenever it is plugged. Water must be drained off to clean the pump filter. In addition, water may have to be drained off completely in the following cases: • before transporting the machine (e.g. when moving house) • when there is the danger of frost In order to clean the dirty filter and discharge the water; 1- Unplug the machine to cut off the supply power. There may be water at 90°C in the machine. Therefore, the filter must be cleaned only after the inside water is cooled down to avoid hazard of scalding. 2- Open the filter cap. The filter cap may be composed of one or two pieces according to the model of your machine. If it is composed of two pieces, press the tab on the filter cap downwards and pull the piece out towards yourself. If it is composed of one piece, hold it from both sides and open it by pulling out. 3- An emergency drain hose is supplied with some of our models. Others are not supplied with this item. If your product is supplied with an emergency drain hose, do the following as shown in the figure below: • Pull out the pump outlet hose from its housing. • Place a large container at the end of the hose. Drain the water off into the container by pulling out the plug at the end of the hose. If the amount of water to be drained off is greater...
-
Page 11: Solution Suggestions For Problems
6 Solution suggestions for problems Cause Program cannot be started or selected. • Machine may have switched to self protection mode due to an infrastructure problem (such as line voltage, water pressure, etc.). There is water coming from the bottom of the machine. • There might be problems with hoses or the pump filter. Machine stopped shortly after the program started. • Machine can stop temporarily due to low voltage. It continuously spins. Remaining time does not count down. (For models with a display) • There may be an imbalance of laundry in the machine. It continuously washes. Remaining time does not count down. (For models with a display) • In the case of a paused countdown while taking in water: • Timer will not countdown until the machine is filled with the correct amount of water. • In the case of a paused countdown at the heating step: • Time will not count down until the selected temperature for the program is reached • In the case of a paused countdown at the spinning step: • There may be an imbalance of laundry in the machine. -
Page 12: Specifications
7 Specifications Models Maximum dry laundry capacity (kg) Height (cm) Width (cm) Depth (cm) Net Weight (±4 kg) Electricity (V/Hz.) Total Current (A) Total Power (W) Spinning cycle (rpm max.) Specifications of this appliance may change without notice to improve the quality of the product. Figures in this manual are schematic and may not match your product exactly. Values stated on the machine labels or in the documentation accompanying it are obtained in laboratory in accordance with the relevant standards. Depending on operational and environmental conditions of the appliance, values may vary. This appliance’s packaging material is recyclable. Help recycle it and protect the environment by dropping it off in the municipal receptacles provided for this purpose. Your appliance also con- tains a great amount of recyclable material. It is marked with this label to indicate the used appli- ances that should not be mixed with other waste. This way, the appliance recycling organised by your manufacturer will be done under the best possible conditions, in compliance with European Directive 2002/96/EC on Waste Electrical and Electronic Equipment. Contact your town hall or your retailer for the used appliance collection points closest to your home. We thank you doing your part to protect the environment. LBS106F 230 V / 50Hz 2200 1000 12 - EN...
